2010 Alfa Romeo Giulietta CD player

266
SOUND SYSTEM
SPEECH VOLUME function
(telephone volume
adjustment)
This function makes it possible to adjust (set-
ting from 1 to 40), by turning the left knob
A-fig. 1 or pressing buttons
/or ex-
clude (OFF setting) the volume of the Tele-
phone and Blue&Me
™(except the Media
Player function).
The display shows the current function status:
❍“Speech Off”: function deactivated.
❍“Speech Volume 23”: function activat-
ed with volume set to 23.
RADIO OFF function
(on and off mode)
This function is used to select the mode for
switching off the radio between two differ-
ent procedures. To turn the function on use
buttons
or.
The selected mode will appear on the dis-
play:
❍“00 MIN”: the radio turns off automat-
ically in connection with the ignition key;
the radio turns off automatically as soon
as the key is turned to the STOP posi-
tion;
❍“20 MIN”: the radio turns off indepen-
dently from the ignition key; the radio
remains on for a maximum period of 20
minutes after the key has been turned
to the STOP position.
SYSTEM RESET function
This function is used to restore all settings
to their preset factory values. The options
are:
❍NO: no restore operation;
❍YES: the default parameters are re-
stored. The display will show “Reset-
ting” during this operation. At the end
of the operation, the source does not
change and the previous situation will
be displayed.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 266

269
SOUND SYSTEM
R R
A A
D D
I I
O O

( (
T T
u u
n n
e e
r r
) )
INTRODUCTION
When the radio is turned on the last func-
tion selected before it was switched off is
activated: Radio, CD, CD MP3 or Media
Player (only with Blue&Me™).
To select the Radio function whilst listening
to another audio source, press the FM
ASor
AM buttons briefly, depending on the desired
band.
Once the Radio mode has been activated,
the display will show the name (RDS sta-
tions only) and the frequency of the select-
ed radio station, the frequency band select-
ed (e.g. FM1) and the preselect button num-
ber (e.g. P1).
FREQUENCY BAND
SELECTION
With the Radio mode activated, press the FMAS
or AM button briefly and repeatedly to select
the desired reception band.
Each time the button is pressed the follow-
ing bands are selected cyclically:
❍Pressing the FMASbutton: “FM1”,
“FM2” or “FMA”;
❍Pressing the AM button: “MW1” and
“MW2”.
Each band is highlighted by the name in the
display. The last station selected on the re-
spective frequency band will be tuned into.
The FM band is divided into sections: FM1,
FM1 or “FMA”; the FMA reception band is
reserved for broadcasters stored automati-
cally using the AutoSTore function.
PRESET BUTTONS
The buttons numbered from 1 to 6 can used
to set the following presettings:
❍18 on the FM band FM (6 on FM1, 6
on FM2, 6 on FMT or “FMA” (on some
versions);
❍12 on the MW band (6 on MW1, 6 on
MW2).
To listen to a preset station, select the desired
frequency band and then briefly press the cor-
responding preset button (from 1 to 6).
By pressing the preset button for more than
2 seconds, the station tuned into will be
stored. The storing phase is confirmed by an
acoustic signal.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 269

273
SOUND SYSTEM
C C
D D

P P
L L
A A
Y Y
E E
R R
INTRODUCTION
This chapter describes the variants regard-
ing the operation of the CD player: as far
as the operation of the radio is concerned,
refer to the description in the “Functions and
Adjustments” chapter.
SELECTING THE CD PLAYER
To activate the CD player built-into the equip-
ment, proceed as follows:
❍load a CD with the device switched on:
the first track will start to play;
or
❍if a CD has already been loaded, turn on
the car radio and then briefly press the
CD button to select the “CD” operating
mode: the last track listened to will start
to play.
It is advisable to use original CDs to ensure
optimum playback. If CD-R/RWs are used,
we recommend using good quality media
mastered at the slowest speed possible.
LOADING/EJECTING A CD
To load the CD, insert it gently into the slot
to activate the motorised loading system,
which will position it correctly.
The CD can be loaded with the radio
switched off and the ignition key in the MAR
position: in this case the radio will remain
off. When the car radio is turned on, the last
source listened to prior to switching off will
be activated.
When a CD is loaded the display will show
“CD-IN” and the words “CD Reading”. They
will rema
in displayed for the entire time re-
quired for the car radio to read the CD tracks.
When this time has elapsed the radio will
automatically start to play the first track. Press the
˚button with the car adio on to
activate the motorised ejection of the CD.
After ejection, the last audio source listened
to before playing the CD will be heard.
If the CD is not removed from the car ra-
dio, it will automatically be reloaded about
20 seconds later and the Tuner mode will
be tuned into (Radio).
The CD cannot be ejected if the car radio is
off.
If the ejected CD is loaded without having
removed it completely from the slot, the
radio will not switch to the CD source.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 273

274
SOUND SYSTEM
Possible error messages
If the CD loaded cannot be read (e.g. a CD
ROM has been inserted or the CD is insert-
ed the wrong way round or there is read-
ing error) the display will show the words
“CD Disc error”.
The CD will then be ejected and the audio
source activated prior to the CD mode selec-
tion will be heard.
With an external audio source activated (TA,
ALARM or Phone), the CD that cannot be
read will be not be ejected until these func-
tions have ended. At the end, with the CD
mode activated, the display will show the
words “CD Disc error” for a few seconds and
then the CD will be ejected.
DISPLAY INFORMATION
When the CD player is working, the display
will show the following information:
❍“CD Track 5”: indicating the number of
the CD track;
❍“03:42”: indicating the time elapsed
since the start of the track (if the rele-
vant Menu function is activated).
TRACK SELECTION
(forward/back)
Briefly press the button to play the pre-
vious CD track and the
button to play the
next track. The tracks are selected cyclical-
ly: the first track is selected after the last
track and vice versa.
If the track has been playing for more than
3 seconds, pressing
will cause the track
to start again from the beginning. In this
case, if you want to play the previous track,
press the button twice consecutively.
TRACK FAST FORWARD/
REWIND
Keep the button pressed down to fast for-
ward the selected track and keep the
but-
ton pressed down to fast rewind the track.
The fast forward/rewind will stop once the
button is released.
PAUSE FUNCTION
To pause the CD player, press the MUTE but-
ton. The words “CD Pause” will appear on
the display.
To resume listening to the track, press the
MUTE button again.
If another audio source is selected, the pause
function is turned off.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 274

275
SOUND SYSTEM
M M
P P
3 3

C C
D D

P P
L L
A A
Y Y
E E
R R
INTRODUCTION
This chapter describes the variants regard-
ing the operation of the MP3 CD player: as
far as the operation of the radio is con-
cerned, refer to the description in the “Func-
tions and Adjustments” and “CD player”
chapters.
NOTE MPEG Layer-3 audio decoding technol-
ogy licensed from Fraunhofer IIS and Thom-
son multimedia.
MP3 MODE
In addition to playing normal audio CDs, the
car radio is also capable of playing CD-ROMs
on which MP3 format compressed audio files
are recorded. The radio functions as de-
scribed in the “CD Player” chapter when an
ordinary audio CD is inserted.
The use of good quality media mastered at
the slowest possible speeds is recommend-
ed for optimum quality.
The files on the MP3 CD are in folders, with
sequential lists of all the folders containing
MP3 tracks (folders and sub-folders are all dis-
played on the same level) and folders that do
not contain MP3 tracks cannot be selected.The operating conditions and specificationsfor playing MP3 files are as follows:
❍the CD-ROMs used must be mastered in
compliance with the ISO9660 Standard;
❍the music files must have an “.mp3”
extension: files with a different exten-
sion cannot be played;
❍the following sampling frequencies can
be played: 44.1 kHz, stereo (96 to 320
kbit/s) - 22.05 kHz, mono or stereo
(32 to 80 kbit/s);
❍tracks with variable bit-rates can also be
played.
IMPORTANT The names of tracks must not
contain the following characters: spaces, ‘
(apostrophes), (and) (open and close brack-
ets). When an MP3 CD is being burned
make sure that the file names do not con-
tain these characters; otherwise, the car ra-
dio will not be able to play those tracks.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 275

276
SOUND SYSTEM
SELECTING MP3 SESSIONS ON
HYBRID DISCS
If a hybrid disc is inserted (Mixed Mode, En-
hanced, CD-Extra) also containing MP3 files,
the radio automatically starts playing the au-
dio session. It is possible to move to the
MP3 session whilst playing by keeping the
MEDIA button pressed for more than 2 sec-
onds.
IMPORTANT When the function is activated
the radio may take a few seconds to start
playback. Whilst checking the disc the dis-
play will show “CD READING”; if no MP3
files are detected, the radio will resume play-
ing the audio session from the point where
it was interrupted.
DISPLAY INFORMATION
ID3-tag information display
In addition to the information relating to the
time elapsed, the name of the folder and the
name of the file, the car radio is also capa-
ble of display ID3-TAG information relating
to the Track title, Artist and Author.
The name of the MP3 folder shown on the
display corresponds to the name with which
the folder was stored on the CD, followed
by an asterisk.
Example of a complete MP3 folder name:
BEST OF *.
If you wish to display ID3-TAG information
(Title, Artist, Album) and this information
has not been recorded for the track played,
the information will be replaced by informa-
tion relating to the name of the file.
SELECT NEXT/PREVIOUS
FOLDER
Press to select the next folder or to
select the previous folder. The display will
show the number and the name of the fold-
er (e.g. “DIR 2 XXXXXX”).
XXXXXX: name of the folder (the display
will only show the first 12 characters).
The folders are selected cyclically: the first
folder is selected after the last folder and
vice versa.
If no other folder/track is selected during
the next 2 seconds, the first track contained
in the new folder will be played.
If the last track on the folder currently se-
lected is being played, the next folder will
be played.
STRUCTURE OF THE FOLDERS
The car radio with MP3 player:
❍only recognises those folders that effec-
tively contain MP3 format files
❍if the MP3 files on a CD-ROM are struc-
tured in “sub-folders”, their structure is
compressed to a single level structure
where the “sub-folders” are at the level
of the main folders.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 276

TROUBLESHOOTING
GENERAL
Sound volume low
The Fader function should be adjusted to “F”
(front) values to prevent the reduction of ra-
dio output power and the cancelling of the
volume if the Fader level adjustment is R+9.
Source cannot be selected
Nothing has been loaded. Load the CD or
MP3 CD to be played.
CD PLAYER
The CD does not play
The CD is dirty. Clean the CD.
The CD is scratched. Try and use another CD.
The CD cannot be loaded
A CD is already loaded. Press ˚and remove
the CD.
MP3 FILE READING
Skips tracks whilst playing
MP3 files
The CD is scratched or dirty. Clean the CD,
referring to the contents of the “CD” para-
graph in the “Introduction” chapter.
The duration of the MP3
tracks is not correctly
displayed
In some cases (due to the recording mode)
the duration of the MP3 tracks may be dis-
played incorrectly.
277
SOUND SYSTEM
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 277
