2010 HONDA PILOT third row

CONT INUED
Position the lap part of the belt as
low as possible across your hips,
then pull up on the shoulder part of
thebeltsothelappartfitssnugly.
This lets your strong pelvic bones
take the force of a crash and reduces
the chance of internal injuries.
Insert the latch plate into the buckle,
then tug on the belt to make sure the
belt is securely latched. Check that
the belt is not twisted, because a
twisted belt can cause serious
injuries in a crash.
Properly adjusted head restraints
will help protect occupants f rom
whiplash and other crash injuries.
See page f or how to adjust the
head restraints and how the driver’s
and f ront passenger’s active head
restraints work.
The center seating position in the
second row and all third row seats
have a detachable seat belt that can
be unlatched and retracted into the
ceiling to allow the seats to be f olded
down. See page f or how to
unlatch and relatch a belt.
Detachable seat belts should
normally be latched whenever the
seat-backs are in an upright position.
See page f or how to unlatch a
belt, and page f or how to relatch
abelt.
157
162
162
163
Protecting A dults and Teens
Fasten and Position the Seat
Belts
5.
Driver and Passenger Saf ety
17
Improperly positioning head
restraints reduces their
effectiveness and you can be
seriously injured in a crash.
Make sure head restraints are
in place and positioned properly
before driving.
——
y

y
(/
yy
2010 Pilot

For added protection, the f ront seat
belts are equipped with automatic
seat belt tensioners. When activated,
the tensioners immediately tighten
the belts to help hold the driver and
a f ront passenger in position.
The tensioners are designed to
activate in any collision severe
enough to cause the f ront airbags to
deploy, or if a sensor detects your
vehicle is about to roll over (see page
).
The tensioners can also be activated
during a collision in which the f ront
airbags. In this case, the
airbags would not be needed, but the
extra tension in the seat belt could
be helpf ul.
If a side curtain airbag deploys
during a side impact, the tensioner
on that side of the vehicle will also
deploy.
The lap/shoulder belts in the center
seat of the second row and both of
the third row seats are equipped with
a detachable anchor that has two
parts: a small latch plate and a
buckle.
The detachable seat belt should
normally be latched whenever the
seat-backs are in an upright position.
For more inf ormation about the
detachable seat belt, see page .
When the tensioners are activated,
the seat belts will remain tight until
they are unbuckled.
162
34
do not deploy
A utomatic Seat Belt T ensioners
Additional Inf ormation About Your Seat Belts
24
DETACHABLE ANCHOR
——
y
y
(/
yy
2010 Pilot

CONT INUED
To install a LATCH-compatible child
seat in either outer second row seat:
Move the seat belt buckle or
tongue away f rom the lower
anchors.
Make sure there are no objects
near the anchors that could
prevent a secure connection
between the child seat and the
anchors.
Your vehicle is equipped with
LATCH (Lower Anchors and
Tethers f or CHildren) at each of the
second row seats and the passenger’s
side third row seat.
When you install a child seat in the
second row seating position, use the
loweranchorsasshowninthe
illustration. You can install up to
three child seats at a time with
LATCH.
Do not attach two child seat
connectors to a single lower anchor
at a time.
You can f ind lower anchors in the
slits in the seat-backs.
The lower anchors are located
between the seat-back and seat
bottom, and are to be used only with
a child seat designed f or use with
LATCH.
The location of each lower anchor is
indicated by a small button above the
anchor point.
1.
2.
Installing a Child Seat with
LATCH
Installing a Child Seat
Using t he Out er L A T CH
Driver and Passenger Saf ety
49
LOWER ANCHORS
MARKS
——
y

y
(/
yy
2010 Pilot

The location of each lower anchor is
indicated by a small button above the
anchor point.
To install a LATCH-compatible child
seat in the passenger’s side seating
position of the third row:
Unlatch the detachable seat belt
anchor latch and retract the seat
belt all the way into the passenger’s
side panel. Place the latch plate
and anchor latch in their holding
slots (see page ).
Followsteps1through4of the
second row installation on pages
and .
You can f ind lower anchors in the
slits in the seat-backs.
Lower the head restraint f irst.
Route the tether strap over the
head restraint and seat-back, then
attach the tether strap hook to the
anchor, making sure the strap is
not twisted.
Push and pull the child seat
f orward and f rom side-to-side to
verify that it is secure.
1.
2.
3.
4.
163
4950
Installing a Child Seat
52
LOWER ANCHORS
——
y
y
(/
yy
2010 Pilot

When not using the LATCH system,
all child seats must be secured to the
vehicle with the lap part of a lap/
shoulder belt.
With the child seat in the desired
seating position, route the belt
through the child seat according
to the seat maker’s instructions,
then insert the latch plate into the
buckle and remove any slack f rom
the lap portion of the belt.
To activate the lockable retractor,
slowly pull the shoulder part of the
belt all the way out until it stops,
then let the belt f eed back into the
retractor.
Af ter the belt has retracted, tug on
it. If the belt is locked, you will not
be able to pull it out. If you can pull
thebeltout,itisnotlocked,and
you will need to repeat these steps.
In addition, the lap/shoulder belts in
all seating positions except the
driver’s have a lockable retractor
that must be activated to secure a
child seat.
If you intend to install a child seat in
the center seating position of the
secondroworinthethirdrow,make
sure the detachable seat belt is
securely latched (see page ).
1.2.
3.
163
CONT INUED
Installing a Child Seat with a L ap/
Shoulder Belt
Installing a Child Seat
Driver and Passenger Saf ety
53
——
y
y
(/
yy
2010 Pilot

Push and pull the child seat
f orward and f rom side-to-side to
verify that it is secure enough to
stay upright during normal driving
maneuvers. If the child seat is not
secure, unlatch the belt, allow it to
retract f ully, then repeat these
steps.
A child seat with a tether can be
installed in any seating position in
the second or third row.
To deactivate the lockable retractor
and remove a child seat, unlatch the
buckle, unroute the seat belt, and let
the belt fully retract.
Since a tether can provide additional
security to the lap/shoulder belt
installation, we recommend using a
tether whenever one is required or
available.
Af ter conf irming that the belt is
locked, grab the shoulder part of
the belt near the buckle, and pull
up to remove any slack from the
lap part of the belt. Remember, if
the lap part of the belt is not tight,
the child seat will not be secure.
To remove slack, it may help to
putweightonthechildseat,or
push on the back of the seat while
pulling up on the belt.
4.5.
Installing a Child Seat with a
Tether
Installing a Child Seat
54
——
y
y
(/
yy
2010 Pilot

Route the tether strap over the
head restraint, then attach the
tether strap hook to the anchor,
making sure the strap is not
twisted.Tighten the strap according to the
seat maker’s instructions.
Attach the tether strap hook to the
anchor, making sure the tether
strap is not twisted.
Tighten the strap according to the
seat maker’s instructions.
Each third row seat has a tether
anchorage point behind the seat-
back.
Af ter properly securing the child
seat (see page ), lower the head
restraint.
1.
2.
3.
2.
3.
53
T hird Row Inst allat ion
Installing a Child Seat
56
——
y
y
(/
y
y
2010 Pilot

The driver’s and f ront passenger’s
seats have active head restraints. If
the vehicle is struck severely f rom
the rear, the occupant properly
secured with the seat belt will be
pushed against the seat-back and the
head restraint will automatically
move forward.
To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button,
then pull the restraint out of the seat-
back.
When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
Make sure the head restraint locks
in position when you reinstall it.
Seats
A ct ive Head Rest raint s
Removing t he Head Rest raint
158
SECOND CENTER AND THIRD ROW
CUSHION
RELEASE BUTTONLEGS
Failure to reinstall the head
restraints can result in severe
injury during a crash.
Always replace the head
restraints before driving.
——
y
y
(/
y
y
2010 Pilot
