I
20
INSTRUMENT PANEL WARNING LAMPS
Warning lamp is on Cause Actions/
Observations
Left-hand direction
indicator Flashing
with
audible
warning T h i s fl a s h e s w h e n y o u
press the lighting stalk
down. I f t h i s i n d i c a t o r l a m p fl a s h e s a b n o r m a l l y q u i c k l y ,
this could indicate that the bulb of one of the
direction indicators has blown. Change the bulb
or contact a CITROËN dealer.
Right-hand direction
indicator Flashing
with
audible
warning T h i s fl a s h e s w h e n y o u
push the lighting stalk up. I f t h i s i n d i c a t o r l a m p fl a s h e s a b n o r m a l l y q u i c k l y ,
this could indicate that the bulb of one of the
direction indicators has blown. Change the bulb
or contact a CITROËN dealer.
Main beam headlamps Fixed This comes on when
you pull the lighting stalk
towards you. Pull the stalk to return to dipped beam
headlamps.
Sidelamps Fixed This comes on when the
lighting stalk is in the
"Sidelamps" or "Dipped
beam headlamps"
position. Turn the stalk to the desired position.
Front foglamps Fixed This comes on when you
use the front foglamps. Turn the ring on the stalk forwards to switch on
the foglamps.
Rear foglamps Fixed This comes on when you
use the rear foglamps. Turn the ring on the stalk forwards to switch on
the foglamps.
Cruise control Fixed This comes on when the
mode is active. Press the "ON/OFF" button to activate/
deactivate the mode.
Page 17 of 217
I
!
M O N I T O R I N G
33
When the vehicle is
s t a t i o n a r y , i t a l l o w s
the user to change the
following settings:
- resetting average fuel consumption
a n d a v e r a g e s p e e d ,
- t h e f u e l c o n s u m p t i o n u n i t s ,
- t h e t e m p e r a t u r e d i s p l a y u n i t s ,
- t h e d i s p l a y l a n g u a g e ,
- activation/deactivation of the INFO
b u t t o n s o u n d ,
- the break (rest) reminder display i n t e r v a l ,
- restore factory settings.
SETTING MENU
System which provides access to the
settings of certain functions.
T o c h a n g e t h e s e t t i n g s , y o u
must stop the vehicle and switch
on the ignition.
Apply the parking brake and place
the gear lever in neutral.
When the vehicle is moving , t h e
setting menu screen is not displayed
when you press the INFO button.
The various menus may differ for the
type 1 instrument panel and the type 2
instrument panel.
With the ignition on , p r e s s t h e INFO
b u t t o n o n t h e d a s h b o a r d , t o t h e r i g h t o f
t h e i n s t r u m e n t p a n e l , s e v e r a l t i m e s i n
succession until the "SETTING MENU"
screen is displayed.
Operation
press and hold the INFO button for
a few seconds to display the menu
screen.
Press and hold the INFO button
for a few seconds to return to the
previous screen.
When the menus screen is dis-
p l a y e d , i f n o o p e r a t i o n i s c a r r i e d o u t
w i t h i n 1 5 s e c o n d s , t h e s e t t i n g m e n u
screen is displayed.
o n t h e m e n u s c r e e n , p r e s s t h e INFO
button to select a function from the
list:
MENU
2/3:
- a/b (option of displaying a different
language in the instrument panel
s c r e e n a n d t h e n a v i g a t i o n s c r e e n ) ,
- a c t i v a t i o n / d e a c t i v a t i o n o f t h e I N F O
button sound ,
- ALARM
(changing the "BREAK
R E M I N D E R " d i s p l a y i n t e r v a l ) ,
- choice of the direction indicators s o u n d ,
- a c t i v a t i o n / d e a c t i v a t i o n o f
current
f u e l c o n s u m p t i o n ,
MENU
1/3
:
- 1 - 2 (options for resetting aver-
age fuel consumption and average
s p e e d ) ,
- UNIT (choice of the fuel consump-
t i o n u n i t s ) ,
- choice of the t e m p e r a t u r e d i s p l a y
unit
s ,
- LANGUAGE (choice of display lan-
g u a g e ) ,
MENU 3/3:
- RESET
(restore factory settings).
Page 47 of 217
II
!
C O M F O R T
59
DOOR MIRRORS
Adjustment
The mirrors can be adjusted when the
ignition switch is in the "ON" or "ACC"
p o s i t i o n .
Move control A to the right or to the left
t o s e l e c t t h e c o r r e s p o n d i n g m i r r o r .
Direct control B in all four directions
t o a d j u s t t h e m i r r o r .
W h e n a d j u s t m e n t i s c o m p l e t e , r e t u r n
control A t o t h e c e n t r a l p o s i t i o n . Electric folding/unfolding
- from inside, with the ignition switch
i n t h e " O N " o r " A C C " p o s i t i o n :
b y p r e s s i n g t h e c o n t r o l C .
- from inside, with the ignition switch i n t h e " L O C K " p o s i t i o n :
b y p r e s s i n g t h e c o n t r o l C, w i t h i n
30 seconds.
- from outside using the remote control:
b y p r e s s i n g t h e " c l o s e d p a d -
l o c k b u t t o n b r i e fl y 3 t i m e s t o f o l d
them,
b y p r e s s i n g t h e " o p e n p a d l o c k "
b u t t o n b r i e fl y 3 t i m e s t o u n f o l d
t h e m .
The folding and unfolding of the door
m i r r o r s c a n b e c o n fi g u r e d v i a t h e c o l -
o u r s c r e e n " E q u i p m e n t " m e n u o r d e -
a c t i v a t e d b y a C I T R O Ë N d e a l e r . The mirrors can also be folded
m a n u a l l y .
If you have folded the mirrors us-
ing the control C , you must use this
control to unfold them, otherwise the
m i r r o r s w i l l n o t b e l o c k i n p l a c e c o r -
r e c t l y .
If you switch the engine off then
re-start it with the mirrors folded, they
will unfold automatically when the
v e h i c l e r e a c h e s 2 0 m p h ( 3 0 k m / h ) .
If the mirrors have been folded manu-
ally or electrically after starting the
engine, they are not unfolded auto-
m a t i c a l l y .
In this case:
Press the control C t o u n f o l d t h e m .
Page 59 of 217
III
A C C E S S
71
Unfolding the key
First press button A to unfold the key.
Unlocking the vehicle
Press the open padlock to
unlock the vehicle.
Unlocking using the remote control
REMOTE CONTROL KEY
System which permits central unlock-
ing or locking of the vehicle using the
lock or from a distance. It also folds and
unfolds the mirrors, closes the electric
windows and starts the vehicle, as well
as providing protection against theft.
Locking the vehicle
Unlocking using the key
Turn the key to the right in the driver's
door lock to unlock the vehicle.
Press the closed padlock
to lock the vehicle.
If one of the doors or the tailgate is
still open, the central locking will not
take place.
U n l o c k i n g i s c o n fi r m e d b y t h e i n t e r i o r
lighting which comes on for approxi-
mately 15 seconds and the direction
i n d i c a t o r s w h i c h fl a s h
twice .
If you press the open padlock twice in
succession within 30 seconds after
unlocking the vehicle, the door mirrors
unfold.
Normal locking using the key
Turn the key to the left in the driver's
door lock to lock the vehicle.
L o c k i n g i s c o n fi r m e d b y t h e d i r e c t i o n i n -
dicators which come on
once .
If you press the closed padlock twice
in succession within 30 seconds af-
ter locking the vehicle, the door mirrors
fold.
An extended press on the closed pad-
lock within 30 seconds after locking the
vehicle closes the windows automati-
cally.
Normal locking using the remote
control
Page 61 of 217
III
A C C E S S
73
Starting the vehicle
Insert the key in the ignition switch.
Operate the starter by turning the
key to position 4 (START) .
When the engine turns over, release
the key. The ignition switch is placed
in position 3 (ON) automatically.
Switching the vehicle off
Park the vehicle.
While pressing the key, turn it to-
wards you to position 1 (LOCK) .
Remove the key from the ignition
switch. Changing the battery
Battery reference: CR1616/3 volts.
Unclip the casing using a coin at the
notch.
S l i d e t h e fl a t b a t t e r y o u t o f i t s h o u s i n g .
Slide the new battery into its housing
observing the original direction.
Clip the casing.
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
in the ignition.
Page 65 of 217
III
A C C E S S
73
Starting the vehicle
Insert the key in the ignition switch.
Operate the starter by turning the
key to position 4 (START) .
When the engine turns over, release
the key. The ignition switch is placed
in position 3 (ON) automatically.
Switching the vehicle off
Park the vehicle.
While pressing the key, turn it to-
wards you to position 1 (LOCK) .
Remove the key from the ignition
switch. Changing the battery
Battery reference: CR1616/3 volts.
Unclip the casing using a coin at the
notch.
S l i d e t h e fl a t b a t t e r y o u t o f i t s h o u s i n g .
Slide the new battery into its housing
observing the original direction.
Clip the casing.
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
in the ignition.
Page 73 of 217
III
A C C E S S
80
SUNROOF Complete closing
With the ignition on, push the con-
trol forwards (in the direction 2 ).
T h e d e fl e c t o r f o l d s d o w n g r a d u a l l y o n
closing.
Complete opening
With the ignition on, push the control
rearwards (in the direction 1 ).
A d e fl e c t o r i s d e p l o y e d g r a d u a l l y o n
opening to prevent unwanted gusts of
air. Temporary stop
To stop opening or closing, press
part 3 of the control or push the con-
trol in the opposite direction.
Partial opening
To open , with the ignition on, press
part 3 of the control.
The rear part of the sunroof opens.
To close , with the ignition on, press
part 3 of the control.
The rear part of the sunroof closes. Safety anti-pinch and reinitialisation
If the roof meets an obstacle while it is
closing, it stops and opens again.
The sunroof stops automatically just
before complete opening. Push the
control again for complete opening.
Operation
In the event of unwanted opening of
the roof on closing (for example, in
the presence of ice) and immediately
after the roof has stopped, or after
the safety anti-pinch has been trig-
g e r e d fi v e t i m e s i n s u c c e s s i o n :
press part 3 of the control several
times to partially open the roof,
when the roof partially opens,
continue to press for more than
3 seconds ,
open and close the sunroof com-
pletely.
The
safety
anti
-
pinch
function is
not
operational during
t
hese opera-
tions.
Page 94 of 217
VI
S A F E T Y
99
DIRECTION INDICATORS HAZARD WARNING LAMPS HORN
Left: lower the lighting stalk passing
the point of resistance.
Right: raise the lighting stalk pass-
ing the point of resistance.
Press one of the spokes of the
steering wheel.
"Motorway" function
P r e s s b r i e fl y u p w a r d s o r d o w n -
w a r d s , w i t h o u t g o i n g b e y o n d t h e
p o i n t o f r e s i s t a n c e ; t h e d i r e c t i o n i n -
d i c a t o r s w i l l fl a s h 3 t i m e s . A u d i b l e w a r n i n g t o a l e r t o t h e r r o a d u s e r s
t o a n i m m i n e n t d a n g e r .
T h e a u d i b l e s i g n a l c a n b e c o n fi g u r e d
v i a t h e c o l o u r s c r e e n " E q u i p m e n t "
m e n u .
P r e s s t h i s b u t t o n , t h e d i r e c t i o n i n d i -
c a t o r s fl a s h .
T h e y c a n o p e r a t e w i t h t h e i g n i t i o n o f f .
Automatic operation of hazard warning lamps
W h e n b r a k i n g i n a n e m e r g e n c y , d e -
p e n d i n g o n t h e d e c e l e r a t i o n , t h e h a z a r d
w a r n i n g l a m p s c o m e o n a u t o m a t i c a l l y .
T h e y s w i t c h o f f a u t o m a t i c a l l y t h e fi r s t
t i m e y o u a c c e l e r a t e .
Y o u c a n a l s o s w i t c h t h e m o f f b y
p r e s s i n g t h e b u t t o n .
A v i s u a l w a r n i n g b y m e a n s o f t h e d i r e c -
t i o n i n d i c a t o r s t o a l e r t o t h e r r o a d u s e r s t o
a v e h i c l e b r e a k d o w n , t o w i n g o r a c c i d e n t .
