2010 Acura TL service indicator

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure shown on the driver’s
doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message. It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible. 547
Low Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
488
09/07/29 18:25:05 31TK4610_493
2010 TL

Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare
tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Each wheel is equipped with a tire
pressure sensor mounted inside the
tire behind the valve stem. You must
use TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
a qualif ied technician.
If you have a f lat tire, the low tire
pressure/TPMS indicator and tire
monitor indicator will come on.
Replace the indicated f lat tire with
thecompactsparetire(seepage
).
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct. If the low tire pressure/TPMS
indicator and the low tire position on
the low tire pressure monitor do not
go out af ter inf lating the tires to the
specified values, have your dealer
check the system as soon as possible.
547
Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS)
492
09/07/29 18:25:46 31TK4610_497
2010 TL

Î
Î
CONT INUED
Your vehicle displays engine oil lif e
and maintenance service items on
the multi-information display to show
youwhenyoushouldhaveyour
dealer perf orm engine oil
replacement and indicated
maintenance service.To see the current engine oil lif e
displayed on the multi-inf ormation
display, turn the ignition switch to
the ON (II) position, and press the
SEL/RESET button on the steering
wheel repeatedly until the engine oil
lif e is displayed. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
Based on the engine operating
conditions, the onboard computer in
your vehicle calculates the remaining
engine oil lif e and displays it as a
percentage. :
178 181
Maintenance Minder
Engine Oil L if e Indicator
Maint enance
497
REMAINING ENGINE OIL LIFE
U.S. model is shown.
09/07/29 18:26:24 31TK4610_502
2010 TL

ÛÝ
Î
Î
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
Pressing either INFO button ( / )
switches the display f rom the
message to another display. Once
you switch the display, this message
will go of f .
Along with the message, the system
message indicator comes on (see
page ).
When the remaining engine oil lif e is
15 to 6 percent, the multi-inf ormation
display shows a ‘‘SERVICE DUE
SOON’’ message along with the
maintenance item code(s) indicating
themainandsubitemsrequiredat
thetimeof theoilchange.Referto
page f or a complete list of the
maintenance main items and sub
items.
The remaining engine oil lif e is
shown on the multi-inf ormation
display according to this table:
The message appears on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pagesand .
72
: 178 181
506
Calculated Engine
Oil Lif e (%)
100 % 91 % 90 % 81 %
80 % 71 %
70 % 61 %
60 % 51 %
50 % 41 %
40 % 31 %
30 % 21 %
20 % 16 %
15 % 11 %10 % 6 % 5% 1% 0% Displayed
Engine Oil Lif e (%) 100 %90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
15 %
10 %5%
0%
Maintenance Minder
498
MAINTENANCE MAIN ITEM CODE
MAINTENANCE SUB ITEM CODE(S)
09/07/29 18:26:35 31TK4610_503
2010 TL

Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning indicators.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(seeon page
).
Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
Go to a service station or garage
where you can get technical
assistance. If the charging system indicator
comes on brightly when the engine
is running, the battery is not being
charged.
This indicator should never come on
when the engine is running. If it
starts flashing or stays on, the oil
pressure has dropped very low or
lost pressure. Serious engine
damage is possible, and you should
take immediate action.
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message on
the multi-information display when
this indicator comes on. You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
1.
2.
3.
4.
448
570 509
Emergency T owing Charging System
Indicator
L ow Oil Pressure
Indicator
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
559
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
09/07/29 18:37:20 31TK4610_564
2010 TL

Î
ÎIf the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads.
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal. You will also see a ‘‘LOW BRAKE
FLUID’’ message on the multi-
inf ormation display.
You will also see a ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display when this
indicator comes on.
To check if they are set, turn the
ignition switch to the ON (II)
position (set the power mode to ON,
on models with keyless access
system), without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks f ive times, the readiness
codes are not set. If possible, do not
take your vehicle f or an emissions
test until the readiness codes are set.
Refer to
for
more information (see page ). Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ). The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and
as a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake. :
178 181
590
519
CONT INUED
Malf unction Indicator L amp, Brake System Indicator
Brake System
Indicator
Emissions T esting
T aking Care of t he Unexpect ed
561
Canada
U.S.
09/07/29 18:37:42 31TK4610_566
2010 TL

Î
Î
...............
DANGER, Explanation of . iii
...................................
Dashboard .3, 62
..............
Daytime Running Lights . 136
.................................
Dead Battery .555
.........
Def ects, Reporting Saf ety . 596
..............
Def ogger, Rear Window . 139
..............
Def rosting the Windows . 221
....................................
Dimensions .578
.............
Dimming the Headlights . 133
Dipstick ..........
Automatic Transmission . 515
..................................
Engine Oil .448
........................
Directional Signals .133
........
Disc Brake Wear Indicators . 481
.................................
Disc Changer .241
...
Disc Changer Error Messages . 251
.....................
Disposal of Used Oil .512
............................
Capacities Chart .578
.............
Carbon Monoxide Hazard . 57
............................
Carrying, Cargo .455
.............
CAUTION, Explanation of . iii
.........................................
CD Care .364
...................................
CD Changer .241
.......................................
CD Player .295
........................
Certif ication Label .576
............................................
Chains .541
....................
Changing a Flat Tire .547
Changing Oil ........................................
How to .510
......................................
When to .497
...
Charging System Indicator . 65,559
............
Checklist, Bef ore Driving . 460
.....................................
Child Saf ety .37
..............................
Booster Seats .54
...................................
Child Seats .45
..........................................
Inf ants .42
............................
Large Children .53
.........................................
LATCH .47
......................
Risks with Airbags .38
.............................
Small Children .43
.........................................
Tethers .51 .....................
Warning Labels .39, 59
.........
Where Should a Child Sit? . 38
.......................................
Child Seats .45
.........................................
LATCH .47
..........
Tether Anchorage Points . 51
................
Childproof Door Locks . 147
................
Cleaning the Seat Belts . 530
..........
Client Service Inf ormation . 594
.......
Climate Control System . 216,217
..........................
On/Off Button .219
..............................................
Clock .373
...................................
Clutch Fluid .520
..................
CO in the Exhaust . 57,588
....
Cold Weather, Starting in . 461,463
......................
Compact Spare Tire .546
.........................................
Compass .378
.................
Console Compartment . 208
...............
Consumer Inf ormation . 594
.............
Controls, Instruments and . 61
Coolant ........................................
Adding .512
....................................
Checking .449
.........................
Proper Solution .512
...................
Temperature Gauge . 76
........
Water Temp Hot Message . 76Crankcase Emissions Control
........................................
System .587
................
Cruise Control Indicator . 72
............
Cruise Control Operation . 382
...................................
Cup Holders .206
.............
Customer Service Of f ice . 594
Index
D
C
II
09/07/29 18:43:43 31TK4610_605
2010 TL

ÎÎ..................................
Saf ety Belts .8, 20
.........
Safety Defects, Reporting . 596
.................................
Saf ety Features .7
...........................................
Airbags .9
.......................................
Seat Belts .8
.............
Saf ety Labels, Location of . 59
..............................
Saf ety Messages .iii
.....................................
Seat Belts .8, 20
...............
Additional Information . 20
Automatic Seat Belt ...............................
Tensioners .22
.....................................
Cleaning .530
......................
Lap/Shoulder Belt .21
................................
Maintenance .23
Reminder Indicator and ................................
Beeper .20, 64
...................
System Components . 20
...............
Use During Pregnancy . 18
..................................
Seat Heaters .196
......................
Seats, Adjusting the .155
............................
Security System .376
.....................
Selecting a Child Seat .45
...
Selector Knob (Disc Changer) . 226
..................
Sequential Shif t Mode . 475...............................
Serial Number .576
..............................
Service Minder .497
...........................
Service Manual .597
.........
Service Station Procedures . 445
..........................
Setting the Clock .373
........................
SH-AWD
Indicator .73
...
Shif t Lever Position Indicators . 468
........................
Shif t Lock Release .471
................................
Side Airbags .9 ,30
........
Side Airbag Of f Indicator . 33,67
......................
Side Curtain Airbags .32
.............................
Signaling Turns .133
.....................................
Snow Tires .541
................................
Sound System .225
Spare Tire ......................................
Inf lating .546
............................
Specif ications .546
....................................
Spark Plugs .579
................................
Specif ications .578
................................
Speed Control .382
...................................
Speedometer .75
..........
SRS, Additional Inf ormation . 24
...
Additional Safety Precautions . 36
.............................
Airbag Service .35
......
Airbag System Components . 24How the Passenger Airbag Of f
......................
Indicator Works .34
How the Side Airbag Of f ......................
Indicator Works .33
How the SRS Indicator .......................................
Works .32
How Your Front Airbags .........................................
Work .26
...
How Your Side Airbags Work . 30
How Your Side Curtain Airbags .........................................
Work .32
.............................
SRS Indicator .32 ,67
..
START (Ignition Key Position) . 145
......
START Mode (Power Mode) . 178
...
Start/Stop Button, Engine . 177,182
..............
Starting the Engine . 461,463
....
Check Starting System . 462,464
In Cold Weather at High ..........................
Altitude .461, 463
................
With a Dead Battery . 555
........
Steam Coming f rom Engine . 557
Steering Wheel ..............................
Adjustments .140
...
Anti-thef t Column Lock . 145,183
Steering Wheel ..............
Buttons . 370,382,388,406
Index
S
VIII
09/07/29 18:44:22 31TK4610_611
2010 TL
