2010 Citroen DS3 DAG key

87Access
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Lost keys
Visit a CITROËN dealer with the vehicle's V5 registration document and your personal identification documents. The CITROËN dealer will be able to retrieve the key code and the transponder code required to order a replacement key.
Remote control
The high frequency remote control is a sensitive syst em; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it. Do not repeatedly press the buttons of your remote con trol out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would have to be reinitialised. The remote control does not operate when the key is i n the ignition, even when the ignition is switched off, except for reinitialisation.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the emergency ser vices more difficult in an emergency. As a safety precaution (with children on board), remove the key from the ignition when you leave the vehicle, even for a shor t time.
Anti-theft protection
Do not make any modifications to the electronic engin e immobiliser system; this could cause malfunctions.
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure that the keys in your possession are the only ones which can star t the vehicle.

85Access
Starting the vehicle
 Inser t the key in the ignition switch.
The system recognises the star ting code.  Turn the key fully towards the dashboard to position 3 (Star ting) .  When the engine star ts, release the key.
 Immobilise the vehicle.
 Turn the key fully towards you to position 1 (Stop) .  Remove the key from the ignition switch.
Switching the vehicle off
Do not attach any heavy objects to the key as this could weigh down on it when in the ignition switch and cause a fault.
Key reminder
If the key is left in the ignition switch, an audible signal sounds when the driver's door is opened.

Following disconnection of the vehicle battery,
replacement of the remote control battery or in the event of a remote control malfunction, you can no longer unlock, lock or locate your vehicle.  First of all, use the key in the lock to unlock or lock your vehicle.  Then, reinitialise the remote control. If the problem persists, contact a CITROËN dealer as soon as possible.
Remote control problem
Reinitialisation
 Switch off the ignition.  Turn the key to position 2 (Ignition) .  Press the closed padlock immediately for a few seconds.  Switch off the ignition and remove the key from the ignition switch. The remote control is fully operational again.
Changing the battery
Battery ref.: CR1620/3 volts. This replacement battery is available from CITROËN dealers.
 Maintain pressure on lug A and remove the chrome finisher by sliding it off at 45°.  Unclip the casing by inser ting a coin at the
notch and rotating.  Slide the flat battery out of its location.  Slide the new battery into its location obser ving the original direction.  Clip the casing in place, then the chrome finisher.  Reinitialise the remote control.
If the battery is flat, you are informed by lighting of this warning lamp in the instrument panel, an audible signal and a message on the multifunction screen.
 Unfold the key.  Release the chrome finisher by pressing on
lug A .

87Access
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Lost keys
Visit a CITROËN dealer with the vehicle's V5 registration document and your personal identification documents. The CITROËN dealer will be able to retrieve the key code and the transponder code required to order a replacement key.
Remote control
The high frequency remote control is a sensitive syst em; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it. Do not repeatedly press the buttons of your remote con trol out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would have to be reinitialised. The remote control does not operate when the key is i n the ignition, even when the ignition is switched off, except for reinitialisation.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the emergency ser vices more difficult in an emergency. As a safety precaution (with children on board), remove the key from the ignition when you leave the vehicle, even for a shor t time.
Anti-theft protection
Do not make any modifications to the electronic engin e immobiliser system; this could cause malfunctions.
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure that the keys in your possession are the only ones which can star t the vehicle.

89Access
In the event of unwanted opening of the window on closing (for example in the presence of frost):  press the switch until it opens completely,  then pull it immediately until it
closes,  continue to hold the switch for approximately one second after the window has closed. The safety anti-pinch function is not active during these operations.
Safety anti-pinch
On the driver's side, the one-touch front electric window has a safety anti-pinch function. When the window rises and meets an obstacle, it stops and par tially lowers again.
Reinitialisation
Always remove the key from the ignition when leaving the vehicle, even for a shor t time. In the event of contact during operation of the windows, reverse the movement of the window. To do this, press the corresponding switch. When the driver operates the passenger electric window switch, they should ensure that no one is preventing correct closing of the window. The driver should ensure that the passenger uses the electric window correctly. Be aware of children when operating the windows.
In the event of a malfunction you have to
reinitialise the operation of the electric windows:  release the switch and pull it again until the window closes completely,  hold the switch for approximately one second after closing,  press the switch to lower the window automatically. The safety anti-pinch function is not active during these operations.

Doors
From outside
 After unlocking the vehicle using the remote control or the key, pull the door handle.
From inside
 Pull the door lever to open the door; this unlocks this vehicle completely.
Closing
When a door is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message on the multifunction screen for a few seconds,
- when the vehicle is moving (speed higher than 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message on the multifunction screen for a few seconds.

91Access
System which provides full manual locking or unlocking of the doors from the inside.
Manual centralised control
Locking
 Press button A to lock the vehicle.
The red indicator lamp on the button comes on.
Unlocking
 Press button A again to unlock the vehicle. The red indicator lamp on the button switches off.
If one of the doors is open, central locking from the inside does not take place.
If the vehicle is locked from the outside, the red indicator lamp flashes and button A is inactive.  In this case, use the remote control or the key to unlock the vehicle.
Automatic centralised
control
System which provides full automatic locking or unlocking of the doors and the boot while driving. You can activate or deactivate this function.
Locking
When the speed exceeds 6 mph (10 km/h), the doors and the boot lock automatically.
Unlocking
 Above 6 mph (10 km/h), press button A to
unlock the doors and the boot temporarily.
If one of the doors is open, the automatic central locking does not take place. If the boot is open, the automatic central locking of the doors is active.

Activation
 Press button A for more than two seconds. A confirmation message appears on the multifunction screen, accompanied by an audible signal.
Deactivation
 Press button A again for more than two seconds. A confirmation message appears on the multifunction screen, accompanied by an audible signal.
To lock or unlock the doors mechanically in the event of a central locking system failure or flat battery.
Emergency control
Locking the driver's door
 Inser t the key in the lock, then turn it to the right.
Unlocking the driver's door
 Inser t the key in the lock, then turn it to the left.
Locking the passenger's door
 Remove the black cap, on the edge of the door, using the key.  Inser t the key in the cavity, then turn it fully.  Remove the key and refit the cap.
Unlocking the passenger's door
 Pull the interior door opening control.
In the event of a fault with the central locking system, you must disconnect the battery to lock the boot and so ensure the complete locking of the vehicle.
