I
M O N I T O R I N G
25
Message is on Cause Solution - action Observations
Airbags Fixed Fault in the airbags or
pretensioners. Consult a CITROËN
dealer.
Service Fixed Problem in one of the systems
w h i c h d o e s n o t h a v e a s p e c i fi c
message. Stop the vehicle and
contact a CITROËN
dealer. To identify the
p r o b l e m , c o n t a c t a
CITROËN dealer.
Engine oil pressure Fixed Engine oil pressure too low or
fault in the engine lubrication
system. Stop the vehicle and
contact a CITROËN
dealer.
Engine oil level Fixed Engine oil level too low. Stop the vehicle and
check the level using
the dipstick. If there is a lack of
o i l , t o p u p t h e l e v e l .
Low fuel warning Fixed The fuel level is low. Refuel as soon as
possible.
Fuel system Fixed Fuel system fault. Consult a CITROËN
dealer.
Opening
not closed correctly Fixed
One of the doors or the tailgate
is not closed correctly. Close the door or the
tailgate. The opening
concerned is
indicated on the
screen.
Page 58 of 217
II
!
C O M F O R T
70
Second installation position.
T h e l o a d s p a c e c o v e r c a n b e s e c u r e d
i n t w o d i f f e r e n t p o s i t i o n s B , so that the
r o w 2 s e a t b a c k s c a n b e t i l t e d .
1. R e e l i n t h e l o a d s p a c e c o v e r .
2. Move one of the slides C towards
the inside of the vehicle and insert
the tab D in the installation hole to
b e u s e d .
M o v e t h e o p p o s i t e s l i d e i n t h e s a m e w a y .
3. A f t e r c h a n g i n g t h e p o s i t i o n , c h e c k
t h a t t h e l o a d s p a c e c o v e r i s s e c u r e d
c o r r e c t l y . Removing the load space cover.
1. R e e l i n t h e l o a d s p a c e c o v e r .
2. Move one of the slides C towards the
i n s i d e o f t h e v e h i c l e a n d r a i s e i t .
R e l e a s e t h e o p p o s i t e s l i d e i n t h e s a m e w a y .
T o p u t t h e l o a d s p a c e c o v e r i n p l a c e , c a r r y
o u t t h e o p e r a t i o n s i n r e v e r s e o r d e r .
Load space cover
U n r o l l t h e l o a d s p a c e c o v e r a n d i n s t a l l i t
in the housing A .
T o s t o r e t h e l o a d s p a c e c o v e r , r e l e a s e i t
from the housing, it reels in to its initial
p o s i t i o n .
T a k e c a r e n o t t o p l a c e h e a v y
o b j e c t s o n t h e l o a d s p a c e c o v e r
w h e n i t i s u n f o l d e d .
T h e l o a d s p a c e c o v e r c a n b e s t o r e d
along the lower tailgate, unless audio
e q u i p m e n t i s p r e s e n t .
Page 59 of 217
III
A C C E S S
71
Unfolding the key
First press button A to unfold the key.
Unlocking the vehicle
Press the open padlock to
unlock the vehicle.
Unlocking using the remote control
REMOTE CONTROL KEY
System which permits central unlock-
ing or locking of the vehicle using the
lock or from a distance. It also folds and
unfolds the mirrors, closes the electric
windows and starts the vehicle, as well
as providing protection against theft.
Locking the vehicle
Unlocking using the key
Turn the key to the right in the driver's
door lock to unlock the vehicle.
Press the closed padlock
to lock the vehicle.
If one of the doors or the tailgate is
still open, the central locking will not
take place.
U n l o c k i n g i s c o n fi r m e d b y t h e i n t e r i o r
lighting which comes on for approxi-
mately 15 seconds and the direction
i n d i c a t o r s w h i c h fl a s h
twice .
If you press the open padlock twice in
succession within 30 seconds after
unlocking the vehicle, the door mirrors
unfold.
Normal locking using the key
Turn the key to the left in the driver's
door lock to lock the vehicle.
L o c k i n g i s c o n fi r m e d b y t h e d i r e c t i o n i n -
dicators which come on
once .
If you press the closed padlock twice
in succession within 30 seconds af-
ter locking the vehicle, the door mirrors
fold.
An extended press on the closed pad-
lock within 30 seconds after locking the
vehicle closes the windows automati-
cally.
Normal locking using the remote
control
Page 60 of 217
III
A C C E S S
72
The vehicle will relock automatically
after thirty seconds unless a door or
the tailgate is opened. This function
prevents inadvertent unlocking.
The duration which precedes the au-
tomatic relocking of the vehicle can
b e c o n fi g u r e d v i a t h e c o l o u r s c r e e n
"Equipment" menu.
Folding the key
First press button A to fold the key. Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the igni-
tion is switched on, this code must be
recognised to permit starting.
This electronic engine immobiliser locks
the engine management system a few
moments after the ignition is switched
off and prevents starting of the engine
by anyone who does not have the key.
Anti-theft protection
In the event of a malfunction and if
your vehicle does not start; contact a
CITROËN dealer as soon as possible.
Page 63 of 217
III
A C C E S S
72
The vehicle will relock automatically
after thirty seconds unless a door or
the tailgate is opened. This function
prevents inadvertent unlocking.
The duration which precedes the au-
tomatic relocking of the vehicle can
b e c o n fi g u r e d v i a t h e c o l o u r s c r e e n
"Equipment" menu.
Folding the key
First press button A to fold the key. Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the igni-
tion is switched on, this code must be
recognised to permit starting.
This electronic engine immobiliser locks
the engine management system a few
moments after the ignition is switched
off and prevents starting of the engine
by anyone who does not have the key.
Anti-theft protection
In the event of a malfunction and if
your vehicle does not start; contact a
CITROËN dealer as soon as possible.
Page 68 of 217
III
A C C E S S
77
DOORS
From outside
After unlocking the vehicle using the
remote control or the key, pull the
door handle. From inside
Pull the front or rear door control to
open the door.
The front passenger door or the rear
d o o r s m u s t fi r s t b e u n l o c k e d m a n u a l l y
using the locking control before being
opened.
Closing
If a door is not closed correctly,
this warning lamp comes on
in the instrument panel screen
until the door concerned is
closed.
Manual centralised control
System which provides full manual
locking or unlocking of the doors and
tailgate from the inside.
Locking
Press the front of button A to lock
the vehicle.
If the driver's door is open when
you operate the central locking from
inside, all of the doors lock with the
exception of the driver's door.
Unlocking
Press the rear of button A to unlock
the vehicle.
Opening
If the doors are locked, opening the
driver's door does not unlock the
other doors.
Page 69 of 217
III
A C C E S S
78
Opening
After unlocking the vehicle using the
remote control or the key, press the
handle A and raise the tailgate.
TAILGATE
Closing
Pull the handle B downwards to
guide the tailgate,
release the handle and press the ex-
terior surface of the tailgate gently to
close it.
Emergency control
System which locks or unlocks mechan-
ically the driver's door only in the event
of a malfunction of the central locking.
Locking the driver's door
Insert the key in the lock, then turn it
to the left.
Unlocking the driver's door
Insert the key in the lock, then turn it
to the right. Unlocking the front and rear doors
(from inside)
Tilt the interior control B rearwards.
Using the key
Locking the front passenger door
and the rear doors (from inside)
Tilt the interior control B forwards.
The other doors are not unlocked.
Page 70 of 217
III
A C C E S S
78
Opening
After unlocking the vehicle using the
remote control or the key, press the
handle A and raise the tailgate.
TAILGATE
Closing
Pull the handle B downwards to
guide the tailgate,
release the handle and press the ex-
terior surface of the tailgate gently to
close it.
Emergency control
System which locks or unlocks mechan-
ically the driver's door only in the event
of a malfunction of the central locking.
Locking the driver's door
Insert the key in the lock, then turn it
to the left.
Unlocking the driver's door
Insert the key in the lock, then turn it
to the right. Unlocking the front and rear doors
(from inside)
Tilt the interior control B rearwards.
Using the key
Locking the front passenger door
and the rear doors (from inside)
Tilt the interior control B forwards.
The other doors are not unlocked.
