2010 CHRYSLER 300 SRT trip computer

This system conveniently allows the driver to select a
variety of useful information by pressing the switches
mounted on the steering wheel. The EVIC consists of the
following:
•System status
•Vehicle information warning message displays
•Tire Pressure Monitor System (if equipped)
•Personal Settings (Customer-Programmable Features)
•Compass display
•Outside temperature display
•Trip computer functions
•Uconnect™ Phone displays (if equipped)
•Uconnect™ gps screens (if equipped)
•Audio mode display
•Surround Sound modes (if equipped with Driver-
Selectable Surround [DSS])
•Performance Pages (if equipped)
Electronic Vehicle Information Center (EVIC)
200 UNDERSTANDING YOUR INSTRUMENT PANEL

Press the SCROLL button to cycle through all the Trip
Computer functions.
The Trip Functions mode displays the following informa-
tion.
•Average Fuel Economy
Shows the average fuel economy since the last reset.
When the fuel economy is reset, the display will read
“RESET” or show dashes for two seconds. Then, the
history information will be erased, and the averaging will
continue from the last fuel average reading before the
reset.
•Distance To Empty (DTE)
Shows the estimated distance that can be traveled with
the fuel remaining in the tank. This estimated distance is
determined by a weighted average of the instantaneous
and average fuel economy, according to the current fuel
tank level. DTE cannot be reset through the FUNCTION
SELECT button. NOTE:
Significant changes in driving style or vehicle
loading will greatly affect the actual drivable distance of
the vehicle, regardless of the DTE displayed value.
When the DTE value is less than 30 miles (48 km)
estimated driving distance, the DTE display will change
to a text display of LOW FUEL.This display will
continue until the vehicle runs out of fuel. Adding a
significant amount of fuel to the vehicle will turn off the
LOW FUEL text and a new DTE value will display.
•Trip A
Shows the total distance traveled for Trip A since the last
reset.
•Trip B
Shows the total distance traveled for Trip B since the last
reset.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 207

Brightness, Interior Lights.................. 147
Bulb Replacement ..................... 406,407
Bulbs, Light .......................... 83,406
Calibration, Compass ..................... 213
Capacities, Fluid ........................ 412
Caps, Filler Fuel ............................... 337
Oil (Engine) .......................... 371
Power Steering ........................ 294
Radiator (Coolant Pressure) ............... 385
Car Washes ............................ 393
Carbon Monoxide Warning ...............80,337
Cargo (Vehicle Loading) ................... 340
Cellular Phone ........................ 93,263
Certification Label ....................... 340
Chart, Tire Sizing ........................ 309
Check Engine Light
(Malfunction Indicator Light) ............... 367Checking Your Vehicle For Safety
............. 79
Checks, Safety ........................... 79
Child Restraint .................. 69,70,71,74,76
Child Restraint Tether Anchors .............73,74
Child Safety Locks ........................ 34
Clean Air Gasoline ....................... 333
Cleaning Wheels ............................. 394
Windshield Wiper Blades ................ 378
Climate Control ......................... 263
Clock ..................... 221,222,224,227,236
Coin Holder ........................... 178
Cold Weather Operation ................... 278
Compact Disc (CD) Maintenance ............. 262
Compass .............................. 213
Compass Calibration ..................... 213
Compass Variance ....................... 214
Computer, Trip/Travel .................... 206
446 INDEX

Memory Seat........................... 135
Memory Seats and Radio .................. 135
Methanol ............................. 334
Mini-Trip Computer ...................... 206
Mirrors ................................ 90
Automatic Dimming ..................... 90
Electric Powered ....................... 92
Electric Remote ........................ 92
Exterior Folding ........................ 91
Heated .............................. 93
Outside .............................. 91
Vanity ............................... 93
Modifications/Alterations, Vehicle ............. 7
Monitor, Tire Pressure System ............... 326
Mopar Parts ......................... 368,438
MTBE/ETBE ........................... 334
Multi-Function Control Lever ............... 145
New Vehicle Break-In Period ................ 78Occupant Restraints
................... 42,60,64
Occupant Restraints (Sedan) .............56,60,62
Octane Rating, Gasoline (Fuel) ............333,413
Odometer ............................. 194
Trip ................................ 194
Oil Change Indicator ..................... 206
Oil Change Indicator, Reset ................. 206
Oil, Engine ......................... 370,413
Capacity ............................ 412
Change Interval ....................... 370
Checking ............................ 370
Dipstick ............................. 370
Disposal ............................ 372
Filter ............................ 372,413
Filter Disposal ........................ 372
Materials Added to ..................... 371
Recommendation ................... 371,412
Synthetic ............................ 371
Viscosity ......................... 371,412
10
INDEX 455
