WIDE VIEW FRONT & SIDE MONITOR
318 D
Wide view front & side monitor
cameras
"1Side camera
2Front camera
When the camera is used under fluores-
cent lights, sodium lights, mercury lights
etc., the lights and the illuminated areas
may appear to flicker.
In the following cases, it may be difficult to
see the images on the screen, even when
the system is functioning correctly.
DIn the dark (e.g. at night).
DIf the temperature near the lens is ex-
tremely high or low.
DIf water droplets get on the camera, or
when humidity is high (e.g. when it
rains).
DIf the camera has scratches or dirt on
it.
DIf foreign matter (e.g. snow or mud) get
on the camera lens.
DIf the sun or headlights are shining di-
rectly into the camera lens.
DIf the camera lens is damaged by flying
stones.
DSmear effect
If a bright light (for example, sunlight re-
flected off the vehicle body) is picked up by
the camera, a smear effect* peculiar to the
camera may occur.
*: Smear effect — A phenomenon that oc- curs when a bright light (for example,
sunlight reflected off the vehicle body) is
picked up by the camera; when trans-
mitted by the light source will appear to
have streaks of light emanating from it.
The streaks will also appear when the
light source is in the masked area.
