IV
80
A C C E S S
Electric opening
BOOT (TOURER)
Manual opening
Press upwards on lever A and lift
up the tailgate.
Press upwards on lever A , or
press button B of the remote
control. Do not attempt to help the opening
of the tailgate manually after press-
ing the control
A .
Manual closing
Lower the tailgate using the inte-
rior handle C .
Electric closing
Press the push-button D to close
the tailgate.
Do not interrupt the closing of the
tailgate; if any obstacle prevents it
closing, the operation will stop and
the tailgate will automatically rise
by a few centimetres.
Locking/unlocking
With the vehicle stationary, this is
carried out using:
- The remote control.
- The key in a door lock.
- The interior central locking/un- locking control. Interrupting the opening/
closing of the tailgate
When the tailgate is being opened or
closed electrically, you can interrupt
its movement at any point by press-
ing push-button
D , the control A or
button B .
You can then open or close the tail-
gate electrically or manually, if nec-
essary moving it in the opposite
direction to release it.
The boot automatically locks when
the vehicle is moving at a speed of
over 6 mph (10 km/h), even if auto-
matic central locking is deactivated.
It is unlocked when a door is opened
or when the central locking button
is pressed (at a speed of less than
6 mph (10 km/h)).
Memorisation of an
intermediate position
You can store an opening angle for
the tailgate:
Manually or automatically move
the tailgate to the required posi-
tion.
Make a long press on push-but-
ton D . The system emits a short
audible beep.
Release the push-button D .
Page 88 of 336
IV
82
A C C E S S
PANORAMIC SUNROOF (SALOON)
Sunroof closed
- Press B t o fi r s t n o t c h : t i l t i n g .
- Press B to second notch: auto-
matic complete tilting.
- Press A t o fi r s t n o t c h : s l i d i n g t o -
wards rear.
- Press A to second notch: auto-
matic total sliding towards rear. Sunroof open
- Press
B t o fi r s t n o t c h : c l o s u r e .
- Press B to second notch: auto-
matic total closure.
Always remove the ignition key
when leaving the vehicle, even if
for a short time .
In the event of anything being
caught by the sunroof closing, you
must reverse the roof movement.
Do this by reversing the position of
the control switch .
When the driver is operating the
sunroof, they must always make
sure that the passengers are not
preventing it from closing properly.
The driver must ensure that pas-
sengers use the sunroof control
correctly.
Pay special attention to where chil-
dren are when operating the sunroof.
T h e fi t t i n g o f a s u n r o o f a s a n a c -
cessory is prohibited
Operation
Tilted sunroof
- Press A t o fi r s t n o t c h : c l o s u r e .
- Press A to second notch: auto-
matic total closure.
Y o u r s u n r o o f i s fi t t e d w i t h a m a n u a l l y -
operated blind.
Anti-pinch
An anti-pinch device stops the sun
roof from closing, whether sliding or
tilting. If it meets an obstacle, it re-
opens. Reinitialisation
After a battery disconnection or if
there has been a malfunction, you
have to re-initialise the anti-pinch
function.
move control B until the roof is in
the complete tilting position,
keep control B pressed down for
a minimum of 1 second.
During these operations, the anti-
pinch function does not operate
.
Page 90 of 336
IV
!
84
A C C E S S
Capacity of the tank: approximately
71 litres.
Low fuel level
When the minimum level
in the tank is reached, this
warning lamp comes on
in the instrument panel,
accompanied by an audible warning
and a message on the multifunction
s c r e e n . W h e n i t fi r s t c o m e s o n , t h e r e
remains around 5 litres of fuel in the
tank.
You must refuel to avoid running out
of fuel.
Press at the top left corner, then
pull open from the left.
turn the key a quarter turn to lock
a n d u n l o c k t h e fi l l e r c a p ,
when refuelling, place the cap on
hook A ,
fi l l t h e t a n k , b u t do not persist
after the third cut-off ; this could
cause your vehicle to malfunction.
While you are refuelling, the engine
must be stopped and the ignition
switched off.
For a petrol engine with a cata-
lytic converter, unleaded fuel is
compulsory.
Opening the fuel flap Additions of fuel must be of at least
5 litres to be taken into account by
the fuel gauge.
T h e fi l l e r n e c k i s n a r r o w e r t o e n s u r e
that only unleaded petrol nozzles
can be put in.
O p e n i n g t h e fi l l e r c a p m a y c r e a t e
a noise of an inrush of air. This
vacuum, which is entirely normal,
is caused by the sealing of the fuel
system.
Refuelling
With Stop & Start, never re-
fuel with the system in STOP
mode; you must switch off
the ignition with the key.
Page 103 of 336
V
94
V I S I B I L I T Y
Special position of the
windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
In the moment following switching
off of the ignition, any action on the
stalk positions the wipers vertically
on the windscreen. To park the wipers after this has
been done, switch on the ignition
and operate the stalk.
For maintain the effectiveness of
t h e " fl a t - b l a d e " w i p e r b l a d e s , i t i s
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- avoid using them to retain card- board on the windscreen.
- r e p l a c e t h e m a t t h e fi r s t s i g n s of wear.
COURTESY LAMPS
1. Front courtesy lamp
2. Map reading lamp
s
Front courtesy lamp
Rear courtesy lamp
1. Rear courtesy lamp
2. Map reading lamps In this position, the courtesy
lamp comes on gradually:
Permanently off.
Permanent lighting.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.
Page 105 of 336
V
94
V I S I B I L I T Y
Special position of the
windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
In the moment following switching
off of the ignition, any action on the
stalk positions the wipers vertically
on the windscreen. To park the wipers after this has
been done, switch on the ignition
and operate the stalk.
For maintain the effectiveness of
t h e " fl a t - b l a d e " w i p e r b l a d e s , i t i s
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- avoid using them to retain card- board on the windscreen.
- r e p l a c e t h e m a t t h e fi r s t s i g n s of wear.
COURTESY LAMPS
1. Front courtesy lamp
2. Map reading lamp
s
Front courtesy lamp
Rear courtesy lamp
1. Rear courtesy lamp
2. Map reading lamps In this position, the courtesy
lamp comes on gradually:
Permanently off.
Permanent lighting.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.
Page 106 of 336
V
94
V I S I B I L I T Y
Special position of the
windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
In the moment following switching
off of the ignition, any action on the
stalk positions the wipers vertically
on the windscreen. To park the wipers after this has
been done, switch on the ignition
and operate the stalk.
For maintain the effectiveness of
t h e " fl a t - b l a d e " w i p e r b l a d e s , i t i s
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- avoid using them to retain card- board on the windscreen.
- r e p l a c e t h e m a t t h e fi r s t s i g n s of wear.
COURTESY LAMPS
1. Front courtesy lamp
2. Map reading lamp
s
Front courtesy lamp
Rear courtesy lamp
1. Rear courtesy lamp
2. Map reading lamps In this position, the courtesy
lamp comes on gradually:
Permanently off.
Permanent lighting.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.
Page 107 of 336
V
95
V I S I B I L I T Y
In permanent lighting mode, differ-
ent lighting times are available:
- with the ignition off, approxi-mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
-
with the engine running, unlimited.
Map reading lamps
With the ignition on, press the
corresponding switch. Panoramic sunroof rear
reading lamps (Tourer)
With the key in position or with the
ignition on:
Press the corresponding switch.
The reading lamp concerned comes
on for ten minutes.
The rear reading lamps come on:
- when the key is removed from the ignition,
- when the vehicle is unlocked.
They switch off gradually:
- when the vehicle is locked,
- when the ignition is switched on.
Page 142 of 336
VIII
122
S A F E T Y
Front airbags
S y s t e m w h i c h p r o t e c t s t h e h e a d a n d
chest of the driver and front passen-
g e r i n t h e e v e n t o f a f r o n t i m p a c t .
T h e d r i v e r ' s a i r b a g i s i n c o r p o r a t e d
in the centre of the steering wheel;
t h e f r o n t p a s s e n g e r ' s a i r b a g i s i n c o r -
porated in the dashboard above the
g l o v e b o x .
Activation
T h e a i r b a g s a r e t r i g g e r e d s i m u l t a n e -
o u s l y , u n l e s s t h e p a s s e n g e r ' s f r o n t
airbag is deactivated, in the event of
a s e r i o u s f r o n t i m p a c t t o a l l o r p a r t o f
t h e f r o n t i m p a c t z o n e A , in the lon-
g i t u d i n a l c e n t r e l i n e o f t h e v e h i c l e o n
a h o r i z o n t a l p l a n e a n d d i r e c t e d f r o m
the front to the rear of the vehicle.
T h e f r o n t a i r b a g i n fl a t e s b e t w e e n t h e
f r o n t o c c u p a n t o f t h e v e h i c l e a n d t h e
d a s h b o a r d t o c u s h i o n t h e i r f o r w a r d
m o v e m e n t . Deactivation
T h i s w a r n i n g l a m p c o m e s o n
on the roof console display
w h e n t h e i g n i t i o n i s o n a n d u n -
til the air bag is reactivated.
T o g u a r a n t e e t h e s a f e t y o f y o u r
c h i l d , i t i s i m p e r a t i v e t h a t t h e p a s -
senger airbag is deactivated when
y o u i n s t a l l a " r e a r w a r d s - f a c i n g " c h i l d
seat on the front passenger seat.
O t h e r w i s e , t h e c h i l d w o u l d r i s k b e -
i n g s e r i o u s l y i n j u r e d o r k i l l e d i f t h e
airbag were triggered. Activation
W h e n y o u r e m o v e t h e c h i l d s e a t , t u r n
switch
1 to the "ON" position to re-
a c t i v a t e t h e a i r b a g a n d s o g u a r a n t e e
t h e s a f e t y o f y o u r f r o n t p a s s e n g e r i n
t h e e v e n t o f a n i m p a c t .
Operating fault
I f t h i s s y m b o l a p p e a r s o n
t h e i n s t r u m e n t p a n e l s c r e e n ,
a c c o m p a n i e d b y a n a u d i b l e
w a r n i n g a n d a m e s s a g e ,
contact a CITROËN dealer to have
t h e s y s t e m c h e c k e d . T h e a i r b a g s
m a y n o l o n g e r b e t r i g g e r e d i n t h e
e v e n t o f a s e r i o u s i m p a c t .
O n l y t h e f r o n t p a s s e n g e r ' s a i r b a g
can be deactivated:
with the ignition off , insert the
key in the passenger airbag de-
activation switch 1 ,
t u r n i t t o t h e "OFF" position,
t h e n , r e m o v e t h e k e y k e e p i n g
the switch in this position. I f t h i s w a r n i n g l a m p fl a s h e s ,
contact a CITROËN dealer.
I f b o t h a i r b a g w a r n i n g l a m p s c o m e
o n c o n t i n u o u s l y , d o n o t i n s t a l l a
" r e a r w a r d s - f a c i n g " c h i l d s e a t o n
the front passenger seat.
Have it checked by a CITROËN
dealer.
