2010 Acura TSX set clock

Once the security system is set,
opening any door (without using the
key or the remote transmitter), the
hood, or the trunk will cause the
alarm to activate. It will also activate
if the audio unit is removed f rom the
dashboard or the wiring is cut.
The security system automatically
sets 15 seconds after you lock the
doors, hood, and trunk. For the
system to activate, you must lock the
doors f rom the outside with the key,
driver’s lock tab, door lock master
switch, or remote transmitter. The
security system indicator on the
instrument panel starts blinking
immediately to show you the system
is setting itself . The security system helps to protect
your vehicle and valuables f rom thef t.
The horn sounds and a combination
of headlights, parking lights, side
marker lights and taillights f lashes if
someone attempts to break into your
vehicle or remove the audio unit.
This alarm continues for two
minutes, then the system resets. To
reset an activated system bef ore the
two minutes have elapsed, unlock
the driver’s door with the key or the
remote transmitter.
To enter the clock setting, turn
the selector knob to select ‘‘SET,’’
then press the knob. The display
will return to the menu item
display.
Press either the RETURN or
MENUbuttontogobacktothe
normal display.
11.
10. Security System
Setting the Clock, Security System
292
SECURITY SYSTEM INDICATOR
2010 TSX

Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (see
on page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
Start the engine, and set the
temperature to maximum heat
(climate control to AUTO at
‘‘ ’’). Add coolant to the
radiator up to the base of the f iller
neck. If you do not have the
proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and ref illed with
the proper mixture as soon as you
can.
If you don’t f ind an obvious leak,
check the coolant level in the
radiator reserve tank (see page
). Add coolant if the level is
below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the
temperature gauge or lower
bef ore checking the radiator.
7. 6.
8.
9. 10.
11.
482
353
Emergency
Towing
If theEngineOverheats
470
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
2010 TSX

...............
DANGER, Explanation of . iii
...................................
Dashboard .3, 58
..............
Daytime Running Lights . 114
.................................
Dead Battery .466
............
Def ects, Reporting Saf ety . 508
..............
Def ogger, Rear Window . 117
..............
Def rosting the Windows . 170
............................
Dimensions .488, 491
.............
Dimming the Headlights . 111
Dipstick ..........
Automatic Transmission . 423
..................................
Engine Oil .352
........................
Directional Signals .111
........
Disc Brake Wear Indicators . 383
.....................
Disposal of Used Oil .419
...................
Capacities Chart . 488,491
.............
Carbon Monoxide Hazard . 55
.............................
Carrying Cargo .359
.............
CAUTION, Explanation of . iii
.........................................
CD Care .256
...................................
CD Changer .244
.......................................
CD Player .189
........................
Certif ication Label .486
..................................
Ceiling Light .161
............................................
Chains .452
....................
Changing a Flat Tire .459
Changing Oil ........................................
How to .417
......................................
When to .403
...
Charging System Indicator . 61,471
............
Checklist, Bef ore Driving . 366
.....................................
Child Saf ety .36
..............................
Booster Seats .52
.............................
Child Seats .43, 44
Important Saf ety ..........................
Reminders .36-54
..........................................
Inf ants .41
..........................
Larger Children .51
.........................................
LATCH .46 ......................
Risks with Airbags .37
.............................
Small Children .42
..........................................
Tether .50
...........................
Warning Labels .56
..........
Where Should a Child Sit . 37
.......................................
Child Seats .36
.........................................
LATCH .46
..........
Tether Anchorage Points . 50
................
Childproof Door Locks . 125
................
Cleaning the Seat Belts . 441
..........
Client Service Inf ormation . 506
...............
Climate Control System . 166
..............................................
Clock .289
...................................
Clutch Fluid .428
..................
CO in the Exhaust . 55,500
....
Cold Weather, Starting in . 367,368
..............................
Compact Spare .458
.........................................
Compass .294
.................
Console Compartment . 156
.................
Consumer Inf ormation . 506
.............
Controls, Instruments and . 57
Coolant ........................................
Adding .420
....................................
Checking .353
.........................
Proper Solution .420
...................
Temperature Gauge . 69............................
Courtesy Lights .162
Crankcase Emissions Control ........................................
System .500
................
Cruise Control Indicator . 66
............
Cruise Control Operation . 298
.........................
Customer Service .506
.......................
Customized Settings .81
Index
D
C
II
2010 TSX

.....................................
Seat Belts .8, 19
...............
Additional Information . 19
Automatic Seat Belt ...............................
Tensioners .21
.....................................
Cleaning .441
................
Lap/Shoulder Belt . 15,20
................................
Maintenance .22
Reminder Indicator and ................................
Beeper .19, 60
...................
System Components . 19
...............
Use During Pregnancy . 17
...
Wearing a Lap/Shoulder Belt . 20
Seats ....................................
Adjusting .134
.......................................
Folding .138
.......................................
Heaters .141
............................
Security System .292
.....................
Selecting a Child Seat .43
.......
Selector Knob (Disc Player) . 175
..................
Sequential Shif t Mode . 379
..........................
Paddle Shif ters .377
...............................
Serial Number .486
..............................
Service Minder .403
.............................
Service Manual .509
.........
Service Station Procedures . 347
..........................
Setting the Clock .289 ...
Shif t Lever Position Indicators . 373
........................
Shif t Lock Release .375
................................
Side Airbags .9 ,29
...
How Your Side Airbags Work . 29
How the Side Airbag Of f ......................
Indicator Works .32
..................
Side Curtain Airbags . 9,31
How Your Side Curtain ..........................
Airbags Work .31
.............................
Signaling Turns .111
.....................................
Snow Tires .451
................................
Sound System .174
Spare Tire ......................................
Inf lating .458
....................
Specif ications .490, 493
............................
Spark Plugs .489, 492
........................
Specif ications .488, 491
................................
Speed Control .298
........................
Speed Limiter .371, 375
...................................
Speedometer .68
.......................................
Spotlights .161
..........
SRS, Additional Inf ormation . 23
...
Additional Safety Precautions . 34
.............................
Airbag Service .34
......
Airbag System Components . 23How the Passenger Airbag Of f
......................
Indicator Works .33
How the Side Airbag Of f ......................
Indicator Works .32
..
How the SRS Indicator Works . 31
How Your Front Airbags .......................................
Works .25
.
How Your Side Airbags Works . 29
How Your Side Curtain Airbags .........................................
Work .31
.............................
SRS Indicator .31 ,62
..
START (Ignition Key Position) . 123
Starting the Engine (4-cylinder ..................................
Models) .367
In Cold Weather at High ..................................
Altitude .367
................
With a Dead Battery . 466
Starting the Engine (6-cylinder ..................................
Models) .368
Check Starting System .................................
Message .369
In Cold Weather at High ..................................
Altitude .368
................
With a Dead Battery . 466
........
Steam Coming f rom Engine . 469
Index
VIII
2010 TSX
