2010 Lexus HS250h oil filter

418
4-3. Do-it-yourself maintenance
CAUTION
The engine compartment contains many mechanisms and fluids that may move sud-
denly, become hot, or become electrically energized. To avoid death or serious injury,
observe the following precautions:
■When working on the engine compartment
●Make sure that the indicator on the “POWER” switch and the “READY” indicator
are both off.
●Keep hands, clothing and tools away from the moving fans and engine drive belt.
●Be careful not to touch the engine, power control unit, radiator, exhaust manifold,
etc. right after driving as they may be hot. Oil and other fluids may also be hot.
●Do not leave anything that may burn easily, such as paper and rags, in the engine
compartment.
●Do not smoke, cause sparks or expose an open flame to fuel. Fuel fumes are flam-
mable.
■When working near the electric cooling fans or radiator grille
Be sure the “POWER” switch is off. 
With the “POWER” switch in ON mode, the electric cooling fans may automati-
cally start to run if the air conditioning is on and/or the coolant temperature is high. 
(  P. 4 3 0 )
■Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc. from getting
in your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear due to
dirt in the air. Also, a backfire could cause a fire in the engine compartment.

427
4-3. Do-it-yourself maintenance
4
Maintenance and care
CAUTION
■Used engine oil
●Used engine oil contains potentially harmful contaminants which may cause skin
disorders such as inflammation and skin cancer, so care should be taken to avoid
prolonged and repeated contact. To remove used engine oil from your skin, wash
thoroughly with soap and water.
●Dispose of used oil and filters only in a safe and acceptable manner. Do not dis-
pose of used oil and filters in househol d trash, in sewers or onto the ground. 
Call your Lexus dealer, service station or auto parts store for information con-
cerning recycling or disposal.
●Do not leave used engine oil within the reach of children.
NOTICE
■To prevent serious engine damage
Check the oil level on a regular basis.
■When replacing the engine oil
●Be careful not to spill engine oil on the vehicle components.
●Avoid overfilling, or the engine could be damaged.
●Check the oil level on the dipstick every time you refill the vehicle.
●Be sure the engine oil filler cap is properly tightened.

550
6-1. Specifications
Fuel
Electric motor (Traction motor)
Hybrid battery (Traction battery)
Lubrication system
Fuel typeUnleaded gasoline only
Octane rating87 (Research octane number 91) or higher
Fuel tank capacity14.5 gal. (55 L, 12.5 Imp. gal.)
Ty p ePermanent magnet synchronous motor
Maximum output105 kW
Maximum torque199 ft•lbf (270 N•m, 27.5 kgf•m)
Ty p eNickel-metal hydride battery
Vo l t a g e7.2 V/module
Capacity6.5 Ah (3HR)
Quantity34 modules
Overall voltage244.8 V
Oil capacity 
Drain and refill 
(Reference)
With filter
Without filter

4.5 qt. (4.3 L, 3.8 lmp.qt.)
4.3 qt. (4.1 L, 3.6 lmp.qt.)

598
Alphabetical index
Keyless entry.............................................. 54
KeysElectronic key ......................................... 39
Engine switch......................................... 147
If the electronic key does not 
operate properly ............................ 533
If you lose your keys......................... 532
Key number ............................................. 39
Keyless entry ........................................... 54
Keys ............................................................. 39
Mechanical key...................................... 40
Wireless remote control key .......... 54
Lane keeping assist ................................217
License plate lights Replacing light bulbs........................ 470
Wattage..................................................556
Light bulbs Replacing ............................................... 469
Wattage..................................................556
Light Door courtesy lights.........................360
Fog light switch .....................................194
Footwell lights......................................360
Headlight switch ................................. 183
Interior light list ....................................360
Interior light switch ..............................361
Outer foot lights .................................360
Personal light switch ..........................361
Remote touch light............................360
Replacing light bulbs........................ 469
Scuff lighting .........................................360
Turn signal lever ................................... 162
Turn signal light bulbs...................... 469
Turn signal light switch...................... 162 Vanity lights........................................... 372
Wattage ................................................. 556
LKA .............................................................. 217
Load capacity......................................... 243
Maintenance Do-it-yourself maintenance........... 416
General maintenance......................... 411
Maintenance data ............................. 548
Maintenance requirements.......... 409
Meter Instrument panel light control ....... 163
Meters ....................................................... 162
Micro dust and pollen filter .............. 256
Mirrors Inside rear view mirror ........................ 81
Side mirror heater............................. 260
Side mirrors............................................. 83
Vanity mirrors ...................................... 372
Moon roof................................................... 89
MP3 disc ................................................... 281
Multi-information display ....................169
Noise from under vehicle ......................18
Odometer .................................................162
Oil Engine oil................................................424
Opener Fuel filler door ......................................... 92
Hood ......................................................... 419
Trunk........................................................... 60K
L
M
N
O

608
GAS STATION INFORMATION
Auxiliary catch leverP. 4 1 9Trunk openerP. 6 0Fuel filler door P. 9 2
Hood lock release lever P. 4 1 9Fuel filler door openerP. 9 2Ti r e i n f l a t i o n p r e s s u r eP. 5 5 5
Fuel tank capacity14.5 gal. (55 L, 12.5 Imp. gal.)
Fuel typeUnleaded gasoline only P. 550
Cold tire inflation 
pressureP. 555
Engine oil capacity
(Drain and refill)qt. (L, Imp. qt.)
With filter 4.5 (4.3, 3.8)
Without filter 4.3 (4.1, 3.6
)
Engine oil typeToyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 551
Recommended oil viscosity: SAE-0W-20
