2010.5 Citroen DS4 display

343
1
2
1
04
AUDIO
Press SOURCE several times in succession and select radio.
Press BAND to select a waveband among: FM1, FM2, DAB (digital radio), AM.
Press LIST to display the list of stations received in alphabetical order.
A press changes to the next or previous letter (e.g. A, B, D, F, G, J, K, …).
RADIO
Select the desired radio station and confi rm by pressing OK .
SELECTING A STATION
A long press on LIST builds or updates the list of stations; audio reception is cut momentarily.
The exterior environment (hills, buildings, tunnel, car park,
below ground…) may prevent reception, even in RDS station tracking mode. This phenomenon is normal in the propagation of radio waves and is in no way indicative of a fault with the audio system.

344
1
2
04
1
1
2
RDS, if displayed, enables you to continue listening to the same station by automatic retuning to alternative frequencies. How ever, in certain conditions, coverage of an RDS station may not be assured throughout the country as radio stations do not cover 100 % of the territory. This explains the loss of reception of the station during a journey.
AUDIO
RDS RECEIVING TA MESSAGES
The TA (Traffi c Announcement) function gives priority to TA alert messages. To operate, this function needs good reception of a radio station transmitting this type of message. When a traffi c report is transmitted, the current audio source (Radio, CD, USB, …) is interrupted automatically to play the TA message. Normal playback of the audio source resumes at the end of the transmission of the message.
Press TA INFO to activate or deactivate the reception of traffi c messages. When the radio is displayed on the screen, press OK to display the contextual menu.
Select " RDS " or " DAB/FM auto tracking " and confi rm to save.
" RDS " or " DAB/FM " is displayed on the screen.
DIGITAL RADIO - DAB/FM AUTO TRACKING
DAB/FM auto tracking allows you to continue listening to the same station, by temporarily switching to the equivalent analogue station until the digital signal is stable again.
The INFO function gives priority to TA alert messages. To be active, this function needs good reception of a radio station that transmits this type of message. When a message is transmitted, the current audio source (Radio, CD, USB, …) is interrupted automatically to receive the INFO message. Normal play resumes automatically to receive the INFO message. Normal play resumes at the end of the message transmission.
Make a long press on TA INFO to display the list of categories.
DIGITAL RADIO - LISTENING TO
INFO MESSAGES
Select or deselect categories to activate or deactivate the reception of the corresponding messages.

345
1
2
04AUDIO
Radio text is information transmitted by the radio station related to the current programme or song.
With the radio displayed on the screen, press OK to display the contextual menu.
Select " RadioText (TXT) display " and confi rm OK to save.
DISPLAY RADIO TEXT
Screen C

348
04
1
3
2
4
5
CD, USB
AUDIO
PLAYING A COMPILATION
Insert an MP3 compilation in the CD player or connect a memory stick to the USB port, directly or via an extension lead.
The system creates playlists (temporary memory) the creation time for which can take from a few seconds to several minutes.
The playlists are updated every time the ignition is switched off or a USB memory stick is connected.
Play starts automatically after a period which depends on the capacity of the USB memory stick.
At a fi rst connection, the order suggested is by folder. When connecting again, the order previously chosen is retained.
To play a disc or memory stick which has already been inserted, press SOURCE several times in succession and select " CD " or " USB ".
Press one of the buttons to select the next or previous track.
Press one of the buttons to select the next or previous folder in the order chosen.
Press and hold one of the buttons for fast forwards or backwards.
Press LIST to display the menu of folders in the compilation.

349
7
6
8
9
2
1
04
Select a line in the list.
Select a track or a folder.
Jump a page.
Up a level in the menu.
AUDIO
USB MEMORY STICK - FILE CLASSIFICATION
Having selected the desired classifi cation (" By folders ", " By artists ", " By genres ", " By playlists ") press OK .
Then confi rm OK to save the modifi cations.
- By folders : all folders containing audio fi les recognised on the peripheral device, in alphabetical order without following the folder structure.
- By artists : all of the artist names defi ned in the ID3 Tags, in alphabetical order.
- By genres : all of the genres defi ned in the ID3 Tags.
- By playlists : if playlists have been saved.
Make a long press on LIST or press MENU , select " Multimedia ", then " Media parameters " and fi nally " Choice of track listing " to display the different classifi cations.

356
1
2
3
4
05
5
USING THE TELEPHONE
The telephone connection automatically includes hands free operation and audio streaming.
Press MENU .
Select " Bluetooth connection " and confi rm.
Indicates connection of the audio steaming profi le.
MANAGING CONNECTIONS
Select " Connections management " and confi rm. The list of paired telephones is displayed.
Select a telephone and confi rm.
Indicates connection of the hands-free profi le.
Then select and confi rm:
- " Connect telephone "/" Disconnect telephone ": to connect/disconnect the telephone or the hands-free connection only.
- " Connect media player "/Connect media player" Disconnect media player ": to Disconnect media playerconnect/disconnect only streaming.
- " Connect telephone + media player "/" playerDisconnect telephone + media player ": to connect/disconnect media playerthe telephone (hands-free and streaming).
- " Delete connection ": to delete the pairing.
Indicates that a device is connected.

357
1
2
1
4
2
33
05
USING THE TELEPHONE
To display the " TELEPHONE " menu:
- Make along press on SOURCE .
- Or, press OK to display the contextual OKmenu. Select " Call " and confi rm.
- Or, press MENU , select " Telephone " and confi rm. Select " Call " and confi rm.
Select " Dial " to enter a number and confi rm.
Repeat the previous step 1 to display the " TELEPHONE " menu.
Select OK and confi rm to start the call.
Select " Calls list " and confi rm.
MAKING A CALL - DIALLING
Select numbers one at a time using the  and  buttons and confi rm.
MAKING A CALL - RECENTLY CALLED
NUMBERS *
Select the number and confi rm to start the call.
The calls list includes calls sent and received in the vehicle
using the connected telephone.
* Depending on the compatibility of the telephone.
Correction allows numbers to be deleted one at a time.

358
1
2
1
4
2
3
05 USING THE TELEPHONE
Repeat the previous step 1 to display the " TELEPHONE " menu.
Select " Directory " and confi rm.
An incoming call is announced by a ring and a superimposed display in the multifunction screen.
Mobile
(depending on the information available in the contact records of the telephone connected).
" YES " " " to accept the call is selected by default.
Press OK to accept the call.
Select " NO " and confi rm to reject the call.
or
Press SOURCE to accept the call.
MAKING A CALL - FROM THE DIRECTORY
Select a contact then confi rm.
RECEIVING A CALL
Select the number and confi rm.
A long press on ESC or on SOURCEalso rejects an incoming call.
Business
Home
