Technical data
* The kerb weight is equal to the unladen weight + driver (75 kg). ** The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning, towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude. The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country). High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
WEIGHTS AND TOWED LOADS (in kg)
Diesel engine2.2 litre Turbo HDi 200 hp
Gearbox Automatic (6 -speed)
Model codes 8D4HLA 8E4HLA
Outline Saloon SW
- Unladen weight 1 540 1 660
- Kerb weight * 1 615 1 735
- Gross vehicle weight (GV W) 2 155 2 280
- Gross train weight (GTW) on a 12% gradient 3 755 3 880
- Braked trailer (within GTW limit) on a 10 % or 12 % gradient 1 700 1 600
- Braked trailer ** (with load transfer with the GTW limit) 1 875 1 900
- Unbraked trailer 750
- Recommended nose weight 75
10
227
i
Technical data
I d e n t i fi c a t i o n m a r k i n g s
A. Vehicle Identification Number (VIN) under the bonnet.
This number is engraved on the bodywork near the damper suppor t.
The inflation pressures must be checked when the tyres are cold, at least once a month.
If the inflation pressures are too low, this increases fuel consumption. B. Vehicle identification Number (VIN) on the windscreen lower crossmember. This number is indicated on a self-adhesive label which is visible through the windscreen.
C. Manufacturer's label. The VIN is indicated on a self-destroying
label affixed to the door aper ture, on the right-hand side.
D. Tyre/paint label. This label is affixed to the door aper ture, on the driver's side.
It bears the following information: - the tyre inflation pressures with and without load, - the wheel rim and tyre sizes, - the brands of tyre recommended by the manufacturer, - the inflation pressure of the spare wheel,
- the paint colour code.
