Your vehicle still has normal f ront-
wheel drive with vehicle stability
assist (VSA), but does not have the
advantages of SH-AWD. Have your
vehicle checked by a dealer as soon
as possible.
If the SH-AWD indicator begins to
blink while driving, it indicates the
dif f erential temperature is too high.
You will also see an ‘‘SH-AWD DIFF
TEMP. HIGH’’ message on the
multi-inf ormation display. If this happens, pull to the side of the
road when it is safe, park the vehicle
and shift to Park (automatic), and let
the engine idle until the indicator
goes out. If the indicator does not go
out, take your vehicle to a dealer to
have it checked.
If the SH-AWD indicator on the
instrument panel stays on, and the
‘‘CHECK SH-AWD SYSTEM’’
message also appears on the multi-
inf ormation display, there is problem
with the SH-AWD system.
Super Handling-A ll Wheel Drive (SH-A WD)System
Driving
479
TM
09/07/29 18:23:30 31TK4610_484
2010 TL

Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly, or
your vehicle may roll if it is parked
on an incline.
If your vehicle has an automatic
transmission, set the parking brake
bef ore you put the transmission in
Park. This keeps the vehicle f rom
moving and putting pressure on the
parking mechanism in the
transmission.Make sure the moonroof and the
windows are closed.
Turn of f the lights.
Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors.
Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire. Check the indicator on the
instrument panel to verif y that the
security system is set.
If the vehicle is f acing uphill, turn
the front wheels away from the
curb. If your vehicle has a manual
transmission, put it in f irst gear.If the vehicle is f acing downhill,
turn the front wheels toward the
curb. If your vehicle has a manual
transmission, put it in reverse gear.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes.
If you are unable to stop the
engine normally when the vehicle is
parked(intheParkpositiononthe
automatic transmission models), see on page
.
186
On models with keyless access system
Parking T ips
Emergency Engine Stop
Parking
480
NOTE:
09/07/29 18:23:42 31TK4610_485
2010 TL

Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The emergency
brake assist system increases the
stopping f orce when you depress the
brake pedal hard in an emergency
situation. The anti-lock brake system
(ABS) helps you retain steering
control when braking very hard.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, reduces their ef f ectiveness and
reduces brake pad lif e. In addition,
f uel economy can be reduced. It also
keeps your brake lights on all the
time, conf using drivers behind you.Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear.
Check your brakes af ter driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious and alert in your driving.
The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.If the brake pads need replacing, you
will hear a distinctive, metallic
screeching sound when you apply
the brake pedal. If you do not have
the brake pads replaced, they will
screech all the time. It is normal f or
the brakes to occasionally squeal or
squeak when you apply them. All f our brakes have audible brake
wear indicators.
Braking System Design Brake Pad Wear Indicators
Braking System
Driving
481
09/07/29 18:23:53 31TK4610_486
2010 TL

Î
Î
The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surf aces. It does this
by regulating the engine’s output,
and by selectively applying the
brakes.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. There may also
be some noise f rom the VSA
hydraulic system. You will also see
the VSA activation indicator blink.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety. When VSA is off, the VSA off
indicator comes on as a reminder.
When VSA activates, you will see the
VSA system indicator blink.
If this indicator comes on while
driving, you will also see a ‘‘CHECK
VSA SYSTEM’’ and/or ‘‘CHECK
HILL START ASSIST SYSTEM’’
message on the multi-inf ormation
display. Drive cautiously as the VSA
may not be f unctioning. Without
VSA, your vehicle will have normal
braking and cornering ability, but it
will not have VSA traction and
stability enhancement. Also, the VSA
OFF switch will not operate. Pull to
the side of the road when it is saf e,
and turn of f the engine. Reset the
system by restarting the engine. If
the VSA system indicator stays on,have the VSA system inspected by
your dealer.
If the indicator does not come on
when the ignition switch is turned
to the ON (II) position, there may be
a problem with the VSA system.
Have your dealer inspect your
vehicle as soon as possible.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pagesand .
The main f unction of the
VSA system is generally known as
Electronic Stability Control (ESC).
The system also includes a traction
control f unction. :
178 181
Vehicle Stability Assist
(VSA ) System Indicator VSA Of f Indicator
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
484
NOTE:
09/07/29 18:24:26 31TK4610_489
2010 TL

This switch is under the driver’s side
vent. To turn the VSA system on and
of f , press and hold it until you hear a
beep.
When VSA is off, the VSA off
indicator comes on as a reminder.
Press and hold the switch again. It
turns the system back on.
If the low tire pressure/TPMS
indicator comes on (see page ),
or the multi-information display
shows a ‘‘CHECK TPMS SYSTEM’’
message with the indicator flashing
(see page ), the VSA system
automatically turns on even if the
VSA system is turned off with the
VSA OFF switch. In this case, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
If there is a problem with the hill
start assist system, the VSA system
indicator comes on and stays on. The
multi-inf ormation display shows a
‘‘CHECK HILL START ASSIST
SYSTEM’’ message.
With the VSA system indicator on,
you may not be able to stop the
engine even if you park the vehicle
saf ely. To stop the engine, see
on page
.
186 487
491
CONT INUED
On models with SH-AWD
On models with keyless access systemVSA OFF Switch
Emergency Engine Stop
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
Driving
485
VSA OFF SWITCH
09/07/29 18:24:36 31TK4610_490
2010 TL

Hillstartassistmaynotpreventyour
vehicle f rom rolling downhill on a
very steep or slippery slope, and will
not operate on small inclines.
Hill start assist is not a replacement
f or the parking brake. If parking
your vehicle, ensure that the
transmission is in park, and/or the
parking brake is f ully applied bef ore
exiting the vehicle. For vehicles with
manual transmission, it is
recommended that you turn of f the
engine bef ore exiting the vehicle.If the VSA system indicator comes
on with a ‘‘CHECK HILL START
ASSIST SYSTEM’’ message on the
multi-inf ormation display, there may
be a problem with the hill start assist.
The VSA also may not f unction.
Have your vehicle inspected by your
dealer.
Hill start assist will still operate even
when VSA is switched off.
On manual transmission models:
You must come to a complete stop,
press the clutch pedal, and shif t to
f irst gear when f acing uphill, or
reverse when f acing downhill.
Release the brake pedal. The brakes
remain engaged brief ly to keep the
vehicle f rom rolling f orward or
backward while you move your f oot
f rom the brake pedal to the
accelerator pedal. Gently apply the
accelerator pedal while
simultaneously releasing the clutch
pedal, as in normal driving. Hill start
assist will release brake pressure
gradually as you accelerate.
Hill start assist will also hold braking
brief ly if you select the neutral gear
position with the clutch pedal
depressed when f acing uphill.
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
Driving
487
09/07/29 18:24:54 31TK4610_492
2010 TL

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure shown on the driver’s
doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message. It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible. 547
Low Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
488
09/07/29 18:25:05 31TK4610_493
2010 TL

Î Each tire pressure is shown in PSI
(U.S. models) or in kPa (Canadian
models).If any of the tires has low pressure,
thetirepressuremonitoralsoshows
the above message and each tire
pressure to warn you about the low
tire pressure when you select the
displaybypressingtheINFObutton
several times.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
178 181
Tire Pressure Monitoring System (TPMS)
490
Canadian model U.S. model Canadian model
09/07/29 18:25:27 31TK4610_495
2010 TL
