2010 HONDA ODYSSEY jump start

(f luid capacities and tire pressures)
(main controls)
(seat belts, SRS, and child protection)
(indicators, gauges, dashboard, and steering column)
(climate control, audio, steering wheel, rear entertainment, security, cruise control, and HomeLink
)
(fuel, vehicle break-in, and cargo loading)
(engine and transmission operation) (minder, f luid checking, minor services, and vehicle storage)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
(f lat tire, jump starting, overheating, and f uses)
Contents
........................................................................\
........................................................................
Index .I
Service Inf ormation Summary ........................................................................\
.......................
Your Vehicle at a Glance .3
............................................................
Driver and Passenger Saf ety .5
..........................................
Instruments and Controls .63
..
Features .209
.......................................................................
Bef ore Driving .367
........................................................................\
.................
Driving .383
.................................................
Maintenance .413
..............................................
T echnical Inf ormation .489
..................
Warranty and Customer Relations (U.S. and Canada only) .507
........................................................................\
..........
A uthorized Manuals (U.S. only) .511
........................................
T aking Care of the Unexpected .461
1
——
y
y
(yy
Owner's Identification Form
00X31-SHJ-6500
\251 2009 American Honda Motor Co., Inc. - All Rights Reserved
2010 Odyssey Online Reference Owner's Manual
2010 Odyssey

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .462
....................
Changing a Flat Tire .463
.............
If the Engine Won’t Start . 471
................................
Jump Starting .473
..............
If the Engine Overheats . 475
.........
Low Oil Pressure Indicator . 477
..........
Charging System Indicator . 477
.......
Malf unction Indicator Lamp . 478
...........................
Readiness Codes .478
...............
Brake System Indicator . 479
..............................................
Fuses .480
..............................
Fuse Locations .483
......................
Emergency Towing .486
Taking Care of the Unexpected
T aking Care of t he Unexpect ed
461
——
y


y
(yy
2010 Odyssey

Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly. Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit f or the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See
on page .
If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of the
battery and terminal connections
(see page ). You can then try
jump starting the vehicle from a
booster battery (see page ).
When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all.
Check these things:
Check the transmission interlock.
The transmission must be in Park
or neutral or the starter will not
operate.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See on page . 458
473 486
473
Emergency T owing
Nothing Happens or the Starter
Motor Operates Very Slowly
Jump Starting
If theEngineWon’tStart
T aking Care of t he Unexpect ed
471
——
y

y
(yy
2010 Odyssey

CONT INUED
Although this seems like a simple
procedure, you should take several
precautions.
You cannot start your vehicle by
pushing or pulling it.The numbers in the illustration
show you the order to connect the
jumper cables.
Open the hood, and check the
physical condition of the battery.
In very cold weather, check the
condition of the electrolyte. If it
seems slushy or f rozen, do not try
jump starting until it thaws.
Turn of f all the electrical
accessories: heater, A/C, climate
control, audio system, lights, etc.
Put the transmission in neutral or
Park, and set the parking brake.
1.
2.To Jump Start Your Vehicle:
Jump Starting
T aking Care of t he Unexpect ed
473
BOOSTER
BATTERY
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone
nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.
If a battery sits in extreme cold, the
electrolyte inside can f reeze.
Attempting to jump start with a f rozen
battery can cause it to rupture.
——
y
y
(yy
2010 Odyssey

µ
´
´ If the booster battery is in another
vehicle, have an assistant start
that vehicle and run it at a fast idle.
Start the vehicle. If the starter
motor still operates slowly, check
that the jumper cables have good
metal-to-metal contact.
Once the vehicle is running,
disconnect the negative cable f rom
your vehicle, then f rom the
booster battery. Disconnect the
positive cable f rom your vehicle,
and then from the booster battery.
Keep the ends of the jumper cables
away from each other and any metal
on the vehicle until everything is
disconnected. Otherwise, you may
cause an electrical short.
Connect the second jumper cable
to the negative ( ) terminal on
the booster battery. Connect the
other end to the grounding strap
as shown. Do not connect this
jumper cable to any other part of
the engine.
Connect one jumper cable to the
positive ( ) terminal on your
vehicle’s battery. Connect the
other end to the positive ( )
terminal on the booster battery.
4. 6.
7. 5.
3.
Jump Starting
474
——
y

y
(yy
2010 Odyssey

CONT INUED
BatteryCharging System ...........................
Indicator .67, 477
............................
Jump Starting .473
..............................
Maintenance .458
............................
Specif ications .492
..............................
Bef ore Driving .367
....................................
Belts,Seat .8,21
.........................
Beverage Holders .195
........
HandsFreeLink. 325
..................................
Booster Seats .57
Brakes ...........
Anti-lock System (ABS) . 392 .............
Break-in, New Linings . 368
............
Bulb Replacement . 441,443
...........................................
Fluid .435
.................
Pad Wear Indicators . 391
.......................................
Parking .192
.................
System Indicator . 69,479
.............................
Braking System .391
.................
Break-in, New Vehicle . 368
Brightness Control, ...............................
Instruments .139
Bulb Replacement ..........................
Back-up Lights .442
..............................
Brake Lights .443
................
Front Parking Lights . 439
........
Front Side Marker Lights . 439
...........
Front Turn Signal Light . 438
.................................
Headlights .437
.........................
Rear Bulbs .441, 442
............
Rear Turn Signal Light . 441
............................
Specif ications .493
..............................
Bulbs, Halogen .437
....................................
Accessories .376
ACCESSORY (Ignition Key .....................................
Position) .144
.............
Accessory Power Socket . 203
...........................
AC Power Outlet .203
....................
Additives, Engine Oil . 427
...............
AdvancedAirbagSystem . 30
...............................
Airbag (SRS) .9, 25
..............
Air Conditioning System . 210
.....................
Rear A/C Control .216
...............
Air Outlets (Vents) . 213,220
.......................
Air Pressure, Tires .451
......................................
Antif reeze .430
Anti-lock Brakes (ABS) ...............................
Indicator .69, 392
...................................
Operation .392
..............
Anti-thef t, Audio System . 284
Anti-thef t Steering Column ............................................
Lock .144
........................................
Armrests .171
...............
Audio Controls, Remote . 282
................................
Audio System .221
...
Automatic Seat Belt Tensioners . 23
.
Automatic Lighting Off Feature . 138.............
Automatic Speed Control . 319
..............
Automatic Transmission . 386
..........................
Capacity, Fluid .492
...............
Checking Fluid Level . 433
.......................................
Shif ting .386
Shif t Lever Position ...............................
Indicators .386
................
Shif t Lever Positions . 387
....................
Shif t Lock Release . 389
......................
Auxiliary Input Jack .283Bluetooth
Index
A
B
INDEX
I
——
y
y
(y
y
2010 Odyssey

CONT INUED
Disc Brake Pad Wear...................................
Indicators .391
.....................
Disposal of Used Oil .429
Doors Auto Door Locking/ ..............................
Unlocking .152
............
Locking and Unlocking . 151
..................
Lockout Prevention . 151
..............
Manual Sliding Doors . 161
........................
Open monitor .75, 92
....................
Power Door Locks . 151
.................
Power Sliding Doors . 161
..........
DOT Tire Quality Grading . 494
...........
Driver and Passenger Safety . 5
...........................................
Driving .383
....................................
Economy .373
Driving Position Memory ........................................
System .184
..................
Dust and Pollen Filter . 444
....................
DVD Error Message .314
...................................
DVD Player .285
..............................
Economy, Fuel .373 ..................................
Emergencies .461
.............
Battery, Jump Starting . 473
...........
Brake System Indicator . 479
................
Changing a Flat Tire . 463
.....
Charging System Indicator . 477
..................
Checking the Fuses . 481
...........
Driving with a Flat Tire . 463
.......
Hazard Warning Flashers . 140
............................
Jump Starting .473
.....
Low Oil Pressure Indicator . 477
...
Malf unction Indicator Lamp . 478
..................
Overheated Engine . 475
.......................................
Towing .486
.........................
Emergency Brake .192
....................
Emergency Flashers .140
......................
Emergency Towing .486
.......................
Emissions Controls .501
.............
Emissions Testing, State . 504
Engine ....
Coolant Temperature Gauge . 77
..............
Engine Speed Limiter . 388
.........................
If It Won’t Start .471
Malf unction Indicator ................................
Lamp .67, 478
........
Oil Pressure Indicator . 67,477
..............
Oil, What Kind to Use . 426...............................
Overheating .475
............................
Specif ications .492
.......................................
Starting .385
.
Evaporative Emissions Controls . 501
...............................
Exhaust Fumes .60
Exhaust Gas Recirculation ........................................
System .502
Expectant Mothers, Use of Seat ........................................
Belts by .19
...................................
Fan, Interior .211
.........................................
Features .209
....................
Filling the Fuel Tank . 369
Filters ..............
Dust and Pollen Filter . 444
...............................................
Oil .428
...........
Flashers, Hazard Warning . 140
...................
Flat Tire, Changing a . 463
.............................
Floor Mats .176, 444
.......................
Floor Storage Area .200
Index
E FINDEX
III
——
y
y
(yy
2010 Odyssey

CONT INUED
................................................
Keys .142
.................
Jacking up the Vehicle . 465
.......................................
Jack, Tire .464
................................
Jump Starting .473
.........
Important Safety Precautions . 6
...................................
Indicators .65, 66
......
ABS (Anti-lock Brake) . 69,392
Brake (Parking and Brake ...........................
System) .69, 479
................
Charging System . 67,477
.............................
Cruise Control .75
DRL (Daytime Running .....................................
Lights) .73
Indicators .....................................
Fog Light .73
.............................
Fuel Economy .75
...................................
High Beam .73
.......
Key (Immobilizer System) . 70
.....................................
Lights On .73
......................................
Low Fuel .74
................
Low Oil Pressure . 67,477
......
Low Tire Pressure . 71,396, 399
..................
Maintenance Minder . 76
.....................
Side Airbag Of f .35, 68
.........................................
SRS .34, 67
.........................
System Message .76
...........................
TPMS .72, 397, 400
Turn Signal and Hazard ...................................
Warning .72 Vehicle Stability Assist
...............
(VSA
) System . 70,394
............................
VSA Activation .70
..............................
Washer Level .74
..................
Individual Map Lights . 206
...............................
Inf ant Restraint .43
......................................
Inf ant Seats .43
......
LATCH Anchorage System . 48
...........................
Lower Anchors .48
..........
Tether Anchorage Points . 54
...................
Inf lation, Proper Tire . 451
...................
In-Floor Storage Area . 200
.................................
Inside Mirror .190
.............................
Inspection, Tire .452
......................
Instrument Panel .4, 133
......
Instrument Panel Brightness . 139
....................
Integrated Sunshade .197
...............................
Interior Lights .205
........................................
Introduction .i .......................
Label, Certif ication .490
...............
Lane Change, Signaling . 136
..................
Lap/Shoulder Belts . 15,22
...........
LATCH Anchorage System . 48
....................
Light Control Switch .205
Lights ....................
Bulb Replacement .437
.......................................
Indicator .73
.......................................
Interior .205
.......................................
Parking .135
................................
Turn Signal .136
............................
Load Limits .379, 404
....
LOCK (Ignition Key Position) . 144
Index
J K
L
INDEX
V
——
y
y
(yy
2010 Odyssey
