2009 VOLVO XC90 ignition

02 Instruments and controlsLeft-side steering wheel lever
0266
Lever positions
G026954
Turn signals, lane change positionTurn signals, position for normal turnsHigh beam flashToggle between high and low beams,
Home Safe lighting
Turn signalsWhen turningMove the lever as far up or down as possible
(to position 2) to start the turn signals. The turn
signals will be cancelled automatically by the
movement of the steering wheel, or the lever
can be returned to its initial position by hand.When changing lanesThe driver can automatically flash the turn sig-
nals 3 times by:•
Moving the turn signal lever up or down to
position (1) and releasing it.
•
Moving the lever up or down to position (2)
and immediately back to its original posi-
tion.NOTE
•
This automatic flashing sequence can
be interrupted by immediately moving
the lever in the opposite direction.
•
If the turn signal indicator flashes faster
than normal, check for a burned-out
turn signal bulb.
High/low beam headlightsContinuous high beams1.
Turn the ignition key to position II.
2. With the light switch (1) in position
, (see page 63) pull the turn signal
lever toward the steering wheel (position 4)
to toggle between high and low beams
(this also applies on models equipped with
the optional Active Bi-Xenon
Ÿ headlights).
High beam flash1.
Turn the ignition key to position II.
2. Pull the turn signal lever to position (3). The
high beams will remain on until the lever is
released.Home safe lightingWhen you leave your vehicle at night, you can
make use of the home safe lighting function to
illuminate the area in front of the vehicle.
1. Remove the key from the ignition switch.
2. Pull the direction indicator lever as far as
possible towards the steering wheel (to
position 4) and release it.
3. Exit the vehicle and lock the doors.
The headlights and parking lights will illuminate
and remain on for 30
1, 60 or 90 seconds. The
1Factory setting

02 Instruments and controls
Right-side steering wheel lever
0269 Tailgate wiper/washer
G027127
Intermittent wiping: Press the upper
section of the switch Neutral position: The wiper is switched
off Normal (continuous) wiping: Press the
lower section of the switch
Move the lever forward to start the tailgate
washer. After washing the rear window, the
wiper will make several additional sweeps.
Tailgate wiper and reverse gearIf the front wipers are on and the transmission
is put into reverse gear, the tailgate wiper will
go into intermittent wiping function
1.
If the tailgate wiper is already in normal wiping
function, the normal wiping function will con-
tinue.
Rain sensor (option)The rain sensor automatically regulates wiper
speed according to the amount of water on the
windshield.
Thesensitivity of the sensor can be adjusted
by twisting ring 1 up (the wipers will sweep the
windshield more frequently) or down (the wip-
ers will sweep the windshield less frequently).Activating the rain sensor:1. Turn the ignition key to at least position I
and put the windshield wiper lever in posi-
tion0.
2. Press button (2).
> A light in the button will light up to indi-
cate that the rain sensor is active.Deactivating the rain sensor:•
Press button (2).
or
•
Move the windshield wiper lever down to
another position. Moving the lever up will
not deactivate the rain sensor. Doing so
will cause the wipers to sweep the wind-
shield until the lever is released, at which
time the wipers return to rain sensor mode.
The rain sensor is also deactivated when the
key is removed from the ignition.CAUTION
The rain sensor should be deactivated when
washing the vehicle in an automatic car
wash, etc. If the rain sensor function is left
on, the wipers will start inadvertently in the
car wash and could be damaged.
1Consult your Volvo retailer if you would like to have this function deactivated.

02 Instruments and controls
12-volt sockets
0275
These 12 volt sockets can be used to plug in
certain accessories such as cellular tele-
phones, etc.
The ignition key must be in at least position I
for the sockets in the front seat and the optional
socket at the rear of the center console to func-
tion.
12-volt socket in the cargo compartment
Fold down the lid to use the socket. This socket
can be used even if the ignition is switched off.
NOTE
•
If the 12-volt sockets are used while the
engine is not running, there is a risk that
the vehicle's battery will be discharged.
•
If the ignition is switched off and a
device drawing more than 0.1 A is con-
nected to a socket, a battery warning
will be displayed in the text window.
•
The covers should be kept on when the
auxiliary sockets are not in use.
•
Maximum current from the sockets is
15 A.
G028425
12-volt socket at the rear of the center console
(option)Ashtrays/cigarette lighterThe auxiliary sockets can also be used for cig-
arette lighters.
Ashtrays and lighters are available as acces-
sories. Please contact your Volvo retailer.
G027099
12-volt socket in the cargo compartment

02 Instruments and controlsPower windows
0278
Power windowsThe power windows are controlled by buttons
in the arm rests. The ignition switch must be
ON
1 (ignition key in position I,II or the engine
running) for the electrically operated windows
to function.
To lower: Press down the front edge of the but-
ton to the first detent ("stop").
To raise: Lightly pull up the front edge of the
button to the first detent ("stop").
Auto up/down function (front doors only):Either front door window can be opened or
closed automatically.
Auto down: Press the front part of the button
as far down as possible and release it immedi-
ately. To stop the window at any time, pull the
button up.
Auto up: Pull the front part of the button up as
far as possible and release it immediately. To
stop the window at any time, press the button
down.
G029571
Power window controls
Front windowsRear windowsNOTE
If a window is obstructed during auto-up, it
will automatically reverse direction and
return to its starting position. If a window is
repeatedly obstructed during auto-up oper-
ation, an overload protection circuit breaker
will temporarily halt window function. The
window will return to normal function after a
brief cool-down period.
WARNING
Always remove the ignition key when the
vehicle is unattended.
Make sure that the windows are completely
unobstructed before they are operated.
Never leave children unattended in the vehi-
cle.
NOTE
To reduce buffeting wind noise if the rear
windows are opened, also open the front
windows slightly.
G029572
1The power windows will also function after the ignition has been switched off as long as neither of the front doors has been opened.

02 Instruments and controlsMirrors
0280
Rearview mirror
G026660
To reduce glare from the headlights of follow-
ing vehicles, use the control to switch between
the normal and night-driving positions.
Normal positionNight position, reduces glare from follow-
ing headlights
Autodim function (option)The autodim function reacts to headlights from
following traffic and automatically reduces
glare.
NOTE
This function is automatically switched off
when the gear selector is placed in the
Reverse position.Rearview mirror with compass (option)
G026965
The upper left-hand corner of the rearview mir-
ror has an integrated display that shows the
compass direction toward which the car is
pointing. Eight different directions can be dis-
played:
N, NE, E, SE, S, SW, W
and
NW
. The
display shows your car's orientation with
respect to true north.
If the compass is activated, it will be displayed
automatically when the ignition is in postilion IIor when the engine is running. The compass
can be switched off or on by pressing the inset
button on the rear side of the mirror (see the
inset illustration). This can be done with
straightened paperclip or similar object. The
button is recessed approximately 1 in. (2.5 cm)
in the mirror.
G026409
Magnetic zonesThe earth is divided into 15 magnetic zones.
The compass is initially set for the zone to
which the car was delivered, and should
always be adjusted if the car is driven to a new
magnetic zone. To do so:
1.
Switch the ignition to position II.

02 Instruments and controls
Power moonroof
02``83 Power moonroof
G007503
To operate the moonroof, turn the ignition key
to position I or II, or start the engine. The moon-
roof can be operated in two ways:
Tilt positionSliding moonroof
G027010
Tilt positionOpen: With the moonroof closed, push up the
rear edge of the switch (position 5 in the illus-
tration in the center column).
Close: Pull down and hold the rear edge of the
switch (position 6 in the illustration in the center
column) until the moonroof has closed com-
pletely.Sliding moonroofManual open: Pull the switch rearward to posi-
tion 3 and hold it until the moonroof has
opened to the position of your choice.Auto open: Pull the switch as far back as pos-
sible (position 4) and release it to automatically
slide open the moonroof to the "comfort"
1
position. Pull the switch rearward again to
open the moonroof completely.
Manual close: Push the switch to position 2
and hold it until the moonroof has closed com-
pletely or to the position of your choice.
Auto close: Push the switch forward as far as
possible (position 1) and release it to automat-
ically close the moonroof.
CAUTION
•
Remove ice and snow before opening
the moonroof.
•
Do not operate the moonroof if it is fro-
zen closed.
•
Never place heavy objects on the
moonroof.
1A position where the moonroof is not quite fully open, which helps alleviate "rumbling" wind noise.

02 Instruments and controlsPower moonroof
0284
WARNING
•
Never open/close the moonroof it is
obstructed in any way when in opera-
tion.
•
Never allow a child to operate the
moonroof.
•
Never extend any object or body part
through the open moonroof, even if the
vehicle's ignition is completely
switched off.
•
Never leave a child alone in a vehicle.
If the moonroof is obstructed during auto-close
operation, it will automatically reverse direction
and return to its starting position. If the moon-
roof is repeatedly obstructed during auto-close
operation, an overload circuit breaker will tem-
porarily halt moonroof function. The moonroof
will return to normal function after a brief cool-
down period.
G020157
Sun visorThe optional moonroof also features a sliding
sun visor. The visor slides open automatically
when the moonroof is opened. The visor must
be closed manually.
WARNING
The moonroof must never be obstructed in
any way when in operation.

02 Instruments and controls
HomeLink® Wireless Control System (option)
02``85 Introduction
G030070
The HomeLink Wireless Control System pro-
vides a convenient way to replace up to three
hand-held radio-frequency (RF) transmitters
used to activate devices such as gate opera-
tors, garage door openers, entry door locks,
security systems, even home lighting. Addi-
tional HomeLink information can be found on
the Internet at www.homelink.com.
WARNING
•
If you use HomeLink to open a garage
door or gate, be sure no one is near the
gate or door while it is in motion.
•
When programming a garage door
opener, it is advised to park outside of
the garage.
•
Do not use HomeLink with any garage
door opener that lacks safety stop and
reverse features as required by U.S.
federal safety standards (this includes
any garage door opener model manu-
factured before April 1, 1982). A garage
door that cannot detect an object - sig-
naling the door to stop and reverse -
does not meet current U.S. federal
safety standards. For more information,
contact HomeLink at:
www.homelink.com.
Retain the original transmitter of the RF device
you are programming for use in other vehicles
as well as for future HomeLink programming. It
is also suggested that upon the sale of the
vehicle, the programmed HomeLink buttons be
erased for security purposes. Refer to “Erasing
HomeLink Buttons”.
Programming HomeLink
NOTE
Some vehicles may require the ignition
switch to be turned on or to the second
(“accessories”) position for programming
and/or operation of HomeLink. It is also rec-
ommended that a new battery be placed in
the hand-held transmitter of the device
being programmed to HomeLink for quicker
training and accurate transmission of the
radio-frequency signal.1. Position the end of your hand-held trans-
mitter 1–3 inches (5–14 cm) away from the
HomeLink button you wish to program
while keeping the indicator light in view.
2. Simultaneously press and hold both the
chosen HomeLink and hand-held transmit-
ter buttons until the HomeLink indicator
light changes from a slow to a rapidly blink-
ing light. Now you may release both the
HomeLink and hand-held transmitter but-
tons.
