18
F A M I L I A R I S A T I O N
Seat belts not fastened/
unfastened warning lamp This warning lamp informs you if
the driver’s or front passenger’s
s e a t b e l t i s n o t f a s t e n e d ( d e -
p e n d i n g o n m o d e l ) , a n d i f t h e
f r o n t p a s s e n g e r ’ s ( d e p e n d i n g
o n m o d e l ) o r t h e s e c o n d - r o w
passengers’ seat belts are unfastened.
The illuminated positions represent
those whose seat belts are not fas-
tened/unfastened.
Once the function has been activated,
when starting the engine, the system
automatically locks the doors once you
r e a c h a p p r o x i m a t e l y 6 m p h ( 1 0 k m / h ) .
This function can be deactivated
by pressing button A for more than
two seconds.
Tyre under-inflation detection
This function warns you if a tyre is de-
fl a t e d o r p u n c t u r e d .
This system does not absolve the driver
of the need to regularly check the tyre
pressures.
The service warning lamp comes
on, and a vehicle outline is dis-
played, accompanied by a mes-
sage and an audible signal.
U n d e r - i n fl a t i o n w a r n i n g
The STOP warning lamp comes
on, and a vehicle outline is dis-
played, accompanied by a mes-
sage and an audible signal.
Puncture
40
124
88
M O N I T O R I N G
Automatic central locking
Instrument panel
with multifunction screen A or C
with the MyWay or NaviDrive
multifunction screen
1. Instrument panel.
2. Multifunction screen.
3. Control buttons.
4. Warning lamps display zone.
30
31 Manual central locking
You can use electrical central locking or
unlocking by pressing on button
A .
If one of the doors is open or is not
closed properly, central locking will not
work.
Page 22 of 355
25
F A M I L I A R I S A T I O N
163
Electric parking brake
Before leaving the vehicle, check that
the electric parking brake warning
lamp P ( r e d ) i s o n fi x e d ( n o t fl a s h i n g ) .
If you leave the vehicle with the en-
gine running, apply the parking brake
manually.
Never leave a child alone inside the
vehicle with the ignition on, as they
could release the parking brake. Parking space sensor
You can activate this function by press-
ing button
A .
Once the space has been measured, the
system displays the following messages:
< 1 2 m p h ( 2 0 k m / h )
Parking possible
P a r k i n g d i f fi c u l t
Parking not advised
This device combines:
- automatic functions: Automatic ap-
plication when the engine stops and
automatic release on use of the ac-
c e l e r a t o r ( a u t o m a t i c o p e r a t i o n b y
d e f a u l t ) ;
- manual use: Manual application/ release of parking brake is possible
by operating control lever A .
When in automatic mode, it remains
possible to apply or release the parking
brake at any time:
To apply it, pull on the lever A .
To release it, pull then release lever A .
Hill start assist
To aid starting on a gradient, your vehicle
i s e q u i p p e d w i t h a s y s t e m w h i c h k e e p s
it immobilised for about 2 seconds, the
approximate time it takes to move your
foot from the brake pedal to the accel-
erator pedal.
143
D R I V I N G
136
Do not drive if the parking brake
warning lamp and the P indicator on
the lever A are on.
Page 29 of 355
I
33
M O N I T O R I N G
Warning lamp is on Cause Action/Observations
Front
foglamps fi x e d . The front foglamps are
switched on. Turn the ring on the stalk rearwards twice
to switch off the front foglamps.
Rear
foglamps fi x e d . The rear foglamps are
switched on. Turn the ring on the stalk rearwards to
switch off the rear foglamps.
Diesel engine
pre-heating fi x e d . The ignition switch is at the
2nd position (ignition on). Wait until the warning lamp has switched off befor
e starting.
The duration for which the warning lamp is on is d etermined
by the climatic conditions.
Parking brake fi x e d .
The parking brake is applied
or not properly released. Release the parking brake to switch off the
warning lamp, keeping your foot on the
brake pedal.
Observe the safety recommendations.
For further information on the parking
brake, refer to the "Driving" section.
fl a s h i n g .
The parking brake is not fully
applied or is released.
Parking
space
sensors fi x e d .
The parking space sensors
function is active. Press the corresponding button to
deactivate it.
fl a s h i n g . The system is measuring the
space. Once the measurement has been done,
t h e w a r n i n g l a m p c o m e s o n fi x e d a g a i n .
Electric child
lock temporarily. The electric child lock is
activated. Displayed for a few seconds after activating
the function and every time the ignition is
switched on.
For more information, refer to the "Child
safety" section.
Page 37 of 355
I
41
M O N I T O R I N G
Service indicator
System which informs the driver
when the next service is due, in ac-
cordance with the manufacturer's
servicing schedule.
The point at which the service is due
is calculated from the last indicator
zero reset. It is determined by two
parameters:
- the distance travelled,
- the time elapsed since the last
service. 5 seconds after the ignition is switched
on,
the spanner is switched off ; the
distance recorder resumes its normal
operation. The display then indicates
the total and trip distances.
Less than 620 miles (1 000 km)
remain before the next service is due
Example: 558 miles (900 km) re-
main before the next service is due.
For 5 seconds after the ignition is
switched on, the display indicates: Service overdue
For 5 seconds after the ignition is
switched on,
t h e s p a n n e r fl a s h e s
to indicate that the service must be
carried out as soon as possible.
Example: the service is overdue by
186 miles (300 km).
For 5 seconds after the ignition is
switched on, the display indicates:
5 seconds after the ignition is
switched on, the distance recorder
resumes its normal operation. The
spanner remains on to indicate that
a service must be carried out soon. 5 seconds after the ignition is
switched on, the distance recorder
resumes its normal operation.
The
spanner remains lit .
More than 620 miles (1 000 km)
remain before the next service is
due
For 5 seconds after the ignition is
switched on, the spanner symbol-
ising the service operations comes
on. The distance recorder display
line indicates the distance remaining
before the next service is due.
Example: 2 976 miles (4 800 km)
remain before the next service is
due.
For 5 seconds after the ignition is
switched on, the display indicates:
The distance remaining may be
weighted by the time factor, depend-
ing on the driver's driving habits.
Therefore, the spanner may also
come on if you have exceeded the
two year service interval.
Page 38 of 355
I
42M O N I T O R I N G
Service indicator zero reset
Engine oil level indicator
After each service, the service indi-
cator must be reset to zero.
The procedure for resetting to zero
is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the dis-
tance recorder display begins a
countdown,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essen-
tial that the level is topped up to pre-
vent damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL--" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 39 of 355
I
42M O N I T O R I N G
Service indicator zero reset
Engine oil level indicator
After each service, the service indi-
cator must be reset to zero.
The procedure for resetting to zero
is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the dis-
tance recorder display begins a
countdown,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essen-
tial that the level is topped up to pre-
vent damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL--" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 41 of 355
II
44
M U L T I F U N C T I O N S C R E E N S
MONOCHROME SCREEN A
Displays in the screen
This screen can display the follow-
ing information:
- time
- date
- ambient temperature
When the ambient temperature is between +3 °C and -3 °C, the
t e m p e r a t u r e d i s p l a y fl a s h e s ( r i s k
of ice). The ambient temperature
displayed may be higher than
the actual temperature if the ve-
h i c l e i s p a r k e d i n t h e s u n .
- the current audio source,
- t r i p c o m p u t e r ( s e e t h e e n d o f t h e section).
A l e r t m e s s a g e s ( e . g . : " A n t i p o l l u t i o n
s y s t e m f a u l t y " ) o r i n f o r m a t i o n m e s -
s a g e s ( e . g . : " B o o t o p e n " ) m a y
appear temporarily. They can be re-
moved by pressing "ESC" .
A. A c c e s s t o t h e " M a i n m e n u " .
B. Navigation in the screen menus
C. C o n fi r m a t i o n o f t h e s e l e c t i o n o f a
function in a menu or of a value
m o d i fi e d
D. Cancellation the current opera-
tion.
E. Selection of the type of infor-
m a t i o n ( d a t e , a u d i o - C D a n d t r i p
computer)
B or F. In the menus, navigation,
choice of activation/deactiva-
tion of functions and choice
of settings.
Press button A , then using B ,
you have access to the following
menus:
- r a d i o - C D
- v e h i c l e c o n fi g
- options
- display adjust
- languages
- units
Press button C t o c o n fi r m .
Controls Main Menu
F o r s a f e t y r e a s o n s , c o n fi g u r a t i o n
of the multifunction screen by the
driver must only be done when
stationary.
Page 42 of 355
II
45
M U L T I F U N C T I O N S C R E E N S Vehicle config
Options
This menu is used for diagnosis of
t h e s t a t e o f s y s t e m s ( a c t i v e , i n a c -
tive, faulty).
Radio-CD
With the Audio system on, you can
activate or deactivate functions of
t h e r a d i o ( R D S s t a t i o n t r a c k i n g ,
R E G m o d e ) , C D o r C D c h a n g e r ( C D
i n t r o s c a n , s h u f fl e , r e p e a t ) .
For more information on the
" R a d i o - C D " a p p l i c a t i o n , r e f e r t o t h e
A u d i o s y s t e m s e c t i o n i n " A u d i o e t
T e l e m a t i c s " . Display adjust
T h e " D i s p l a y a d j u s t " m e n u i s u s e d
for the following settings:
- year,
- month,
- day,
- hour,
- minutes,
- 12 or 24 hour mode.
Languages
You can select the screen dis-
p l a y l a n g u a g e ( F r a n ç a i s , I t a l i a n o ,
Nederlands, Portugues, Portugues-
B r a s i l , D e u t s c h , E n g l i s h , E s p a n o l ) .
Units
This menu is used to select the units
f o r t e m p e r a t u r e ( ° C o r ° F ) a n d f u e l
c o n s u m p t i o n ( l / 1 0 0 k m , m p g o r k m / l ) .
* D e p e n d i n g o n d e s t i n a t i o n c o u n t r y .
T h e " V e h i c l e c o n fi g " m e n u i s u s e d
to activate/deactivate the following
functions:
- rear wiper coupled to reverse g e a r ( r e f e r t o t h e " V i s i b i l i t y " s e c -
tion),
- guide-me-home and welcome l i g h t i n g ( r e f e r t o t h e " V i s i b i l i t y "
section),
- a u t o m a t i c f u n c t i o n s ( a p p l i c a t i o n / r e l e a s e ) o f t h e e l e c t r i c p a r k i n g
b r a k e * ,
- s e l e c t i v e d o o r l o c k i n g ,
- d a y t i m e r u n n i n g l a m p s ( r e f e r t o t h e " V i s i b i l i t y " s e c t i o n ) .
