MAINTENANCE PRODUCT SPECIFICATIONS AND CAPACITIES
Item CapacityFord part name or
equivalentFord part number /
Ford specification
Brake fluidBetween
MIN/MAX on
brake fluid
reservoirMotorcraft
High
Performance DOT 3
Motor Vehicle Brake
FluidPM-1-C /
WSS-M6C62-A or
WSS-M6C65-A1
4.6L engine oil 6.0 quarts (5.7L)•Motorcraft
SAE 5W-20
Premium Synthetic
Blend Motor Oil (US)
•Motorcraft
SAE 5W-20
Full Synthetic Motor Oil
(US)
•Motorcraft
SAE 5W-20
Super Premium Motor
Oil (Canada)
•Motorcraft
SAE 5W-20
Synthetic Motor Oil
(Canada)
1
•XO-5W20–QSP (US)
•XO-5W-20 QFS (US)
•CXO-5W20–LSP12
(Canada)
•CXO-5W-20-LFS12
(Canada) /
WSS-M2C930–A and API
Certification Mark 5.4L engine oil 7.0 quarts (6.6L)
4.6L 2V engine coolant16.4 quarts
(15.5L)
Motorcraft
Premium
Gold Engine Coolant
with bittering agent
(yellow-colored)
2
VC-7–B /
WSS-M97B51–A1 4.6L 3V engine coolant15.8 quarts
(15.0L)
5.4L engine coolant16.9 quarts
(16.0L)
Maintenance and Specifications
400
2010 F-150(f12)
Owners Guide, 1st Printing
USA(fus)

Item CapacityFord part name or
equivalentFord part number /
Ford specification
Fuel tank
Reg. Cab 8’ box /
SuperCab 6.5’ box /
SuperCab 8’ box26.0 gallons
(98.4L) Standard
36.0 gallons
(136.2L) Optional——
1Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the
requirements of Ford specification WSS-M2C930-A and the API Certification mark.2Add the coolant type originally equipped in your vehicle.3Service refill capacity is determined by filling the axle to 1/4-9/16 inch (6-14 mm) below the
bottom of the filler hole with the vehicle on a level surface.
Add 4 oz. (118 ml) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification
EST-M2C118-A, for complete fill of 8.8 inch and 9.75 inch Traction-Lok axles.4Your vehicle’s rear axle is filled with a synthetic rear axle lubricant and is considered lubricated
for life. These lubricants do not need to be checked or changed unless a leak is suspected, service
is required or the axle assembly has been submerged in water. The axle lubricant should be
changed any time the rear axle has been submerged in water.5Service refill capacity is determined by filling the transfer case to the bottom of the filler hole
with the vehicle on a level surface.6Approximate dry fill capacity including transmission fluid cooling system, actual refill capacities
will vary based on vehicle application and transmission fluid cooling system (i.e. coolers size,
cooling lines, auxiliary cooler capacities). The amount of transmission fluid and fluid level should
be set by the indication on the dipstick’s normal operating range.7Automatic transmissions that require MERCON
LV should only use MERCON
LV fluid. Refer to
scheduled maintenance informationto determine the correct service interval. Use of any fluid
other than the recommended fluid may cause transmission damage.
Maintenance and Specifications
403
2010 F-150(f12)
Owners Guide, 1st Printing
USA(fus)

A
Accessory delay ..........................93
AdvanceTrac ..............................279
Air cleaner filter .......396–397, 399
Air conditioning ........59, 62, 64, 67
manual heating and air
conditioning system .................59
Airbag supplemental restraint
system ................185–186, 193, 196
and child safety seats ............187
description ..............186, 193, 196
disposal ....................................199
driver airbag ....186, 188, 194, 197
indicator light .........192, 195, 198
operation .........186, 188, 194, 197
passenger
airbag ...............186, 188, 194, 197
side airbag ...............................193
Ambient mood/lighting ...............78
Ambulance packages ....................6
AM/FM .........................................42
Antifreeze
(see Engine coolant) ................373
Anti-lock brake system
(see Brakes) ......................277–278
Anti-theft system ......................138
arming the system ..................139
Armrests ....................................151
Audio system (see Radio) ...40, 42
Automatic transmission
driving an automatic
overdrive .........................291, 293
fluid, adding ....................393, 395
fluid, checking ................393, 395
fluid, refill capacities ..............400
fluid, specification ..................400
Auxiliary input jack (Line in) ....50Axle
lubricant specifications ..........400
refill capacities ........................400
B
Battery .......................................371
acid, treating emergencies .....371
jumping a disabled battery ....338
maintenance-free ....................371
replacement, specifications ...399
servicing ..................................371
Bed extender ............................117
Belt-Minder
.............................180
deactivating/activating the
Belt-Minder
...........................183
Booster seats .............................219
Brakes ........................................277
anti-lock ...........................277–278
anti-lock brake system (ABS)
warning light ...........................278
fluid, checking and adding ....393
fluid, refill capacities ..............400
fluid, specifications .................400
lubricant specifications ..........400
parking ....................................278
shift interlock ..................287, 289
trailer .......................................263
Bulbs ............................................78
C
Capacities for refilling fluids ....400
Car2U
Home Automation
System .......................................108
Cargo management system ......120
CD ................................................42
Cell phone use ..............................8
Changing a tire .........................330
Index
413
2010 F-150(f12)
Owners Guide, 1st Printing
USA(fus)

Child safety seats ......................204
attaching with tether straps ..214
in front seat ....................205, 211
in rear seat ......................205, 211
LATCH .....................................212
recommendations ...................202
Child safety seats - booster
seats ...........................................219
Cleaning your vehicle
engine compartment ..............355
instrument panel ............357–358
interior .....................................359
plastic parts ............................356
safety belts ..............................359
washing ....................................353
waxing .....................................354
wheels ......................................354
wiper blades ............................356
Climate control
(see Air conditioning or
Heating) .....................59, 62, 64, 67
Clock adjust
AM/FM .......................................43
AM/FM Stereo ...........................42
Compass, electronic ....................88
calibration .................................89
set zone adjustment .................89
Console ........................................88
Controls
power seat ...............................153
steering column ......................101
Coolant
checking and adding ..............373
refill capacities ................376, 400
specifications ..........................400
Cruise control
(see Speed control) ....................98
Customer Assistance ................319Ford Extended Service
Plan ..........................................410
Getting assistance outside the
U.S. and Canada .....................350
Getting roadside assistance ...319
Getting the service you
need .........................................346
Ordering additional owner’s
literature .................................351
Utilizing the
Mediation/Arbitration
Program ...................................350
D
Daytime running lamps
(see Lamps) ................................74
Defrost
rear window and rearview
mirrors ...........................62, 64, 67
windshield .....................62, 64, 67
Dipstick
automatic transmission
fluid ..................................393, 395
engine oil .................................368
Driving under special
conditions ..................296, 309, 312
sand .........................................311
snow and ice ...........................313
through water .................311, 314
E
Electronic message center ...22, 30
Emergencies, roadside
jump-starting ..........................338
running out of fuel .........338, 385
Emission control system ..........389
Engine ................................404–405
cleaning ...................................355
Index
414
2010 F-150(f12)
Owners Guide, 1st Printing
USA(fus)

coolant .....................................373
fail-safe cooling .......................377
idle speed control ...................371
lubrication specifications .......400
refill capacities ........................400
service points ..................365–366
Engine block heater .................275
Engine oil ..................................368
checking and adding ..............368
dipstick ....................................368
filter, specifications ........370, 399
recommendations ...................370
refill capacities ........................400
specifications ..........................400
Event data recording ....................7
Exhaust fumes ..........................275
F
Fail safe cooling ........................377
Fleet MyKey programming ......141
Flexible Fuel Vehicle (FFV) ....379
Fluid capacities .........................400
Fog lamps ....................................73
Four-Wheel Drive vehicles .......301
driving off road .......................307
electronic shift ........................304
indicator light .........................301
lever operated shift ................302
preparing to drive your
vehicle .....................................286
Fuel ............................................379
calculating fuel
economy ......................26, 32, 386
cap ...........................................381
capacity ...................................400
choosing the right fuel ...........383
comparisons with EPA fuel
economy estimates .................389detergent in fuel .....................385
filler funnel .............................385
filling your vehicle with
fuel ...........................379, 381, 386
filter, specifications ........378, 399
fuel pump shut-off ..................321
improving fuel economy ........386
octane rating ...383–384, 404–405
quality ......................................384
running out of fuel .........338, 385
safety information relating to
automotive fuels .....................379
Fuel - flex fuel vehicle
(FFV) .........................379, 383–384
Fuses ..................................321–322
G
Garage door opener ..................104
Gas cap (see Fuel cap) ............381
Gas mileage
(see Fuel economy) .................386
Gauges .........................................18
transmission fluid
temperature gauge ...................22
H
Hazard flashers .........................320
Headlamps ...................................72
aiming ..................................74–75
autolamp system .......................72
bulb specifications ....................79
daytime running lights .............74
flash to pass ..............................73
high beam .................................73
replacing bulbs .........................79
turning on and off ....................72
Index
415
2010 F-150(f12)
Owners Guide, 1st Printing
USA(fus)
