93
1-6. Refueling
1
Before driving
Closing the fuel tank cap
After refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.
■If the fuel filler door opener is inoperable
■Fuel types
Use unleaded gasoline. (Octane rating 8
7 [Research Octane Number 91] or
higher)
■Fuel tank capacity
Approximately 14.5 gal. (55 L, 12.5 lmp. gal.)
■Use of ethanol blended gasoline in a gasoline engine
Lexus allows the use of ethanol blended gasoline where the ethanol content is up to
1
0%. Make sure that the ethanol blended gasoline to be used has a Research
Octane Number that follows the above.
The lever can be used to open the fuel filler
door if the fuel filler door cannot be opened
using the inside switch.

530
5-2. Steps to take in an emergency
If the hybrid system will not start
Reasons for the hybrid system not starting vary depending on the situation.
Check the following and perform the appropriate procedure:
■The hybrid system will not start even though the correct starting
procedure is being followed. ( P. 1 4 7 )
One of the following may be the cause of the problem:
● The electr
onic key may not be functioning properly.* (P. 5 3 3 )
● Ther
e may not be sufficient fuel in the vehicle’s tank. 
Refuel the vehicle.
● Ther
e may be a malfunction in the immobilizer system.* (P. 9 6 )
● Ther
e may be a malfunction in the P position control system.* 
( P. 1 5 0 , 502 )
● The hybrid s
ystem may be malfunc tioning due to an electrical
problem such as an open circuit or a blown fuse. However,
depending on the type of malfunc tion, an interim measure is avail-
able to start the hybrid system. ( P. 4 5 5)
*: It may not be possible to shift out of the P position.
■The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.
One of the following may be the cause of the problem:
● The 12-
volt battery may be discharged. (P. 5 3 6 )
● The 12-
volt battery terminal co nnections may be loose or cor-
roded.

550
6-1. Specifications
Fuel
Electric motor (Traction motor)
Hybrid battery (Traction battery)
Lubrication system
Fuel typeUnleaded gasoline only
Octane rating87 (Research octane number 91) or higher
Fuel tank capacity14.5 gal. (55 L, 12.5 Imp. gal.)
Ty p ePermanent magnet synchronous motor
Maximum output105 kW
Maximum torque199 ft•lbf (270 N•m, 27.5 kgf•m)
Ty p eNickel-metal hydride battery
Vo l t a g e7.2 V/module
Capacity6.5 Ah (3HR)
Quantity34 modules
Overall voltage244.8 V
Oil capacity 
Drain and refill 
(Reference)
With filter
Without filter

4.5 qt. (4.3 L, 3.8 lmp.qt.)
4.3 qt. (4.1 L, 3.6 lmp.qt.)

558
6-1. Specifications
■Recommendation of the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxygen-
ates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in many
areas.
Lexus recommends the use of cleaner burning gasoline and appropriately blended
reformulated gasoline. These types of gasoline provide excellent vehicle perfor-
mance, reduce vehicle emissions and improve air quality.
■Non-recommendation of the use of blended gasoline
●Lexus allows the use of oxygenate blended gasoline where the oxygenate con-
tent is up to 10% ethanol or 15% MTBE.
●If you use gasohol in your vehicle, be sure that it has an octane rating no lower
than 87.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcyclo-
pentadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoli ne that contains MMT. If fuel contain-
ing MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instrument panel may come on. If this hap-
pens, contact your Lexus dealer for service.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking for a short time while accelerating
or driving uphill. This is normal and there is no need for concern.

559
6-1. Specifications
6
Vehicle specifications
NOTICE
■Notice on fuel quality
●Do not use improper fuels. If improper fuels are used, the engine will be dam-
aged.
●Do not use leaded gasoline. 
Leaded gasoline can cause damage to your vehicle’s three-way catalytic convert-
ers causing the emission control system to malfunction.
●Do not use gasohol other than the type previously stated. 
Other gasohol may cause fuel system damage or vehicle performance problems.
●Using unleaded gasoline with an octane number or rating lower than the level
previously stated will cause persistent heavy knocking. 
At worst, this will lead to engine damage.
■Fuel-related poor driveability
If poor driveability is encountered after using a different type of fuel (poor hot start-
ing, vaporization, engine knoc king, etc.), discontinue the use of that type of fuel.
■When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle’s paint.

596
Alphabetical index
Engine oilCapacity ................................................ 550
Checking ............................................... 424
Preparing and checking 
before winter .................................... 244
Engine oil maintenance data............ 426
Engine switch............................................147
Enhanced VSC...................................... 225
EPS ............................................................. 225
EV drive mode switch .......................... 152
Event data recorder ............................490
Floor mat ................................................. 380
Fluid Brake........................................................554
Washer ................................................... 432
Fog lights Replacing light bulbs........................ 469
Switch ........................................................194
Wattage..................................................556
Foot light ...................................................360
Foot well lighting ...................................360
Front fog lights
Replacing light bulbs........................ 469
Switch ........................................................194
Wattage..................................................556
Front passenger occupant 
classification system ............................115
Front passenger's seat belt 
reminder light......................................495 Front seats
Adjustment ...............................................64
Driver’s seat po sition memory ...... 68
Front side marker light Replacing light bulbs ....................... 469
Wattage ................................................. 556
Front turn signal lights Replacing light bulbs ....................... 469
Switch ........................................................ 162
Wattage ................................................. 556
Fuel Capacity ................................................550
Fuel gauge .............................................. 162
Gas station information .................608
Information ........................................... 557
Refueling .................................................... 92
Type ......................................................... 557
Fuel door ..................................................... 92
Fuel filler door ........................................... 92
Fuses .......................................................... 455
Garage door opener .......................... 383
Gas station information .....................608
Gauges .......................................................162
Glove box ................................................ 364
Grocery bag hooks .............................. 381
F
G

608
GAS STATION INFORMATION
Auxiliary catch leverP. 4 1 9Trunk openerP. 6 0Fuel filler door P. 9 2
Hood lock release lever P. 4 1 9Fuel filler door openerP. 9 2Ti r e i n f l a t i o n p r e s s u r eP. 5 5 5
Fuel tank capacity14.5 gal. (55 L, 12.5 Imp. gal.)
Fuel typeUnleaded gasoline only P. 550
Cold tire inflation 
pressureP. 555
Engine oil capacity
(Drain and refill)qt. (L, Imp. qt.)
With filter 4.5 (4.3, 3.8)
Without filter 4.3 (4.1, 3.6
)
Engine oil typeToyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 551
Recommended oil viscosity: SAE-0W-20
