Mirrors
Each fitted with an adjustable mirror glass permitting the lateral rear ward vision necessary for over taking or parking. They can also be folded for parking in confined spaces.
Demisting - Defrosting
If your vehicle is fitted with heated mirrors, the demisting-defrosting operates with the engine running, by switching on the heated rear screen (refer to the "Rear screen demist-defrost" page).
Adjustment
 Move control A to the right or to the left to select the corresponding mirror.  Move control B in all four directions to adjust.  Return control A to the central position.
Door mirrors
The objects obser ved are, in reality, closer than they appear. Take this into account in order to correctly judge the distance of vehicles approaching from behind.
Folding
 From outside: lock the vehicle using the remote control or the key.  From inside: with the ignition on, pull control A rear wards.
Unfolding
 From outside: unlock the vehicle using the remote control or the key.  From inside: with the ignition on, pull control A rear wards.
If the mirrors are folded using control A , they will not unfold when the vehicle is unlocked. Pull again on control A .
The folding and unfolding of the door mirrors using the remote control can be deactivated by a CITROËN dealer. Never fold or unfold the electric folding mirrors manually.

lamps and flashing of the direction indicators for a few seconds.
Locating your vehicle
 Press the closed padlock to
locate your locked vehicle in a car park.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip which has a special code. When the ignition is switched on, this code must be recognised in order for star ting to be possible. This electronic engine immobiliser locks the engine management system a few minutes after the ignition is switched off and prevents star ting of the engine by anyone who does not have the key.
In the event of a malfunction, you are informed by lighting of this warning lamp, an audible signal and a message on the multifunction screen. In this case, your vehicle does not star t; contact a CITROËN dealer as soon as possible.
- Position 1: Stop - Position 2: Ignition - Position 3: Star ting
Ignition switch

lamps and flashing of the direction indicators for a few seconds.
Locating your vehicle
 Press the closed padlock to
locate your locked vehicle in a car park.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip which has a special code. When the ignition is switched on, this code must be recognised in order for star ting to be possible. This electronic engine immobiliser locks the engine management system a few minutes after the ignition is switched off and prevents star ting of the engine by anyone who does not have the key.
In the event of a malfunction, you are informed by lighting of this warning lamp, an audible signal and a message on the multifunction screen. In this case, your vehicle does not star t; contact a CITROËN dealer as soon as possible.
- Position 1: Stop - Position 2: Ignition - Position 3: Star ting
Ignition switch

85Access
Starting the vehicle
 Inser t the key in the ignition switch.
The system recognises the star ting code.  Turn the key fully towards the dashboard to position 3 (Star ting) .  When the engine star ts, release the key.
 Immobilise the vehicle.
 Turn the key fully towards you to position 1 (Stop) .  Remove the key from the ignition switch.
Switching the vehicle off
Do not attach any heavy objects to the key as this could weigh down on it when in the ignition switch and cause a fault.
Key reminder
If the key is left in the ignition switch, an audible signal sounds when the driver's door is opened.

Doors
From outside
 After unlocking the vehicle using the remote control or the key, pull the door handle.
From inside
 Pull the door lever to open the door; this unlocks this vehicle completely.
Closing
When a door is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message on the multifunction screen for a few seconds,
- when the vehicle is moving (speed higher than 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message on the multifunction screen for a few seconds.

93Access
Boot
Opening
 After unlocking the vehicle using the remote control or the key, pull the handle and raise the tailgate.
Closing
 Lower the tailgate using the interior grab handle.
If the tailgate is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message on the multifunction screen for a few seconds,
- when the vehicle is moving (speed above 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message on the multifunction screen for a few seconds.
System for mechanical unlocking of the boot in the event of a battery or central locking malfunction.
Tailgate release
Unlocking
 Fold back the rear benchseat to gain access to the lock from inside the boot.  Inser t a small screwdriver into hole A of the lock to unlock the tailgate.

Fuel tank Fuel tank capacity: approximately 50 litres (petrol) or 48 litres (Diesel).
Low fuel level
Filling
A label affixed to the inside of the flap reminds you of the type of fuel to be used depending on your engine. Additions of fuel must be of at least 5 litres,
in order to be taken into account by the fuel gauge.
The key cannot be removed from the lock until the cap is refitted. Opening the filler cap may create a noise caused by an inrush of air. This vacuum is entirely normal, resulting from the sealing of the fuel system.
To fill the tank safely:  the engine must be switched off, open the fuel filler flap,  inser t the key in the cap, then turn it to the left,
 remove the cap and hook it onto the clip located on the inside of the flap,  fill the tank, but do not continue after the 3rd cut- off of the pump ; this could cause malfunctions.
When you have filled the tank:  put the cap back in place,  turn the key to the right, then remove it from the cap,  close the flap.
When the fuel tank minimum level is reached this warning lamp comes on
on the instrument panel. When it first comes on there remains approximately 5 litres of fuel in the tank. You must refuel as soon as possible to avoid running out of fuel. If you run out of fuel (Diesel), refer also to the "Checks" section.
With Stop & Star t, never refuel with the system in STOP mode; you must switch off the ignition with the key.

95Access
Quality of the fuel used for
petrol engines
The petrol engines are per fectly compatible with E10 type petrol biofuels (containing 10 % ethanol), conforming to European standards EN 228 and EN 15376. E85 type fuels (containing up to 85 % ethanol) are reser ved exclusively for vehicles marketed for the use of this type of fuel (BioFlex vehicles). The quality of the ethanol must comply with European standard EN 15293. For Brazil only, special vehicles are marketed to run on fuels containing up to 100 % ethanol (E100 type).
Quality of the fuel used for
Diesel engines
