2010 NISSAN LATIO navigation system

NAVIGATION SYSTEMAV-75
< SERVICE INFORMATION > [AUDIO WITH NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
NAVIGATION SYSTEM
How to Proceed with Trouble DiagnosisINFOID:0000000005924437
Refer to AV-65, "Symptom Chart".
Revision: January 20102010 Versa

AV-76
< SERVICE INFORMATION >[AUDIO WITH NAVIGATION]
TELEPHONE
TELEPHONE
Component Parts and Harn
ess Connector LocationINFOID:0000000005924425
System DescriptionINFOID:0000000005988553
BLUETOOTH® HANDS-FREE PHONE SYSTEM
Refer to the Owner's Manual for Bluetoot h telephone system operating instructions.
NOTE:
Cellular telephones must have their wireless connection set up (paired) before using the Bluetooth telephone
system.
Bluetooth telephone system allows users who have a Bluetooth cellular telephone to make a wireless connec-
tion between their cellular telephone and the Bluetooth cont rol unit. Hands-free cellular telephone calls can be
sent and received. Some Bluetooth cellular telephones may not be recognized by the Bluetooth control unit.
AWNIA2212ZZ
1. AV control unit M702. Steering wheel audio control
switches 3. Combination meter M24
4. Bluetooth microphone R15 5. Bluetooth antenna (hatchback) 6. Bluetooth control unit B121, B122, B135
(hatchback) [view with luggage side lower
finisher (RH) removed]
7. Bluetooth antenna (sedan) 8. Bluetooth control unit B121,
B122, B135 (sedan) (view with
trunk side finisher RH removed)
Revision: January 20102010 Versa

TELEPHONEAV-77
< SERVICE INFORMATION > [AUDIO WITH NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
When a cellular telephone or the Bluetooth control unit is replaced, the telephone must be paired with the
Bluetooth control unit. Different cellular telephones may have different pairing procedures. Refer to the cellular
telephone operating manual.
Bluetooth Telephone System Diagram
Bluetooth Control Unit
When the ignition switch is turned to ACC or ON, the Bluetooth control unit will power up. During power up, the
Bluetooth control unit is initialized and performs various se lf checks. Initialization may take up to 20 seconds. If
a phone is present in the vehicle and paired with the Bl uetooth control unit, Nissan Voice Recognition will then
become active. Bluetooth telephone func tions can be turned off using the Nissan Voice Recognition system.
For Bluetooth control unit location, refer to AV-76, "
Component Parts and Harness Connector Location".
Steering Wheel Audio Control Switches
When buttons on the steering wheel audio control switch are pushed, the resistance in steering wheel audio
control switch circuit changes depending on which button is pushed. The Bluetooth control module uses this
signal to perform various functions while navigating through the voice recognition system.
The following functions can be performed usi ng the steering wheel audio control switch:
• Initiate Self Diagnosis of the Bluetooth telephone system
• Start a voice recognition session
• Answer and end telephone calls
• Adjust the volume of calls
Volume Switch
Call volume can be adjusted using the AV control unit volume switch.
Bluetooth Microphone
The Bluetooth microphone is located in the roof console assembly. The Bluetooth microphone sends a signal
to the Bluetooth control unit. The Bluetooth microphone can be actively tested during self-diagnosis. For Blue-
tooth microphone location, refer to AV-76, "
Component Parts and Harness Connector Location".
AV Control Unit
The AV control unit receives signals from the Bluetoot h control unit and sends audio signals to the speakers.
AWNIA2191GB
Revision: January 20102010 Versa

AV-80
< SERVICE INFORMATION >[AUDIO WITH NAVIGATION]
TELEPHONE
Bluetooth Control Unit Harnes s Connector Terminal Layout
INFOID:0000000005924428
Terminal and Reference Value for Bluetooth Control UnitINFOID:0000000005924429
AWNIA1988GB
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
(Approx.) Example of symptom
+– Ignition
switch Operation
1 (R) Ground Battery pow-
erInput –
–Battery voltage System does not
work properly.
2 (L) Ground ACC power Input ACC/
ON –
Battery voltage System does not
work properly.
3 (LG) Ground IGN power Input ON/
START –
Battery voltage System does not
work properly.
4 (B) – Ground – – –– –
5–Shield –– – ––
6–Shield –– – ––
7 (R/W) 8 (R/L) Mic-in signal Input – ––Bluetooth Micro-
phone inoperative.
9 (LG) 10 (V) Audio out Output ACC/
ON Bluetooth control
unit sends audio
signal Audio can not be
heard.
21 (B) – Cont-2 – – –– –
27 (B) – Cont-6 – – –– –
28 (O) Ground Vehicle
speed signal
(8–pulse)Input ON When vehicle
speed is approx.
40 km/h (25
MPH) Speed sensitive vol-
ume is inoperative.
29 (B) Ground Bluetooth
Microphone
powerOutput –
–5VBluetooth Micro-
phone inoperative.
33 – Bluetooth
antenna sig-
nalInput –
– – –
35 (L) — M CAN + — — —— —
SKIB3609E
PKIC0643E
Revision: January 20102010 Versa

TELEPHONEAV-81
< SERVICE INFORMATION > [AUDIO WITH NAVIGATION]
C
D
E
F
G H
I
J
L
M A
B
AV
N
O P
Bluetooth Control Unit Self-Diagnosis FunctionINFOID:0000000005924430
The Bluetooth control unit has two diagnostic checks. The first diagnostic check is performed automatically
every ignition cycle during control unit initialization. The second diagnostic check is performed by the techni-
cian using the steering wheel audio control switches prior to trouble diagnosis.
BLUETOOTH CONTROL UNIT INITIALIZATION CHECKS
• Internal control unit failure
• Bluetooth antenna connection open or shorted
• Steering wheel audio control switches (PHONE/SEND, PHONE/END) stuck closed
• Vehicle speed pulse count
• Bluetooth Microphone connection test (with playback to operator)
• Bluetooth inquiry check
SELF-DIAGNOSIS MODE
1. Turn ignition switch to ACC or ON.
2. Wait for the Bluetooth system to complete initialization. This may take up to 20 seconds.
3. Press and hold the steering wheel audio control switch PHONE/ SEND button for at least 5 seconds. The Bluetooth system will
begin to play a verbal prompt.
NOTE:
At any time, press and hold the steering wheel audio control
switch PHONE/SEND button for at least 5 seconds to exit diag-
nostic mode.
4. While the prompt is playing, press and hold the steering wheel audio control switch PHONE/END button for at least 5 seconds.
The Bluetooth system will sound a 5 second beep.
5. While the beep is sounding, press and hold the steering wheel audio control switch PHONE/END button for at least 5 seconds
again.
6. The Bluetooth system has now entered into the diagnostic
mode. Results of the diagnostic checks will be verbalized to the
technician. Refer to AV-82, "
Workflow".
7. If there are no failure records to report, the speed pulse count
will be reported next.
8. After the speed pulse count is reported, an interactive Bluetooth microphone test will be performed. Follow the voice pr ompt. If the Bluetooth microphone test fails refer to
AV-82, "
Workflow".
9. Self-diagnosis mode is complete when the voice prompt says "All diagnostic functions completed". A short beep is heard.
36 (P) — M CAN - — — —— —
37 — M CAN
shield—— —
——
39 (Y/R) — M CAN
jumper 1—— —
——
40 (Y/R) — M CAN 1 — — —— —
41 (SB) — M CAN
jumper 2
—— —
——
42 (SB) — M CAN 2 — — —— —
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
(Approx.) Example of symptom
+– Ignition
switch Operation
WKIA6003E
AWNIA2219GB
Revision: January 20102010 Versa

AV-82
< SERVICE INFORMATION >[AUDIO WITH NAVIGATION]
TELEPHONE
Workflow
INFOID:0000000005924431
Power Supply and Ground Circuit Inspection for Bluetooth Control UnitINFOID:0000000005924432
1.CHECK FUSES
Make sure the following fuses for the Bluetooth control unit are not blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
4.
2.CHECK POWER SUPPLY CIRCUIT
1. Disconnect Bluetooth control unit connector B121.
2. Check voltage between connector terminals and ground as fol- lows.
OK or NG
OK >> GO TO 3.
NG >> Check harness for open between Bluetooth control unit and fuse.
3.CHECK GROUND CIRCUITS
1. Turn ignition switch OFF.
Failure Message Action
“Internal failure” Replace Bluetooth control unit. Refer to AV- 8 5 , "
Removal and Installation".
“Bluetooth antenna open” 1. Inspect harness connection.
2. Replace Bluetooth antenna. Refer to AV- 8 5 , "
Removal and Installation".
“Bluetooth antenna shorted”
“Phone/Send for Hands Free System is stuck” Check steering wheel audio control switches. Refer to AV- 6 8 , "
Steering Switch
Check".
“Phone/End for the Hands Free System is stuck”
“Microphone test” (failed interactive test) 1. Inspect harness between Bluetooth control unit and microphone.
2. Replace microphone. Refer to
AV- 8 5 , "
Removal and Installation".
Te r m i n a l s
Ignition Switch Fuse No.
Connector Terminal
B121 1
All positions27
2 ACC/ON20
3 ON/START3
Terminals Ignition switch position
(+) (–) OFF ACC ON
Connector Terminal
B121 1
Ground Battery
voltage Battery
voltage Battery
voltage
20 VBattery
voltage Battery
voltage
30 V0V Battery
voltage
WKIA4389E
Revision: January 20102010 Versa
