Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk or pull a trailer, readjustment
may be required. Adjustments
should be done by your dealer or
another qualif ied technician.The low beam headlight bulbs are
high voltage discharge tube bulbs.
High voltage can remain in the
circuit even with the light switch of f
and the key removed. Because of
this, you should not attempt to
examine or change a low beam
headlight bulb yourself . If a low
beam headlight bulb fails, take the
vehicle to your dealer to have it
replaced.Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
f rom contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.
CONT INUED
High beam headlights on all models
Low beam headlights on Canadian TSXwith 4-cylinder engine
All models except Canadian TSX with
4-cylinder engine
Headlight Aiming L ow Beam Headlight Bulb
ReplacementReplacing a Headlight Bulb
Lights
Maint enance
429
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
2010 TSX

To change the passenger’s side
bulb, start the engine, turn the
steering wheel all the way to the
lef t, and turn of f the engine. To
change the driver’s side bulb, turn
the steering wheel to the right.Pull the inner f ender cover away
f rom the f ender and bumper.
Remove the cover on the back of
the headlight assembly by turning
the tab counterclockwise.
Use a f lat-tip screwdriver to
remove the holding clip f rom the
inner f ender, and remove the
screw with a Phillips-head
screwdriver.
3.
4.
1.
2.
Canadian TSX with 4-cylinder engine
L ow Beam Headlight
Lights
430
TAB
COVER
SCREW HOLDING CLIP
2010 TSX

Open the hood.
Insert the new bulb into the hole,
making sure the tabs are in their
slots.
Push the electrical connector onto
the new bulb. Make sure it is
connected securely.
Pivot the hold-down wire back in
place, and clip the end into the slot.
Reinstall the cover over the back
of the headlight assembly and turn
it clockwise to lock it in place.
Turn on the headlights to test the
new bulb.
Put the inner f ender cover in place.
Install the holding clip. Lock it in
placebypushingonthecenter.
Tighten the screw securely.
Remove the electrical connector
f rom the bulb by pulling the
connector straight back, then
remove the bulb. Unclip the end of the hold-down
wire f rom its slot. Pivot it out of
the way.
Tochangeabulbonthe
passenger’s side, remove the
engine coolant reserve tank by
pulling it out of its stay. Remove all engine compartment
covers (see page ).
1.
8. 7.
9.
10.
11.
12.
5.
6.
2.
3.414
CONT INUED
6-cylinder models
High Beam Headlights
Lights
Maint enance
431
STAY
4-cylinder models
2010 TSX

Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To remove the burned out bulb,
push it in and turn it
counterclockwise until it unlocks.
Use a f lat-tip screwdriver to
remove the holding clip f rom the
inner f ender, and remove the
screw with a Phillips-head
screwdriver.
Pull the inner f ender cover away
f rom the f ender and bumper.
To change the bulb on the driver’s
side, start the engine, turn the
steering wheel all the way to the
right, then turn of f the engine. To
change the bulb on the passenger’s
side, turn the steering wheel to the
lef t.
4.
5.
2.
1.
3.
Lights
Replacing a Front T urn Signal/
Parking and Side Marker Light
Bulb
434
SCREWHOLDING CLIP
2010 TSX

Check the condition of the battery
monthlybylookingatthetest
indicator window. The label on the
battery explains the test indicator’s
colors.
The location of the test indicator
window varies between
manuf acturers.Check the terminals f or corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f uture corrosion.
If additional battery maintenance is
needed, see your dealer or a
qualif ied technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
To see the battery label, remove the
lef t side engine compartment cover
(see page ).
414
CONT INUED
6-cylinder models
Checking the Battery
WARNING:
Wash your hands af ter handling.
Maint enance
453
TEST INDICATOR WINDOW TEST INDICATOR WINDOW
4-cylinder models 6-cylinder models
2010 TSX

If possible, periodically run the
engine until it reaches f ull
operating temperature (the
cooling f ans cycle on and of f
twice). Pref erably, do this once a
month. Support the f ront wiper blade
arms with a f olded towel or rag so
they do not touch the windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and trunk seals.
Cover the vehicle with a
‘‘breathable’’ cover, one made
f rom a porous material such as
cotton. Non-porous materials, such
as plastic sheeting, trap moisture,
which can damage the paint.
Leave the parking brake off. Put
the transmission in reverse
(manual) or Park (automatic).
Block the rear wheels.
If the vehicle is to be stored f or a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the vehicle is being stored
indoors).
Disconnect the battery.
Vehicle Storage
Maint enance
455
2010 TSX

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .458
....................
Changing a Flat Tire .459
.............
If the Engine Won’t Start . 464
................................
Jump Starting .466
..............
If the Engine Overheats . 469
.........
Low Oil Pressure Indicator . 471
..........
Charging System Indicator . 471
.......
Malf unction Indicator Lamp . 472
.........................
Readiness Code .472
...............
Brake System Indicator . 473
Opening the Fuel Fill Door ....................................
Manually .474
..............................................
Fuses .475
..............................
Fuse Locations .479
......................
Emergency Towing .482
Taking Care of the Unexpected
T aking Care of t he Unexpect ed
457
2010 TSX

When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all.
Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:
Check these things:
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See on page .
Check the transmission interlock.
If you have a manual transmission,
the clutch pedal must be pushed
all the way to the f loor or the
starter will not operate. With an
automatic transmission, it must be
in Park or neutral. Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit f or the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See
on page .
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is dis-
charged or the connections are
corroded. Check the condition of the
battery connections (see page ).
You can then try jump starting the
vehicle from a booster battery (see
page ).
466 466 482
453
Nothing Happens or the Starter
Motor Operates Very Slowly
Jump Starting Emergency T owing
If theEngineWon’tStart
464
