2010 FIAT LINEA RHD check engine light

LOW ENGINE OIL
PRESSURE (red)
Turning the ignition key to
MARthe warning light turns on, but it
should go out as soon as the engine is
started.
On certain versions the dedicated message
is displayed.
If the warning light
turns on when the car is trav-
elling (on cer tain versions together
with the message on the display) stop
the engine immediately and contact
a Fiat Dealership.
WARNING
In the case of demanding use (e.g.
towing traile rs uphill or car at full
load): slow down and stop the car if
the warning light stays on. Stand for
2 or 3 minutes with the engine running
and slightly accelerated to promote a
better circulation of coolant.
Then
stop the engine. Check correct liquid
level as described above.
IMPORTANT Under severe use of the
car, keep the engine on and slightly accel-
erated for few minutes before switching it
off.
On certain versions the dedicated message
is displayed.LOW BATTERY
CHARGE (red)
Turning the igni tion key to
MARthe warning light turns on, but it
should go out as soon as the engine is
started (with the engine running at idle
speed a brief delay in going out is allowed).
Go to a Fiat Dealership immediately
if the warning light stays on either ste-
ady or blinking.
CORRECT USE
OF THE CAR
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES
104
LINEA Owner HAND BOOK RHD.pdf 104LINEA Owner HAND BOOK RHD.pdf 1048/21/09 2:16:15 PM8/21/09 2:16:15 PM

IMPORTANT Scheduled service coupons
are required by the manufacturer. Default
may cancel the warranty.
Scheduled Servicing is performed by all
Fiat Dealersh ip,
at pre-e stab lished
times.
If during each operation, in addition to the
ones programmed, the need arises for fur-
ther replacements or repairs,
these may
be carried out only with the explicit agree-
ment of the Customer.IMPORTANT
You are advised to contact
Fiat Dealersh ip in the event of any
minor operating faults,
witho ut waiting
for the next service coupon.
If your car is used frequently for towing,
the interval between one service coupon
and the other must be reduced.
SCHEDULED SERVICING
Correct maintenance is essential for en-
suring long car life under the best condi-
tions.
This is why Fiat has planned a series of
checks and
maintenance operations every
Scheduled servicing will not however ful-
ly cover all of the need of your car:
It is
however important to remember that
scheduled servicing
does not completely
cover all the car’s requirements: also in
the
initial period before 20,000 km service
coupon and later, between one coupon
and another,
ordinary care is still required
such as for example routine check and
topping up the level of fluids, tyre pressure
check, touch-up of damages to protective
138
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES
SPECIFICATIONS
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
DASHBOARD
SAFETY
TECHNICAL
20,000 km.
coating of bodywork, etc.
PETROL ENGINES
LINEA Owner HAND BOOK RHD.pdf 138LINEA Owner HAND BOOK RHD.pdf 1388/21/09 2:16:21 PM8/21/09 2:16:21 PM

Thousands of kilometres
Replace spark plugs
Check and Top up fluid levels (engine coolant, brake
fluid, screen washer, battery, and power steering oil,
etc, if requried) ( )
Check condition of toothed driving belt
Check operation of engine management systems
(using diagnostic socket) Replace toothed timing drive belt (*)
Change brake / clutch fluid (every 60000 kms or
24 months, whichever is earlier) Change engine oil and replace oil filter
(every 20,000 kms or 12 months, whichever is earlier)
Change pollen filter
(*) Regardless of the km covered, the timing belt shall be replaced every 3 years for particularly demanding use
(cold climates, driving in the city, idling for a long time) or in any case every 5 years
(**) Paint and or body damages must promply be rectified to prevent possible deterioration of paint and ( ) Regardless of the km covered, Air filter should be replaced earlier if operating in dusty condition
140
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES
SPECIFICATIONS
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
DASHBOARD
SAFETY
TECHNICAL
20 40 60 80 100 120 140 160 180
Check transmission oil level
( ) Change power steering oil every 24 months
formation of rust
LINEA Owner HAND BOOK RHD.pdf 140LINEA Owner HAND BOOK RHD.pdf 1408/21/09 2:16:22 PM8/21/09 2:16:22 PM

Thousands of kilometres
Replace air filter cartridge ( )
Check and Top up fluid levels (engine coolant, bra-
ke fluid screen washer, battery, and power steering
oil, etc, if requried) ( )
Check operation of engine management systems
(using diagnostic socket)
Change engine oil and replace oil filter (every
15000 kms or 12 months, whichever is earlier)
Change brake/clutch fluid (every 60000 kms or 24
months, whichever is earlier)
Change pollen filter (every 15000 kms)
Change of engine coolant (every 60000 kms or 24
months, whichever is earlier)
Change of transmission oil (every 60000 kms or
( ) Regardless of the km covered, Air filter should be replaced earlier if operating in dusty condition 24 months, whichever is earlier)
Wheel alignment
Tires rotation (Pattern : Front to Rear)
15 30 45 60 75 90 105 120 135 150 165 180Inspection
at 3000 kms
142
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES
SPECIFICATIONS
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
DASHBOARD
SAFETY
TECHNICAL(*) Regardless of the km covered, the timing belt shall be replaced every 4 years for particularly demanding use
(cold climates, driving in the city, idling for a long time) or in any case every 5 years
( ) Change power steering oil every 24 months
LINEA Owner HAND BOOK RHD.pdf 142LINEA Owner HAND BOOK RHD.pdf 1428/21/09 2:16:22 PM8/21/09 2:16:22 PM

DEMANDING USE
OF THE CAR
Should prevailing use of the car be under
one of the following specially heavy con-
ditions:
trailer or caravan towing;
dusty roads;
short distances (less than 7-8 km) re-
peated and with external temperatures
below zero;
frequently idling engines or long dis-
tance low speed driving (e.g . taxis or
door-to-door deliveries) or in case of
a long term inactivity;
in cities;
perform the following inspections and
shown on the Service Schedule:

check cleanness of locks, bonnet and
boot and lever cleanness and lubrica-
tion;
visually inspect the conditions of: en-
gine, gearbox, transmission, pipes and
hoses (exhaust - fuel - brakes), rubber
parts (boots, sleeves, bushes, etc.);
check battery charge and liquid level
(electrolyte) (see paragraph “Charge
level check” in chapter “Maintenance
and care”);
visually inspect the accessory drive belt
conditions;
check pollen filter
check air cleaner and replace, if re-
quired.
REGULAR
INSPECTIONS
Every 1,000 km or before long journeys,
check and top up if required:
 engine coolant fluid level; Engine Oil level, every 3,000 km and
brake - clutch fluid level and type;
power steering fluid level;


tyre pressure and conditions;
operation of lights (headlights, direction
indicators, hazard lights, etc.);
143
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
TECHNICAL
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
SPECIFICATIONS
AND CONTROLS
DEVICES
. If the vehicle is
replacements more frequently than
check front disk brake pad conditions
and wear; frequently than required; replace engine oil and oil filter more
frequently
than required on the service replace spark plugs more
schedules, in particular contact a Fiat
Dealership if a reduction in the
vehicle engine performance is noted;used frequently in dusty or heavily
polluted environments it is
advisable to replace the filtering
elementts more frequently, in
particular it should be replaced if a
reduction of the amount of air
admitted to the passenger
compartment is noted; top up if required;
LINEA Owner HAND BOOK RHD.pdf 143LINEA Owner HAND BOOK RHD.pdf 1438/21/09 2:16:22 PM8/21/09 2:16:22 PM

CHECKING FLUID
