2010 HONDA CIVIC HYBRID heating

(seat belts, SRS, and child protection)(f luid capacities and tire pressures)
(main controls)
(indicators, gauges, dashboard, and steering column)
(climate control, audio, steering wheel, security, and cruise control ) (fuel, vehicle break-in, and cargo loading)
(engine and transmission operation) (minder, f luid checking, minor services, and vehicle storage) (f lat tire, jump starting, overheating, and f uses)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
Contents
............................................................
Driver and Passenger Saf ety .5
........................................................................\
........................................................................
Index .I
Service Inf ormation Summary ........................................................................\
.......................
Your Vehicle at a Glance .3
..........................................
Instruments and Controls .55
.............................................
Features .103
.......................................................................
Bef ore Driving .241
........................................................................\
.................
Driving .257
.................................................
Maintenance .275
........................................
T aking Care of the Unexpected .311
..............................................
T echnical Inf ormation .335
..................
Warranty and Customer Relations (U.S. and Canada only) .351
........................................................................\
..........
A uthorized Manuals (U.S. only) .355
1
09/07/15 10:29:34 31SNC640_006
Owner's Identification Form
00X31-SNC-6400
\251 2009 American Honda Motor Co., Inc. - All Rights Reserved
2010 Civic Hybrid
2010 Civic Hybrid Online Reference Owner's Manual

Your vehicle’s exhaust contains
carbon monoxide gas. Carbon
monoxide should not enter the
vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.If you must sit in your parked vehicle
with the engine running, even in an
unconf ined area, adjust the heating
and cooling system as f ollows:
The vehicle is raised f or an oil
change.
Have the exhaust system inspected
f or leaks whenever:
You notice a change in the sound
of the exhaust. Select the f resh air mode.
Select the mode.
Set the f an speed to high.
Set the temperature control to a
comfortable setting.
With the trunk open, airf low can pull
exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
trunk open, open all the windows and
set the climate control system as
shown below.
The vehicle was in a crash that
may have damaged the underside. 1.
2.
3.
4.
Carbon Monoxide Hazard
52
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
09/07/15 10:36:29 31SNC640_057
2010 Civic Hybrid

If you turn the steering wheel to the
f ull lef t or right position repeatedly
while stopping or driving at very low
speed, you may f eel slightly harder
steering due to overheating of the
steering gearbox.For more inf ormation, see page .
Continuously driving under those
conditions could damage the power
steering system.
This indicator normally comes on
when you turn the ignition switch to
the ON (II) position and goes of f
af ter the engine starts. If it comes on
at any other time, there is a problem
in the electric power steering system.
If this happens, stop the vehicle in a
saf e place, and turn of f the engine.
Reset the system by restarting the
engine. The indicator will not turn
of f immediately. If it does not go of f
after driving a short distance, or
comes back on again while driving,
take the vehicle to your dealer to
have it checked. With the indicator
on, the EPS may be of f , making the
vehicle harder to steer. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. When the brake system
indicator (amber) is on, there is a
problem with the Cooperative
Control with Regenerative Brake,
Creep Aid System or Brake Assist
(the normal brake operates properly).
Have your vehicle checked by your
dealer.
326
Electric Power Steering
(EPS) Indicator
Brake System
Indicator
(A mber)
Instrument Panel Indicators
Inst rument s and Cont rols
63
U.S. Canada
09/07/15 10:38:19 31SNC640_068
2010 Civic Hybrid

Only on models equipped withNavigation SystemYou can manually select various
f unctions of the climate control
system when it is in f ull automatic
mode. All other f eatures remain
automatically controlled.
Making any manual selection causes
thewordAUTOinthedisplaytogo
out.
Turn this dial to increase or decrease
the fan speed and airflow.
Turning this dial clockwise increases
the temperature of the airflow.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you set the temperature to its
lower limit ( ) or its upper limit
( ), the system runs at f ull
cooling or heating only. It does not
regulate the interior temperature.
In cold weather, the fan will not
come on automatically until the
heater starts to develop warm air.
In ‘‘AUTO’’ mode, the air conditioner
may not work if the humidity inside
the vehicle is low. To activate the air
conditioner, press A/C button.
The climate control system f or your
vehicle can also be operated using
the voice control system. See the
navigation system manual f or
complete details.
The automatic climate control
system adjusts the f an speed and
airflow levels to maintain the interior
temperature you select.
Press the AUTO button.
Set the desired temperature by
turning the temperature control
dial. You will see AUTO in the
system’s display.
Voice Control System
Semi-automatic Operation
Fan Control Dial
T emperature Control Dial
Using A utomatic Climate Control
Climat e Cont rol
Features
105
09/07/15 10:43:47 31SNC640_110
2010 Civic Hybrid

Airf low is divided between
the f loor vents and def roster vents at
the base of the windshield.
Air f lows f rom the def roster
vents at the base of the windshield.
When you select , the system
automatically switches to fresh air
mode and turns on the A/C.
In AUTO mode, the system controls
the airf low direction automatically
between the dashboard vents and
the f loor vents.
This button turns the air
conditioning on and of f . The
indicatorinthebuttonisonwhen
the A/C is on.
When the recirculation indicator is
on, air f rom the vehicle’s interior is
sent throughout the system again.
Select recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
When the f resh air indicator is on,
air is brought in f rom the outside of
the vehicle. Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Use the mode control buttons to
select the vents air flows from. Some
air will f low f rom the dashboard
corner vents in all modes.
Air flows from the center
and corner vents in the dashboard.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents. When you select , the
system automatically switches to
f resh air mode.
Air Conditioning (A/C) Button
Recirculation Button
Fresh Air Button
Mode Control Button
Climat e Cont rol
106
09/07/15 10:44:01 31SNC640_111
2010 Civic Hybrid

This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the heating and
cooling system/climate control
system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the
inf ormation display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the f low f rom
the heating and cooling system
becomeslessthanusual.Check the condition of the wiper
blades at least every 6 months.
Replace them if you f ind signs of
cracking in the rubber, and areas
that are getting hard or if they leave
streaks and unwiped areas when
used.
To replace a wiper blade:Raise each wiper arm off the
windshield, lif ting the driver’s side
first, then the passenger’s side.
1.
Dust and Pollen Filter, Wiper Blades
Dust and Pollen Filter
Wiper Blades
300
WIPER ARMS
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.
09/07/15 11:10:32 31SNC640_305
2010 Civic Hybrid

Î
CONT INUED
........
DOT Tire Quality Grading . 340
...........
Driver and Passenger Safety . 5
...........................................
Driving .257
....................................
Economy .247
..................
Dust and Pollen Filter . 300
..............................
Economy, Fuel .247
............
Emergencies on the Road . 311
.............
Battery, Jump Starting . 319
...........
Brake System Indicator . 326
................
Changing a Flat Tire . 313
.....
Charging System Indicator . 324
..................
Checking the Fuses . 328
Low Oil Pressure ...........................
Indicator .62, 323
Malf unction Indicator ................................
Lamp .62, 325
..................
Overheated Engine . 321
...........................
Emergency Brake .99
......................
Emergency Flashers .76
......................
Emergency Towing .333
............
Emergency Trunk Opener . 88
.......................
Emissions Controls .345
........................
Emissions Testing .348 Engine
....
Coolant Temperature Gauge . 66
..............
Engine Speed Limiter . 262
Malf unction Indicator ................................
Lamp .62, 325
........
Oil Pressure Indicator . 62,323
..............
Oil, What Kind to Use . 285
...............................
Overheating .321
............................
Specif ications .338
.......................................
Starting .259
.
Evaporative Emissions Controls . 345
...............................
Exhaust Fumes .52
Expectant Mothers, Use of Seat ........................................
Belts by .17
...................................
Fan, Interior .105
.........................................
Features .103
....................
Filling the Fuel Tank . 243
Filters .........................
Dust and Pollen .300
...............................................
Oil .286
.............
Flashers, Hazard Warning . 76
...................
Flat Tire, Changing a . 313Fluids
..........
Automatic Transmission . 291
..........................................
Brake .292
..................
Windshield Washer . 290
FM Stereo Radio ...................................
Reception .204
..........................
Four-way Flashers .76
............................
Front Airbags .10, 22
.................................................
Fuel .242
......................
Fill Door and Cap .243
...........................................
Gauge .67
................
Octane Requirement . 242
...............................
Oxygenated .242
........................
Reserve Indicator .61
........................
Tank, Filling the .243
.....................
Fuses, Checking the .328
...............
Gas Mileage, Improving . 247
Index
F
E
G
INDEX
III
09/07/15 11:18:00 31SNC640_364
2010 Civic Hybrid

CONT INUED
..................................
Maintenance .275
........................................
Minder .277
.........................
Minder Indicator .61
Owner’s Maintenance ...................................
Checks .282
..........................................
Saf ety .276 .
Malf unction Indicator Lamp . 62,325
.........................
Meters, Gauges .57, 65
...................
Methanol in Gasoline . 242
..........................
Mirrors, Adjusting .98
...........................
MP3/WMA .121, 160
...................
Neutral Gear Position . 262
..................
New Vehicle Break-in . 242
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 336
...
Octane Requirement, Gasoline . 242
.........................................
Odometer .65
................................
Odometer,Trip .67
Oil ........................
Change, How to .286
......................
Change, When to .277
......................
Checking Engine .244
..............
Pressure Indicator . 62,323
.......
Selecting Proper Viscosity . 285
...........
ON (Ignition Key Position) . 80Onboard Ref ueling Vapor
....................................
Recovery .345
..............................
Outside Mirrors .98
....
Outside Temperature Indicator . 68
....................
Overheating, Engine .321
....
Owner’s Maintenance Checks . 282
.........................
Oxygenated Fuels .242
..............
Panel Brightness Control . 75
........................
Park Gear Position .262
...........................................
Parking .266
.................................
Parking Brake .99
Parking Brake and Brake .................
System Indicator . 58,326
.................................
Parking Lights .74
..
Parking Over Things that Burn . 266
.............................
PGM-FI System .346
..................
Playing the Radio . 113,148
........................
Playing a Disc .121, 160
.........................
Playing a PC Card .170
.........
Pregnancy, Using Seat Belts . 17
Lights
....................
Bulb Replacement .293
.......................................
Indicator .60
.........................................
Parking .74
..................................
Turn Signal .74
....................................
Load Limits .253
......
LOCK (Ignition Key Position) . 80
Locks .......
Anti-thef t Steering Column . 80
............................
Fuel Fill Door .243
.................................
Power Door .81
...........................................
Trunk .88
........................
Low Coolant Level .246
.........................
Low Fuel Indicator .61
................................
Lower Anchors .43
...
Low Oil Pressure Indicator . 62,323
...
Lubricant Specif ications Chart . 338
Index
M N
O
P
INDEX
V
09/07/15 11:18:13 31SNC640_366
2010 Civic Hybrid
