2010 HONDA CIVIC HYBRID light

If the ABS indicator comes on with
the brake system indicator, have
your vehicle inspected by your
dealer immediately.
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (see
on page ).
If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully.
The brake system
indicator normally
comes on when
you turn the ignition switch to the
ON (II) position and as a reminder to
check the parking brake. It will stay
on if you do not f ully release the
parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads. If the brake system indicator
(amber) comes on with the parking
brake system indicator (red) with
the parking brake released, there
may be a malfunction with the
power-assist f eature. When the
power-assist f eature malf unctions,
the brake indicator (red) comes on
and a buzzer sounds f or a second.
The power-assist f eature may stop
when the brake ef f ect is weak. Stop
your vehicle immediately at a saf e
place and contact a dealer.
292
333Emergency
Towing
Brake System Indicator
326
U.S. Canada
09/07/15 11:14:00 31SNC640_331
2010 Civic Hybrid

Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box.
If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
and , or the diagram on the
fuse box lid, which fuse or fuses
control that device. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
the cause. Replace any blown f uses,
and check if the device works.
Check each of the large f uses in
the primary under-hood f use box
by looking through the top at the
wire inside. Remove the screws
with a Phillips-head screwdriver.
1.
2. 3.
331 332
Checking and Replacing Fuses
Fuses
328
BLOWN
FUSE
BLOWN
09/07/15 11:14:13 31SNC640_333
2010 Civic Hybrid

µ
µNo.
No. Circuits Protected
No.
Circuits Protected
Circuits Protected Amps.
Amps.
Amps.
1
2
3
1
2
3 IMA2
IMA1
Booster MS
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 Headlight Main
Power Window Main
Booster Motor
Sub Fan Motor
Main Fan Motor
Rear Defogger
Blower
Hazard
FI Sub
Stop and Horn
IG Coil (EX)
IG Coil (IN)
Oil Level
Not Used
Not Used
IG Coil
FI Main
MG Clutch
DBW
Interior Light
Back Up
Main Fuse
EPS
Option Main
Ignition Switch Main
ABS Motor
ABS F/S 50 A
40 A
40 A
20 A
20 A
30 A
40 A
10 A
15 A
15 A
15 A
15 A
7.5 A
20 A
15 A
7.5 A 15 A
7.5 A 10 A 10 A
7.5 A 15 A
100 A
70 A
60 A
50 A
30 A
40 A
Fuse Locations
T aking Care of t he Unexpect ed
331
UNDER-HOOD PRIMARY FUSE BOX UNDER-HOOD SECONDARY FUSE BOX
09/07/15 11:14:32 31SNC640_336
2010 Civic Hybrid

µ
µ
µ
µ
µ
µ
µ Î
Î
Î
No. No.No.
Circuits Protected
Amps. Amps.
Amps. Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
ODS
MET ER
SRS
Right Headlight High Beam
Left Headlight High Beam
Small (Interior)
Small (Exterior)
Right Headlight Low Beam
7.5 A
7.5 A
10 A
10 A
10 A
7.5 A
7.5 A 10 A 10 A
20 A
15 A
20 A
(7.5 A)
(7.5 A)
20 A
20 A
(15 A) 15 A
20 A
20 A
20 A
7.5 A 10 A
7.5 A 30 A
7.5 A
15 A
10 A
7.5 A 15 A
7.5 A Power Window
Fuel Pump
IG1 ACG
ABS/VSA Unit
Seat Heater
Not Used
TPMS
Not Used Left Headlight Low Beam
Headlight High Main
Small (Main)
Not Used
Headlight Low Main
(HAC)
STS
Not Used
Door Lock
Driver’s Power Window
Not Used
Rear ACC Socket
ACC
Passenger’s Power Window
Not Used
Right Rear Power Window
Left Rear Power Window
Not Used
ACC, Radio
HAC
Daytime Running Light
Wiper
: Optional in U.S.
Fuse Locations
332
INTERIOR FUSE BOX
09/07/15 11:14:40 31SNC640_337
2010 Civic Hybrid

µµµµ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Specif ications
Technical Inf ormation
339
Air Conditioning
Fuses
Alignment
12 Volt Battery Tires
Lights
HFC-134a (R-134a)
14.1 15.9 oz (400 450 g) SE-10Y
12 V 60 W
12 V 3 CP 12 V 21/5 W 12 V 21 W 7°6’1°39’ 0°3’
0.00 in (0.0 mm)
P195/65R15 89S 2.0 in (2.0 mm)
Refrigerant type
Charge quantity
Lubricant oil type
Interior
Under-hood
Toe-in
Camber
Caster
12 V 12 V 51 W
12 V 21 W
12 V
12 V
12 V
12 V
5W
8W
8W
5W
Capacity 12 V 35 AH/20 HR T135/80D15 99M
32 psi (220 kPa , 2.2 kgf/cm
)
60 psi (420 kPa , 4.2 kgf/cm)
Size
Pressure
12 V 2 CP
12 V 28 AH/5 HR 24/2.2 CP
Headlights
Front turn signal/side marker
lights
Rear turn signal lights
Brake/Taillights (in fenders)
Back-up lights
Rear side marker lights
Taillights (in trunk lid)
License plate lights
Ceiling light
Spotlights
Trunk light See page
332or the fuse label
attached to the inside of the fuse
box door under the steering
column.
See page 331or the fuse box
cover.
Front
Rear
Front
Rear
Front
High
Low
(HB3)
(HB4)
Front/Rear
Spare
Front/Rear
Spare
09/07/15 11:15:43 31SNC640_344
2010 Civic Hybrid

Î
ÎThe burning of gasoline in your
vehicle’s engine produces several by-
products. Some of these are carbon
monoxide (CO), oxides of nitrogen
(NOx), and hydrocarbons (HC).
Gasoline evaporating f rom the tank
also produces hydrocarbons. Con-
trolling the production of NOx, CO,
and HC is important to the environ-
ment. Under certain conditions of
sunlight and climate, NOx and HC
react to f orm photochemical ‘‘smog.’’
Carbon monoxide does not contri-
bute to smog creation, but it is a
poisonous gas. The United States Clean Air Act
sets standards f or automobile
emissions. It also requires that
automobile manufacturers explain to
owners how their emissions controls
workandwhattodotomaintain
them. This section summarizes how
the emissions controls work.
In Canada, Honda vehicles comply
with the Canadian emission
requirements, as specif ied in an
agreement with Environment
Canada, at the time they are
manuf actured.
Your vehicle has a positive
crankcase ventilation system. This
keeps gasses that build up in the
engine’s crankcase f rom going into
the atmosphere. The positive
crankcase ventilation valve routes
them from the crankcase back to the intake manif old. They are then
drawn into the engine and burned.
As gasoline evaporates in the f uel
tank, an evaporative emissions
control canister f illed with charcoal
adsorbs the vapor. It is stored in this
canister while the engine is of f . Af ter
the engine is started and warmed up,
the vapor is drawn into the engine
and burned during driving.
The onboard ref ueling vapor
recovery (ORVR) system captures
the f uel vapors during ref ueling. The
vapors are adsorbed in a canister
f illed with activated carbon. While
driving, the f uel vapors are drawn
into the engine and burned of f .
The Clean Air Act
Crankcase Emissions Control
System
Evaporative Emissions Control
System
Onboard Ref ueling Vapor
Recovery
Emissions Cont rols
Technical Inf ormation
345
09/07/15 11:16:38 31SNC640_350
2010 Civic Hybrid

Select a nearby lightly traveled
major highway where you can
maintain a speed of 50 to 60 mph
(80to97km/h)foratleast20
minutes. Drive on the highway in
D. Do not use the cruise control.
When traffic allows, drive for 90
seconds without moving the
accelerator pedal. (Vehicle speed
may vary slightly; this is okay.) If
you cannot do this f or a
continuous 90 seconds because of
traf f ic conditions, drive f or at least
30 seconds, then repeat it two
more times (for a total of 90
seconds).Then drive in city/suburban
traffic for at least 10 minutes.
When traf f ic conditions allow, let
the vehicle coast f or several
seconds without using the
accelerator pedal or the brake
pedal.
Make sure the vehicle has been
parked with the engine of f f or 30
minutes.
If the testing f acility determines the
readiness codes are still not set, see
your dealer.
7.
8.
9.
Emissions T esting
Technical Inf ormation
349
09/07/15 11:17:07 31SNC640_354
2010 Civic Hybrid

Bulb Replacement..........................
Back-up Lights .297
.....................
Brake Lights .296, 297
........
Front Side Marker Lights . 295
...........
Front Turn Signal Light . 295
.................................
Headlights .293
..........................
Parking Lights .295
.........
Rear Side Marker Lights . 296
..........
Rear Turn Signal Lights . 296
............................
Specif ications .339
..............................
Bulbs, Halogen .293
.........................................
Card, PC .170
............................
Capacities Chart .338
.............
Carbon Monoxide Hazard . 52
.............................
Carrying Cargo .252
.............
CAUTION, Explanation of . iii
..................................
Ceiling Light .102
........................
Certif ication Label .336
............................................
Chains .308
....................
Changing a Flat Tire .313
Changing Oil ........................................
How to .286
......................................
When to .277 ...
Charging System Indicator . 62,324
..............
Check Fuel Cap Indicator . 69
............
Checklist, Bef ore Driving . 258
.....................................
Child Saf ety .34
Child Seats .............
LATCH Anchor System . 43
.............................
Lower Anchor .43
............................
Tether Anchor .47
..................
Childproof Door Locks . 82
....................
Cleaning the Wheels .303
.........................
Clock, Setting the .212
........................
CO in the Exhaust .345
............
Cold Weather, Starting in . 259
..............................
Compact Spare .312
.............
Controls, Instruments and . 55
Coolant ........................................
Adding .288
....................................
Checking .246
.........................
Proper Solution .288
...................
Temperature Gauge . 66
Crankcase Emissions Control ........................................
System .345
............
Cruise Control Operation . 214
....
Customer Service Inf ormation . 352...............
DANGER, Explanation of . iii
...................................
Dashboard .3, 56
................
Daytime Running Lights . 75
............
Def ects, Reporting Saf ety . 354
........................
Def og and Def rost .108
................
Def ogger, Rear Window . 76
..............
Def rosting the Windows . 108
....................................
Dimensions .338
...............
Dimming the Headlights . 74
Dipstick ..........
Automatic Transmission . 291
..................................
Engine Oil .245
..........................
Directional Signals .74
Disc Brake Pad Wear ...................................
Indicators .268
............................
Disc Player .121, 160
..................
Display Change Button . 66
.....................
Disposal of Used Oil .288
Doors .
Auto Door Locking/Unlocking . 82
.....................
Auto Door Locking .82
.................
Auto Door Unlocking . 85
..............
Locking and Unlocking . 81
......................
Power Door Locks .81
Index
C D
II
09/07/15 11:17:54 31SNC640_363
2010 Civic Hybrid
