2010 JEEP LIBERTY engine

126,000 Miles (210,000 km) or
126 Months Maintenance
Service Schedule
❏Change the engine oil and engine oil
filter.
❏ Rotate tires.
❏ Inspect the front and rear axle fluid;
change if using your vehicle for police,
taxi, fleet, off-road or frequent trailer
towing.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
132,000 Miles (220,000 km) or 132 Months Maintenance Service
Schedule
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the air conditioning filter.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the
engine air cleaner filter; replace if necessary.
❏ Inspect the brake linings; replace if necessary.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for
damage, wear, improper looseness or end play; replace if necessary.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
8
M
A I
N T
E
N A
N CE
S
C
H E
D
U L
E
SMAINTENANCE SCHEDULES 485

138,000 Miles (230,000 km) or
138 Months Maintenance
Service Schedule
❏Change the engine oil and engine oil
filter.
❏ Rotate tires.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
144,000 Miles (240,000 km) or 144 Months Maintenance Service
Schedule
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the air conditioning filter.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the
engine air cleaner filter; replace if necessary.
❏ Inspect the brake linings; replace if necessary.
❏ Inspect the front and rear axle fluid; change if using your vehicle for police, taxi, fleet,
off-road or frequent trailer towing.
❏ Inspect the CV joints.
❏ Inspect exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for
damage, wear, improper looseness or end play; replace if necessary.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
8
M
A I
N T
E
N A
N CE
S
C
H E
D
U L
E
S486 MAINTENANCE SCHEDULES

† This maintenance is recommended by the manufacturer
to the owner, but is not required to maintain emissions
warranty.
WARNING!
•You can be badly injured working on or around a
motor vehicle. Do only service work for which you
have the knowledge and the right equipment. If
you have any doubt about your ability to perform
a service job, take your vehicle to a competent
mechanic.
•Failure to properly inspect and maintain your
vehicle could result in a component malfunction
and effect vehicle handling and performance. This
could cause an accident
150,000 Miles (250,000 km) or
150 Months Maintenance Service
Schedule
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the engine air cleaner filter.
❏ Replace the spark plugs (3.7L Engine).
❏ Adjust parking brake on vehicles equipped
with four-wheel disc brakes.
❏ Inspect the transfer case fluid.
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
8
M
A I
N T
E
N A
N CE
S
C
H E
D
U L
E
SMAINTENANCE SCHEDULES 487

has also made a major investment in facilities, tools, and
training to assure that you are absolutely delighted with
the ownership experience. You’ll be pleased with their
sincere efforts to resolve any warranty issues or related
concerns.
WARNING!
Engine exhaust, some of its constituents, and certain
vehicle components contain, or emit, chemicals
known to the State of California to cause cancer and
birth defects, or other reproductive harm. In addi-
tion, certain fluids contained in vehicles and certain
products of component wear contain, or emit, chemi-
cals known to the State of California to cause cancer
and birth defects, or other reproductive harm.
WARRANTY INFORMATION (U.S. Vehicles Only)
See the Warranty Information Booklet, located on the
DVD, for the terms and provisions of Chrysler Group
LLC warranties applicable to this vehicle.
MOPARPARTS
MOPAR fluids, lubricants, parts, and accessories are
available from an authorized dealer. They are recom-
mended for your vehicle in order to help keep the vehicle
operating at its best.
REPORTING SAFETY DEFECTS
In the 50 United States and Washington, D.C.
If you believe that your vehicle has a defect that could
cause a crash or cause injury or death, you should
immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying the
manufacturer.
494 IF YOU NEED CONSUMER ASSISTANCE

These comprehensive Service Manuals provide the
information that students and professional technicians
need in diagnosing/troubleshooting, problem solving,
maintaining, servicing, and repairing Chrysler Group
LLC vehicles. A complete working knowledge of the
vehicle, system, and/or components is written in
straightforward language with illustrations, diagrams,
and charts.
•Diagnostic Procedure Manuals
Diagnostic Procedure Manuals are filled with dia-
grams, charts and detailed illustrations. These practi-
cal manuals make it easy for students and technicians
to find and fix problems on computer-controlled ve-
hicle systems and features. They show exactly how to
find and correct problems the first time, using step-by-
step troubleshooting and drivability procedures,
proven diagnostic tests and a complete list of all tools
and equipment.
•Owner’s Manuals
These Owner’s Manuals have been prepared with the
assistance of service and engineering specialists to
acquaint you with specific Chrysler Group LLC ve-
hicles. Included are starting, operating, emergency
and maintenance procedures as well as specifications,
capabilities and safety tips.
Call toll free at:
•1–800–890–4038 (U.S.)
•1–800–387–1143 (Canada)
Or
Visit us on the Worldwide Web at:
•www.techauthority.com
496 IF YOU NEED CONSUMER ASSISTANCE

About Your Brakes....................... 327
ABS (Anti-Lock Brake System) ............329,332
Adding Engine Coolant (Antifreeze) .......... 437
Adding Fuel ........................... 378
Additives, Fuel ......................... 375
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 427
Air Conditioner Maintenance ............... 429
Air Conditioning ........................ 281
Air Conditioning Controls ................. 281
Air Conditioning Filter .................293,430
Air Conditioning, Operating Tips ............ 294
Air Conditioning Refrigerant .............429,430
Air Conditioning System .............281,285,429
Air Filter .............................. 427
Air Pressure, Tires ....................... 353
Airbag ................................ 56
Airbag Deployment ....................... 70
Airbag Light ....................... 73,87,222
Airbag Maintenance ....................... 72 Airbag, Window (Side Curtain)
............... 60
Alarm, Panic ............................ 24
Alarm (Security Alarm) .................17,222
Alarm System (Security Alarm) ............... 17
Alterations/Modifications, Vehicle ............. 8
Antenna, Satellite Radio ................... 275
Antifreeze (Engine Coolant) ...........436,437,465
Disposal ............................ 439
Anti-Lock Brake System (ABS) ............329,332
Anti-Lock Warning Light .................. 213
Anti-Theft Security Alarm (Theft Alarm) ........ 17
Anti-Theft System ....................... 222
Appearance Care ........................ 448
Arming Theft System (Security Alarm) ......... 17
Assist, Hill Start ........................ 334
Assistance Towing ....................... 112
Auto Down Power Windows ................ 35
Auto Unlock, Doors ....................... 31
Automatic Dimming Mirror ................. 94
500 INDEX

Brake/Transmission Interlock............... 303
Break-In Recommendations, New Vehicle ........ 85
Bulb Replacement ....................... 461
Bulbs, Light .......................... 88,461
Calibration, Compass ..................... 229
Capacities, Fluid ........................ 465
Caps, Filler Fuel ............................... 378
Oil (Engine) .......................... 426
Power Steering ........................ 327
Radiator (Coolant Pressure) ............... 438
Car Washes ............................ 449
Carbon Monoxide Warning ...............86,377
Cargo Area Cover ....................... 197
Cargo Area Features ...................... 193
Cargo Compartment ...................... 193
Light ............................... 154
Cargo Light ............................ 154 Cargo Load Floor
........................ 193
Cargo Tie-Downs ........................ 195
Cargo (Vehicle Loading) ................... 380
Cellular Phone .......................... 98
Certification Label ....................... 380
Changing A Flat Tire ..................... 405
Chart, Tire Sizing ........................ 345
Check Engine Light
(Malfunction Indicator Light) .............210,421
Checking Your Vehicle For Safety ............. 85
Checks, Safety ........................... 85
Child Restraint .................... 75,76,80,83
Child Restraint Tether Anchors .............79,80
Child Safety Locks ........................ 32
Clean Air Gasoline ....................... 373
Cleaning Windshield Wiper Blades ................ 431
Climate Control ......................... 281
Clock ........................ 237,251,254,263
502 INDEX

Coin Holder........................... 192
Cold Weather Operation ................... 300
Command-Trac Operation .................. 309
Compact Disc (CD) Maintenance ............. 280
Compact Spare Tire ...................... 355
Compass .............................. 229
Compass Calibration ..................... 229
Compass Variance ....................... 230
Computer, Trip/Travel .................... 227
Console .............................. 192
Console, Floor .......................... 192
Contract, Service ........................ 493
Coolant Pressure Cap (Radiator Cap) .......... 438
Cooling System ......................... 435
Adding Coolant (Antifreeze) .............. 437
Coolant Capacity ...................... 465
Coolant Level ...................... 435,439
Disposal of Used Coolant ................ 439
Drain, Flush, and Refill .................. 436 Inspection
........................... 439
Points to Remember .................... 440
Pressure Cap ......................... 438
Selection of Coolant (Antifreeze) ......436,465,466
Corrosion Protection ..................... 448
Cruise Light ........................... 220
Cupholders ............................ 191
Customer Assistance ..................... 491
Daytime Running Lights ................... 151
Dealer Service .......................... 423
Defroster, Rear Window ................... 200
Defroster, Windshield ................87,283,289
Delay (Intermittent) Wipers ................. 156
Diagnostic System, Onboard ................ 420
Dimmer Switch, Headlight ................. 153
Dipsticks Oil (Engine) .......................... 424
Power Steering ........................ 327
10
INDEX 503
