2010.5 Citroen DS4 DAG engine

Access
Misfuel prevention
Mechanical device which prevents filling the tank of a Diesel vehicle with petrol. It avoids the risk of engine damage that can result from filling with the wrong fuel. Located in the filler neck, the misfuel prevention device appears when the filler cap is removed.
When a petrol filler nozzle is introduced into the fuel filler neck of your Diesel vehicle, it comes into contact with the flap. The system remains
closed and prevents filling. Do not persist but introduce a Diesel type filler nozzle.
Operation
It is still possible to use a fuel can to fill the reser voir. In order to ensure a good flow of fuel, do not place the nozzle of the fuel can in direct contact with the flap of the misfuel prevention device.
This equipment will become available during the year.

123Visibility
Switching off the lighting when switching off the ignition
When the ignition is switched off, all of the lamps switch off immediately, except for the dipped beam headlamps if automatic guide-me-home lighting is activated.
Temporarily keeping the dipped beam headlamps on after the vehicle's ignition has been switched off makes the driver's exit easier when the light is poor.
Switching on
 With the ignition off, "flash" the headlamps using the lighting stalk.  A fur ther "headlamp flash" switches the function off.
Switching off
The manual guide-me-home lighting switches off automatically after a set time.
Manual guide-me-home
lighting
Daytime lighting, compulsory in cer tain countries, which comes on automatically when the engine is star ted making the vehicle more visible to other users.
This function is assured:
- in countries where it is imposed by regulations, by illumination of the dipped beam headlamps associated with illumination of the sidelamps and number plate lamps. - for other countries where it is provided, by illumination of dedicated lamps associated with illumination of the sidelamps and number plate lamps.
The instruments and controls (multifunction screen, air conditioning control panel, ...) are not illuminated, except in night mode with manual or automatic illumination of headlamps.
Daytime running lamps
This function can be activated or deactivated via the vehicle configuration menu.
Switching on the lighting when switching on the ignition
To reactivate the lighting control stalk, turn the ring A to position A"0" - lighting off, then to the position of your choice. If the lighting is switched on manually after
switching off the ignition, there is an audible signal when a front door is opened to warn the driver that they have forgotten to switch off the vehicle's lighting, with the ignition off. They switch off automatically after a period which depends on the state of charge of the battery (entry to energy economy mode).

123Visibility
Switching off the lighting when switching off the ignition
When the ignition is switched off, all of the lamps switch off immediately, except for the dipped beam headlamps if automatic guide-me-home lighting is activated.
Temporarily keeping the dipped beam headlamps on after the vehicle's ignition has been switched off makes the driver's exit easier when the light is poor.
Switching on
 With the ignition off, "flash" the headlamps using the lighting stalk.  A fur ther "headlamp flash" switches the function off.
Switching off
The manual guide-me-home lighting switches off automatically after a set time.
Manual guide-me-home
lighting
Daytime lighting, compulsory in cer tain countries, which comes on automatically when the engine is star ted making the vehicle more visible to other users.
This function is assured:
- in countries where it is imposed by regulations, by illumination of the dipped beam headlamps associated with illumination of the sidelamps and number plate lamps. - for other countries where it is provided, by illumination of dedicated lamps associated with illumination of the sidelamps and number plate lamps.
The instruments and controls (multifunction screen, air conditioning control panel, ...) are not illuminated, except in night mode with manual or automatic illumination of headlamps.
Daytime running lamps
This function can be activated or deactivated via the vehicle configuration menu.
Switching on the lighting when switching on the ignition
To reactivate the lighting control stalk, turn the ring A to position A"0" - lighting off, then to the position of your choice. If the lighting is switched on manually after
switching off the ignition, there is an audible signal when a front door is opened to warn the driver that they have forgotten to switch off the vehicle's lighting, with the ignition off. They switch off automatically after a period which depends on the state of charge of the battery (entry to energy economy mode).

Visibility
Windscreen and headlamp
wash
 Pull the windscreen wiper stalk towards you. The windscreen wash then the windscreen wipers operate for a fixed period. The headlamp washers only operate when the dipped beam headlamps are on .
Low screenwash/headlamp wash level
The low level of this fluid is indicated by gauge in the reser voir filler neck under the bonnet. Checking and topping up this fluid can only be done when stationary with the engine off.
On vehicles fitted with headlamp washers, the driver should check the level of this fluid regularly, par ticularly during winter.
Refer to "Checks - § Screenwash/headlamp
wash level" for the procedure on checking the level.

1. Front cour tesy lamp
2. Front map reading lamps3. Rear cour tesy lamp4. Rear map reading lamps
Courtesy lamps
In this position, the cour tesy lamp comes on gradually:
Front and rear courtesy lamps
- when the vehicle is unlocked, - when the key is removed from the ignition, - on opening a door, - when the remote control locking button is used to locate your vehicle.
It switches off gradually: - when the vehicle is locked, - when the ignition is switched on, - 30 seconds after the last door is closed.
Permanently off.
Permanent lighting.
In permanent lighting mode, the lighting time varies according to the circumstances: - with the ignition off, approximately ten minutes, - in energy economy mode, approximately thir ty seconds, - with the engine running, unlimited. When the cour tesy lamp is in the "permanent lighting" position, the rear cour tesy lamp also comes on, except if it is in the "permanently off " position. To switch off the rear cour tesy lamp, put it in the the "permanently off " position.
Front and rear map reading
lamps
 With the ignition on, press the corresponding switch.
Take care not to put anything in contact with the cour tesy lamps.

Interior welcome lighting The remote switching on of the passenger compar tment lighting makes your entry into the vehicle easier in poor light. It is activated depending on the light intensity detected by the sunshine sensor.
Switching on
The interior welcome lighting switches off automatically after a set time or when one of
the doors is opened.
This comes on automatically when the boot is opened and switches off automatically when the boot is closed.
Boot lamp
The lighting time varies according to the circumstances: - when the ignition is off, approximately ten minutes, - in energy economy mode, approximately thir ty seconds, - when the engine is running, no limit.
Programming
 Press the open padlock on the remote control.
The side spotlamps, the footwell lighting and
the cour tesy lamps come on; your vehicle is also unlocked. The lighting duration is selected via the vehicle configuration menu.
Switching off

147Fittings

230 V/50 Hz power socket
A 230 V/50 Hz socket (maximum power: 120 W) is fitted to the centre console. To use the socket :  lift the front armrest cover for access to its compar tment,  check that the warning lamp is on green,  connect your multimedia or other electrical
device (telephone charger, laptop computer, CD-DVD player, baby food warmer...). This socket works with the engine running, as well as in STOP mode on Stop & Star t.
In the event of a fault with the socket, the green warning lamp flashes. Have it checked by a CITROËN dealer or a qualified workshop.
Connect only one device at a time to the socket (no extension or multi-way connector).
Connect only devices with class II insulation (shown on the device). As a safety measure, when electrical
consumption is high and when required by the vehicle's electrical system (par ticular weather conditions, electrical overload...), the current supply to the socket will be cut off; the green warning lamp goes off.
12 V accessory
socket
 To connect a 12 V accessory (max power: 120 W), lift the cover and connect a suitable adaptor.

147Fittings

230 V/50 Hz power socket
A 230 V/50 Hz socket (maximum power: 120 W) is fitted to the centre console. To use the socket :  lift the front armrest cover for access to its compar tment,  check that the warning lamp is on green,  connect your multimedia or other electrical
device (telephone charger, laptop computer, CD-DVD player, baby food warmer...). This socket works with the engine running, as well as in STOP mode on Stop & Star t.
In the event of a fault with the socket, the green warning lamp flashes. Have it checked by a CITROËN dealer or a qualified workshop.
Connect only one device at a time to the socket (no extension or multi-way connector).
Connect only devices with class II insulation (shown on the device). As a safety measure, when electrical
consumption is high and when required by the vehicle's electrical system (par ticular weather conditions, electrical overload...), the current supply to the socket will be cut off; the green warning lamp goes off.
12 V accessory
socket
 To connect a 12 V accessory (max power: 120 W), lift the cover and connect a suitable adaptor.
