DTC Description Possible Causes Action Sensor or Left Rear
Vertical Acceleration
Sensor or Right Rear
Vertical Acceleration
Sensor supply partial
short to other circuit
or ground
Left Front Vertical
Acceleration Sensor or
Right Front Vertical
Acceleration Sensor or
Left Rear Vertical
Acceleration Sensor or
Right Rear Vertical
Acceleration Sensor
internal failure
Internal control
module failure U0001-88
High speed CAN
communication
bus - Bus off
Lost Communication
With Engine Control
Module (ECM) (CAN
Bus circuit fault)
Check Engine Control Module for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus circuit for faults,
check CAN circuits for open circuits or shorts to power, ground
or other circuits U0100-00
Lost
Communication
With ECM/PCM A
- No sub type
information
Missing message from
ECM
Check Engine Control Module for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus for circuit fault U0101-00
Lost
Communication
with TCM - No
sub type
information
Lost Communication
with Transmission
control module (TCM)
(CAN Bus circuit fault)
Check Transmission Control Module for stored DTCs. Refer to
the electrical circuit diagrams and check CAN Bus for circuit
fault U0103-00
Lost
Communication
With Gear Shift
Control Module
A - No sub type
information
Lost Communication
With Gear Shift
Module (GSM) (CAN
Bus circuit fault)
Check Gear Shift Module for stored DTCs. Refer to the
electrical circuit diagrams and check Can Bus for circuit faults U0121-00
Lost
Communication
With Anti-Lock
Brake System
(ABS) Control
Module - No sub type information
Lost Communication
With Anti-Lock Brake
System (ABS) Control
Module (CAN Bus
circuit fault)
Check Anti lock Brake System Control Module for stored DTCs.
Refer to the electrical circuit diagrams and check Can Bus
circuit to Anti lock Brake System Control Module for circuit
faults U0132-00 Lost
Lost Communication
Check Air Suspension Control Module for stored DTCs. Refer to Communication With Suspension With Air Suspension the electrical circuit diagrams and check CAN Bus circuit to Air Control Module Control Module (CAN Suspension Control Module for circuit faults A - No sub type Bus circuit fault information U0136-00
Lost
Communication
With Differential
Control Module -
Rear - No sub type information
Lost Communication
With Rear Differential
Control Module (CAN
Bus circuit fault)
Check Rear Differential Control Module for stored DTCs. Refer
to the electrical circuit diagrams and check Can Bus circuit to
Rear Differential Control Module for circuit faults U0140-00
Lost
Communication
With Body
Control Module -
No sub type
information
Lost Communication
With Body Control
Module (Front Smart
Junction Box) (CAN
Bus circuit fault)
Check Body Control Module for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus circuit to Body
Control Module for faults U0142-00
Lost
Communication
With Body
Control Module
B - No sub type
information
Lost Communication
with rear smart
junction box (CAN Bus
circuit fault)
Check Rear Smart Junction Box for stored DTCs. Refer to the
electrical circuit diagrams and check Can Bus circuit to Rear
Smart Junction Box for faults U0155-00
Lost
Communication
With Instrument
Panel Cluster
Lost Communication
With Instrument Panel
Cluster (IPC) Control
Check Instrument Panel Cluster for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus to Instrument
Panel Cluster for circuit fault

Published: 17-Apr-2014
General Information - Diagnostic Trouble Code (DTC) Index DTC: Anti-Lock Braking System (ABS)
Description and Operation

Anti-Lock Braking System (ABS)


CAUTION: Diagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not
guarantee confirmation of a fault, and may also cause additional faults in the vehicle being tested and/or the donor vehicle
NOTES:


If the control module or a component is suspect and the vehicle remains under manufacturer warranty, refer to the
warranty policy and procedures manual, or determine if any prior approval programme is in operation, prior to the installation
of a new module/component


Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to
the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the
manufacturer-approved diagnostic system)


When performing voltage or resistance tests, always use a digital multimeter accurate to three decimal places and with a
current calibration certificate. When testing resistance, always take the resistance of the digital multimeter leads into account


Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests


Inspect connectors for signs of water ingress, and pins for damage and/or corrosion


If diagnostic trouble codes are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent
concern may be the cause. Always check for loose connections and corroded terminals


Where an 'on demand self-test' is referred to, this can be accessed via the 'diagnostic trouble code monitor' tab on the
manufacturers approved diagnostic system


Check DDW for open campaigns. Refer to the corresponding bulletins and SSMs which may be valid for the specific
customer complaint and carry out the recommendations as required

The table below lists all Diagnostic Trouble Codes (DTCs) that could be logged in the anti-lock braking system module, for
additional diagnosis and testing information refer to the relevant Diagnosis and Testing Section.
For additional information, refer to: Anti-Lock Control - Stability Assist (206-09 Anti-Lock Control - Stability Assist, Diagnosis
and Testing).

DTC Description Possible Causes Action C0021-09
Brake Booster
Performance -
Component Failures
No vacuum available from
engine due to split/leaking
hose etc
Brake booster servo has
failed due to lack of vacuum
Check integrity of brake booster vacuum hose.
Check and install a new brake booster as required C0030-38
Left Front Tone
Wheel - Signal
frequency incorrect
Left front magnetic pulse
ring damaged/contaminated
Incorrect component
installed
Sensor internal fault
Check the left front magnetic pulse ring for damage
or contamination. Clean or replace as required. If no
damage/contamination found, suspect wheel speed
sensor. Refer to the Warranty Policy and Procedures
manual if a module/component is suspect. To
validate the repair and extinguish the lamps, the
vehicle needs to be driven above 9mph/15kph for
more than 10 seconds C0031-12
Left Front Wheel
Speed Sensor -
Short to battery
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to power. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a www.JagDocs.com

DTC Description Possible Causes Action module/component is suspect C0031-14
Left Front Wheel
Speed Sensor -
Circuit short to
ground or open
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground or
open circuit. Repair harness as required. If no
harness fault found, suspect wheel speed sensor.
Refer to the Warranty Policy and Procedures manual
if a module/component is suspect C0031-25
Left Front Wheel
Speed Sensor -
Signal
shape/waveform
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for partial or
intermittently grounded signal circuit. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph C0031-2F
Left Front Wheel
Speed Sensor -
Signal erratic
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph C0031-31
Left Front Wheel
Speed Sensor - No
signal
Electrical wiring harness
fault
Magnetic pulse ring
de-magnetised or damaged
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for open circuit or high
resistance. Check connectors for damage or
corrosion. Check the wheel speed sensor for correct
location and contamination. Check the magnetic
pulse wheel for contamination, damage or
de-magnetisation. Clean or replace the sensor or
wheel bearing as required. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph C0031-62
Left Front Wheel
Speed Sensor -
Signal compare
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph C0031-64
Left Front Wheel
Speed Sensor -
Signal plausibility
failure
Incorrect wheels/tyres
installed
Electrical wiring harness
fault
EMC influences on left front
wheel speed sensor and
supply line
Magnetic pulse wheel
damaged/contaminated,
de-magnetised
Sensor internal fault
Check the correct wheels and tyres are installed.
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, or ground. Check for EMC influences on the
speed sensor and circuits. Check magnetic pulse
wheel for damage/contamination and
de-magnetisation. Repair Wiring harness, install a
new sensor or wheel bearing as required. Refer to
the Warranty Policy and Procedures manual if a
module/component is suspect C0032-11
Left Front wheel
Speed Sensor
Supply - Circuit
short to ground
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground.
Repair harness as required. If no harness fault
found, suspect wheel speed sensor. Refer to the
Warranty Policy and Procedures manual if a
module/component is suspect

DTC Description Possible Causes Action C0033-38
Right Front Tone
Wheel - Signal
frequency incorrect
Right front magnetic pulse
ring damaged/contaminated
Incorrect component
installed
Sensor internal fault
Check the right front magnetic pulse ring for
damage or contamination. Clean or replace as
required. If no damage/contamination found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph for more than 10 seconds C0034-12
Right Front Wheel
Speed Sensor -
Short to battery
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to power. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect C0034-14
Right Front Wheel
Speed Sensor -
Circuit short to
ground or open
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground or
open circuit. Repair harness as required. If no
harness fault found, suspect wheel speed sensor.
Refer to the Warranty Policy and Procedures manual
if a module/component is suspect C0034-25
Right Front Wheel
Speed Sensor -
Signal
shape/waveform
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for partial or
intermittently grounded signal circuit. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph C0034-2F
Right Front Wheel
Speed Sensor -
Signal erratic
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph C0034-31
Right Front Wheel
Speed Sensor - No
signal
Electrical wiring harness
fault
Magnetic pulse ring
de-magnetised or damaged
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for open circuit or high
resistance. Check connectors for damage or
corrosion. Check the wheel speed sensor for correct
location and contamination. Check the magnetic
pulse wheel for contamination, damage or
de-magnetisation. Clean or replace the sensor or
wheel bearing as required. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph C0034-62
Right Front Wheel
Speed Sensor -
Signal compare
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph C0034-64
Right Front Wheel
Speed Sensor -
Signal plausibility
failure
Incorrect wheels/tyres
installed
Electrical wiring harness
fault
EMC influences on right front
Check the correct wheels and tyres are installed.
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, or ground. Check for EMC influences on the
speed sensor and circuits. Check magnetic pulse

DTC Description Possible Causes Action wheel speed sensor and
supply line
Magnetic pulse wheel
damaged/contaminated,
de-magnetised
Sensor internal fault wheel for damage/contamination and
de-magnetisation. Repair wiring harness, install a
new sensor or wheel bearing as required. Refer to
the Warranty Policy and Procedures manual if a
module/component is suspect C0035-11
Right Front Wheel
Speed Sensor
Supply - Circuit
short to ground
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground.
Repair harness as required. If no harness fault
found, suspect wheel speed sensor. Refer to the
Warranty Policy and Procedures manual if a
module/component is suspect C0036-38
Left Rear Tone
Wheel - Signal
frequency incorrect
Left rear magnetic pulse ring
damaged/contaminated
Incorrect component
installed
Sensor internal fault
Check the left rear magnetic pulse ring for damage
or contamination. Clean or replace as required. If no
damage/contamination found, suspect wheel speed
sensor. Refer to the Warranty Policy and Procedures
manual if a module/component is suspect. To
validate the repair and extinguish the lamps, the
vehicle needs to be driven above 9mph/15kph for
more than 10 seconds C0037-12
Left Rear Wheel
Speed Sensor -
Short to battery
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to power. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect C0037-14
Left Rear Wheel
Speed Sensor -
Circuit short to
ground or open
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground or
open circuit. Repair harness as required. If no
harness fault found, suspect wheel speed sensor.
Refer to the Warranty Policy and Procedures manual
if a module/component is suspect C0037-25
Left Rear Wheel
Speed Sensor -
Signal
shape/waveform
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for partial or
intermittently grounded signal circuit. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph C0037-2F
Left Rear Wheel
Speed Sensor -
Signal erratic
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph C0037-31
Left Rear Wheel
Speed Sensor - No
signal
Electrical wiring harness
fault
Magnetic pulse ring
de-magnetised or damaged
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for open circuit or high
resistance. Check connectors for damage or
corrosion. Check the wheel speed sensor for correct
location and contamination. Check the magnetic
pulse wheel for contamination, damage or
de-magnetisation. Clean or replace the sensor or
wheel bearing as required. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph

DTC Description Possible Causes Action C0037-62
Left Rear Wheel
Speed Sensor -
Signal compare
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph C0037-64
Left Rear Wheel
Speed Sensor -
Signal plausibility
failure
Incorrect wheels/tyres
installed
Electrical wiring harness
fault
EMC influences on left rear
wheel speed sensor and
supply line
Magnetic pulse wheel
damaged/contaminated,
de-magnetised
Sensor internal fault
Check the correct wheels and tyres are installed.
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, or ground. Check for EMC influences on the
speed sensor and circuits. Check magnetic pulse
wheel for damage/contamination and
de-magnetisation. Repair Wiring harness, install a
new sensor or wheel bearing as required. Refer to
the Warranty Policy and Procedures manual if a
module/component is suspect C0038-11
Left Rear Wheel
Speed Sensor
Supply - Circuit
short to ground
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground.
Repair harness as required. If no harness fault
found, suspect wheel speed sensor. Refer to the
Warranty Policy and Procedures manual if a
module/component is suspect C0039-38
Right Rear Tone
Wheel - Signal
frequency incorrect
Right rear magnetic pulse
ring damaged/contaminated
Incorrect component
installed
Sensor internal fault
Check the right rear magnetic pulse ring for damage
or contamination. Clean or replace as required. . If
no damage/contamination found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph for more than 10 seconds C003A-12
Right Rear Wheel
Speed Sensor -
Short to battery
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to power. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect C003A-14
Right Rear Wheel
Speed Sensor -
Circuit short to
ground or open
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to ground or
open circuit. Repair harness as required. If no
harness fault found, suspect wheel speed sensor.
Refer to the Warranty Policy and Procedures manual
if a module/component is suspect C003A-25
Right Rear Wheel
Speed Sensor -
Signal
shape/waveform
failure
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for partial or
intermittently grounded signal circuit. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a
module/component is suspect. To validate the repair
and extinguish the lamps, the vehicle needs to be
driven above 9mph/15kph C003A-2F
Right Rear Wheel
Speed Sensor -
Signal erratic
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for intermittent short to
power, ground or open circuit. Repair harness as
required. If no harness fault found, suspect wheel
speed sensor. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect. To validate the repair and extinguish the
lamps, the vehicle needs to be driven above
9mph/15kph

DTC Description Possible Causes Action error following
re-programming
Noise/EMC related error network for interference/EMC related issues B1009-63 Ignition Authorisation
- Circuit/component
protection time-out
CJB fault
Low speed CAN fault
Instrument cluster fault
Low battery voltage <9V
Check Power and Ground supplies to CJB and
instrument cluster. Check CAN communications
between CJB and instrument cluster. Check
battery is in fully charged and serviceable
condition, refer to the battery care manual B1009-64 Ignition Authorisation
- Signal plausibility
failure
CJB fault
Low speed CAN fault
Instrument cluster fault
Check power and ground supplies to CJB and
instrument cluster. Check CAN communications
between CJB and instrument cluster B102B-67
Passive Key - Signal
incorrect after event
CJB fault
Low speed CAN fault
Remote Keyless Entry (RKE)
module fault
Write target SID
synchronisation error
following re-programming
Check power and ground supplies to CJB and RKE
module. Check CAN communications between CJB
and RKE module. Re-synchronise ID by
re-configuring the RKE module as a new module B102B-87
Passive Key - Missing
message
CJB fault
Low speed CAN fault
RKE module fault
Key fob battery low/battery
contact issue
Interference from other RF
signal
EMC/noise
Receiver fault
Receiver not programmed
correctly
Serial communications fault
(between receiver and RKE
module)
Key fault
Passive antenna fault
Confirm placement of key
within vehicle
Check power and ground supplies to CJB, RKE
module and receiver. Check CAN communications
between CJB and instrument cluster. Check key
fob battery. Confirm vehicle surroundings, move
vehicle. Check CAN network for interference/EMC
related issues. Disconnect battery, then
re-connect - confirm operation by re-programming
keys. Check serial circuit between receiver and
RKE module. Confirm spare key works. Refer to
the electrical circuit diagrams and test circuits to
all 3 antennas. Check whereabouts of key B1084-13
Boot/Trunk Motor
Close Switch - Circuit
open
Trunk latch open signal
circuit - open circuit
Refer to the electrical circuit diagrams and check
trunk latch open signal circuit for open circuit B1087-83
LIN Bus "A" - Value of
signal protection
calculation incorrect
Checksum of the received
LIN frame from battery
backed sounder, roof header
console, and/or rain/light
sensor is incorrect
Check operation of rain/light sensor by covering
sensor or applying water to screen, install a new
sensor as required B1087-88 LIN Bus "A" - Bus off
Bus off. Battery backed
sounder, roof header
console, and/or rain/light
sensor LIN circuit - short to
ground, power
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check battery backed sounder, roof header
console, and rain/light sensor LIN circuit for short
to ground, power B108A-11
Start Button - Circuit
short to ground
Start/Stop switch analogue
input circuits 1 or 2 - short
to ground
Refer to the electrical circuit diagrams and check
Start/Stop switch analogue input circuits 1 and 2
for short to ground B108A-12
Start Button - Circuit
short to battery
Start/Stop switch analogue
input circuits 1 or 2 - short
to power
Refer to the electrical circuit diagrams and check
Start/Stop switch analogue input circuits 1 and 2
for short to power B1095-12
Wiper On/Off Relay -
Circuit short to battery
Wiper On/Off relay control
circuit - short to power
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check wiper On/Off relay control circuit for www.JagDocs.com

DTC Description Possible Causes Action short to power B1095-14
Wiper On/Off Relay -
Circuit short to ground
or open
Wiper On/Off relay control
circuit - short to ground,
open circuit
Refer to the electrical circuit diagrams and check
wiper On/Off relay control circuit for short to
ground, open circuit B1096-12 Wiper High/Low Relay
- Circuit short to
battery
Wiper Fast/Slow relay
control circuit - short to
power
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check wiper Fast/Slow relay control circuit for
short to power B1096-14 Wiper High/Low Relay
- Circuit short to
ground or open
Wiper Fast/Slow relay
control circuit - short to
ground, open circuit
Refer to the electrical circuit diagrams and check
wiper Fast/Slow relay control circuit for short to
ground, open circuit B1097-12
Heated Windshield
Relay - Circuit short to
battery
Heated windshield relay
control circuit - short to
power
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check heated windshield relay control circuit
for short to power B1097-14
Heated Windshield
Relay - Circuit short to
ground or open
Heated windshield relay
control circuit - short to
ground, open circuit
Refer to the electrical circuit diagrams and check
heated windshield relay control circuit for short to
ground, open circuit B10A6-12
Main Light Switch -
Circuit short to battery
Master light switch signal
from roof header console
circuit - short to power
Refer to the electrical circuit diagrams and check
master light switch signal from roof header
console circuit for short to power B10A6-23
Main Light Switch -
Signal stuck low
Master light switch signal
from roof header console
signal stuck low. Switch is
read as ON for too long a
time
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check master light switch signal from roof
header console for short to ground B10AD-09
Rain Sensor -
Component failures
Component failures
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Suspect the rain/light sensor, check and
install a new sensor as required B10AD-11
Rain Sensor - Circuit
short to ground
Rain/light sensor power
circuit - short to ground
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check rain/light sensor power circuit for short
to ground B10AD-96
Rain Sensor -
Component internal
failure
Component internal failure
Suspect the rain/light sensor, check and install a
new sensor as required B10E5-11
PCM Wake-up Signal -
Circuit short to ground
ECM wake-up signal circuit -
short to ground
Refer to the electrical circuit diagrams and check
ECM wake-up signal circuit for short to ground B10E5-12
PCM Wake-up Signal -
Circuit short to battery
ECM wake-up signal circuit -
short to power
Refer to the electrical circuit diagrams and check
ECM wake-up signal circuit for short to power B10E5-13
PCM Wake-up Signal -
Circuit open
ECM wake-up signal circuit -
open circuit
Refer to the electrical circuit diagrams and check
ECM wake-up signal circuit for open circuit B10F1-11
Key In Switch - Circuit
short to ground
Keyless vehicle module, key
IN status circuit - short to
ground
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check keyless vehicle module, key IN status
circuit for short to ground
