2010 Acura TL set clock

Î
Î
You can customize the door lock/
unlock settings (see page ).
Youcanopenorclosethewindows
and the moonroof by using the key
in the driver’s door (see page ).
To lock all doors, push the f ront of
the master door lock switch on
either f ront door, pull the lock tab
rearward on the driver’s door, or
turn the key counterclockwise in
the outside lock on the driver’s door. All doors can be locked f rom the
outsidebyusingthekeyinthe
driver’s door. To unlock only the
driver’s door, insert the key, turn it
clockwise, and release it. The
remaining doors unlock when you
turn the key a second time within a
f ew seconds.
Thebuilt-inkeycanbeusedtolock/
unlock the doors when the remote
battery becomes weak and the
power door lock/unlock operation is disabled. For more inf ormation, see
page .
When the door is unlocked, you can
seetheredindicatoronthelocktab
above the inner door handle. The lock tab on any passenger’s door
locks and unlocks that door. Pushing the rear of either master
door lock switch will unlock all doors.
Pushing f orward the lock tab on the
driver’s door unlocks only that door.
195
121200
On models with keyless accesssystem
Door L ocks
146
MASTER DOOR LOCK SWITCH
UnlockLock
LOCK TAB
RED INDICATOR
Unlock
Lock
09/07/29 17:06:45 31TK4610_151
2010 TL

The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them. The climate control system in your
vehicle provides a comfortable
driving environment in all weather
conditions.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to dis-
courage vandalism and thef t of your
vehicle................
Climate Control System . 216
Using Automatic Climate ...................................
Control .218 Dual Temperature and Mode
...................................
Control .222
..........
Climate Control Sensors . 224
................................
Audio System .225
................................
Audio System .226
..........
Playing the AM/FM Radio . 227
................
Playing the XM
Radio . 235
.................................
Playing Discs .241
...
Disc Changer Error Messages . 251
............................
PlayinganiPod
. 252
.................
iPod
Error Messages . 259
Playing a USB Flash Memory ........................................
Device .260
USB Flash Memory Device ........................
Error Messages .268
.............
Audio System . 269
................................
Audio System .273
..........
Playing the AM/FM Radio . 274
................
Playing the XM
Radio . 287
................................
Playing a Disc .295
.......
Disc Player Error Messages . 307
Playing Hard Disc Drive (HDD) ..........................................
Audio .308
............................
PlayinganiPod
. 338 .................
iPod
Error Messages . 346
Playing a USB Flash Memory ........................................
Device .347
USB Flash Memory Device ........................
Error Messages .358
.............
Audio System . 359
..................
Protecting Your Discs . 364
............
AM/FM Radio Reception . 368
................
Remote Audio Controls . 370
......................
Auxiliary Input Jack .371
.................
Radio Thef t Protection . 372
..........................
Setting the Clock .373
............................
Security System .376
.........................................
Compass .378
...............................
Cruise Control .382
HomeLink
Universal ................................
Transceiver .385
HandsFreeLink
(Models without navigation
..................................
system) .388
HandsFreeLink
(Models with navigation
..................................
system) .406
..
AcuraLink
(U.S. models only) . 425
...
Rearview Camera and Monitor . 441
Models without navigation system
BluetoothModels with navigation system Bluetooth
BluetoothBluetooth
Features
Features
215
09/07/29 17:18:54 31TK4610_220
2010 TL

Most audio system f unctions can be
controlled by standard buttons, bars,
and knobs. In addition, you can
access some f unctions by using the
selector knob on the audio system.The knob turns lef t and right. Use it
to scroll through lists, or to make
selections or adjustments to a list or
menu item on the display. When you
make a selection, push the center of
the selector (ENTER) to go to that
selection.
When the audio system is in XM
Radio mode or playing discs, pushing
the selector (ENTER) knob switches
the display between the normal
display and the extended display.
The extended display has three
segments to display the detailed
inf ormation.
To select any setting such as the
clock or sound adjusting, press the
SETUP button. To use any audio
system f unction, the ignition switch
must be in the ACCESSORY (I) or
ON (II) position. You can select the
item by turning the selector knob.
To go back to the previous display,
press the RETURN button.
Pressing the SETUP button again
will also cancel the setup display
mode.
When you unlock the doors with
your remote transmitter and turn the
audio system on with the ignition
switch in the ACCESSORY (I) or ON
(II) position, the driver’s ID (Driver
1orDriver2)isdetected,andthe
radio presets and sound level
settings (see page ) are turned to
the respective memorized mode
automatically.
233
Selector K nob
SET UP Display
Personalization Setting
Audio System (Models without navigation system)
226
RETURN
BUTTON SELECTOR
KNOBSETUP BUTTON
09/07/29 17:20:57 31TK4610_231
2010 TL

To set the time, press the CLOCK
button until you hear a beep. The
displayed time begins to blink.
Change the hours by pressing the H
(hour) button until the numbers
advance to the desired time. Change
the minutes by pressing the M
(minute) button until the numbers
advance to the desired time.
Press the CLOCK button again to
enter the set time.
You can quickly set the time to the
nearest hour. If the displayed time is
bef ore the half hour, press and hold
the CLOCK button, then press the R
(reset) button to set the time back to
the previous hour. If the displayed
time is af ter the half hour, the same
procedure sets the time f orward to
the beginning of the next hour.The navigation system receives
signals f rom the global positioning
system (GPS), and the displayed
time is updated automatically by the
GPS. Ref er to the navigation system
manual f or how to adjust the time.
1:06 would RESET to 1:00.
1:52 would RESET to 2:00.
For example:
On models with navigation system
On models without navigation system
CONT INUED
Setting the Clock
Features
373
On models without navigation system
CLOCK BUTTONRESET BUTTON
(PRESET 6)
HOUR BUTTON
(PRESET 4) MINUTE BUTTON
(PRESET 5)
09/07/29 17:55:58 31TK4610_378
2010 TL

Ú
You can also adjust the clock and
switch the clock display between 24-
hours and 12-hours in the menu
mode.
To adjust the clock setting:
You can adjust the clock setting
with the ignition switch in the
ACCESSORY (I) or ON (II)
position. Press and release the SETUP
button. The display shows you the
menu items. Turn the selector knob to select
‘‘CLOCK ADJUST.’’
Press the selector knob (ENTER)
to enter your selection. The
display changes to the clock
adjusting display.Turn the selector knob to select
the item which you want to adjust.
Turning the selector knob will
change the selected item between
the clock display setting, hours,
minutes, and SET. The selected
item is indicated with in the
display.
1.
2.
3.4.
On models without navigation system
Setting the Clock
A djust ing t he Clock wit h SET UP
Button
374
09/07/29 17:56:09 31TK4610_379
2010 TL

Turn the selector knob to change
the setting between 12H and 24H.
Press the selector knob (ENTER)
to enter your selection. The
display will return to the clock
adjusting display.To set the time, turn the selector
knob and select the hours or the
minutes, then press the knob to
enter your selection. The display
changes to the setting display.
Turn the selector knob to count
the numbers up or down.
Press the selector knob (ENTER)
to enter your selection. The
display will return to the clock
adjusting display.While setting the clock, pressing
the RETURN button will go back
to the previous display.
Pressing the SETUP button again
will cancel this setting mode.
5.
6. 7.
8.
9.
CONT INUED
Setting the Clock
Features
375
MINUTE SETTING
09/07/29 17:56:21 31TK4610_380
2010 TL

The security system helps to protect
your vehicle and valuables f rom thef t.
The horn sounds and a combination
of headlights, parking lights, side
marker lights and taillights f lash if
someone attempts to break into your
vehicle or remove the audio unit.
This alarm continues f or 2 minutes,
then the system resets. To reset an
activated system before the 2
minutes have elapsed, unlock the
driver’s door with the key or use the
remote transmitter/keyless access
remote.
You can also turn off an activated
system by grabbing either f ront door
handle while carrying the keyless
access remote to unlock the door.
To enter the clock setting, turn
the selector knob to select ‘‘SET,’’
then press the knob. The display
will return to the menu item
display.
Press either the RETURN or
SETUPbuttontogobacktothe
normal display. The security system automatically
sets 15 seconds after you lock the
doors, hood, and trunk. For the
system to activate, you must lock the
doors f rom the outside with the key,
driver’s lock tab, master door lock
switch, or remote transmitter
(keyless access remote on models
with keyless access system). The
security system indicator on the
instrument panel starts blinking
immediately to show you the system
is setting itself .
11. 10.
On models with keyless access system
Setting the Clock, Security System
Security System
376
SECURITY SYSTEM INDICATOR
A/T model is shown.
09/07/29 17:56:31 31TK4610_381
2010 TL

Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.Start the engine. If you are
replacing a driver’s side bulb, turn
the steering wheel all the way to
theright.If youarereplacinga
passenger’s side bulb, turn the
steering wheel to the lef t. Turn of f
the engine.
Remove the bulb by pulling it
straight out of its socket. Install the new bulb in the socket
by pushing it straight in the socket
until it bottoms.
Insert the socket into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Push the under cover in place and
set the spoiler and inner f ender
cover in the original position.
Install the bolts and tighten them
securely. Put the holding clip, and
lock it by pushing on its center.
4.
5. 6.
7.
8.
1.
9. Replacing a Front T urn Signal/
Parking L ight Bulb
Lights
524
SOCKET
BULB
09/07/29 18:31:06 31TK4610_529
