2009 VOLVO V70 climate control

Contents
5
03
03 Your driving environmentInstruments and controls.......................... 70
Ignition modes.......................................... 77
Seats......................................................... 79
Steering wheel.......................................... 84
Lighting..................................................... 85
Wipers and washers................................. 91
Power windows......................................... 94
Mirrors....................................................... 96
Power moonroof....................................... 98
HomeLink® Wireless Control System
(option).................................................... 100
Starting the engine.................................. 103
Transmission...........................................107
Brakes..................................................... 110
Hill Descent Control (HDC)..................... 112
Parking brake.......................................... 114
04
04 Comfort and driving pleasureMenus and messages............................. 120
Climate system....................................... 124
Audio system.......................................... 131
BluetoothŸ hands-free connection......... 143
Rear Seat Entertainment - Dual Screen
(RSE)–option.......................................... 149
Trip computer.........................................152
Compass................................................. 153
Stability system....................................... 155
Active chassis system–Four C................157
Cruise control.......................................... 158
Collision warning with Auto-brake
(option).................................................... 160
Adaptive Cruise Control–ACC (option). . . 166
Distance alert ......................................... 173
Driver Alert System (option) ...................176
Park assist (option).................................181
Blind Spot Information System (option). . 184
Passenger compartment convenience. . . 188
05
05 During your tripDriving recommendations....................... 194
Refueling................................................. 198
Loading................................................... 202
Cargo area.............................................. 207
Towing a trailer....................................... 210
Emergency towing.................................. 212

03 Your driving environment
Instruments and controls
03``71
Function
Page
Menus and mes-
sages, turn signals,
high/low beams,
trip computer
120, 88,
85, 152
Cruise control
158
Horn, airbag
84, 18
Main instrument
panel
71
Menu system, audio
controls
131
Ignition slot
77
START/STOP
ENGINE button
77
Hazard warning
flashers
87
Door handle
–
In-door control pan-
els (power win-
dows, mirrors,
power child safety
locks, central lock-
ing button)
94, 96,
48, 63
Function
Page
Menu controls,
audio and climate
control systems
120, 134,
126
Center console but-
tons
120
Gear selector
107
Controls for active
chassis (Four-C) -
certain models only
157
Wipers and washers
91, 92
Steering wheel
adjustment
84
Parking brake
114
Hood opening con-
trol
219
Seat adjustment
controls
79
Lighting panel, but-
tons for opening
fuel filler door and
unlocking the tail-
gate
85, 200,
64
Information displays
G010604
Information displays in the instrument panelThe information displays (1) show information
on some of the vehicle's functions, such as
cruise control, the trip computer and mes-
sages. The information is shown with text and
symbols.
More detailed information can be found in the
descriptions of the functions that use the infor-
mation displays.

03 Your driving environment
Mirrors
0397
locking. For a description of the menu system,
see page 120.Resetting to neutralMirrors that have been moved out of position
by an external force must be electrically reset
to the neutral position for electric retracting/
extending to work.•
Retract the mirrors with the L and R but-
tons.
•
Fold them out again with the L and R but-
tons.
The mirrors are now reset in neutral position.
Home safe and approach lightingThe light on the door mirrors comes on when
approach lighting or home safe lighting is
selected, see page 89.
Rear window and door mirror
defrosters
G018377
Use the defroster to quickly remove misting
and ice from the rear window and the door mir-
rors.
Press the button once to start simultaneous
rear window and door mirror defrosting. The
light in the button indicates that the function is
active. Defrosting is deactivated automatically
and its duration is controlled by the outside
temperature.
The rear window is demisted/de-iced automat-
ically if the vehicle is started in an outside tem-
perature lower than 45 °F (7 °C).
Defrosting can be selected under Climate
settings
Auto. rear defroster. Select
betweenOn
or
Off
.
Interior rearview mirrorAuto-dim functionAn integrated sensor reacts to headlights from
following traffic and automatically reduces
glare in the mirror.

G020908
118
Menus and messages........................................................................... 120
Climate system..................................................................................... 124
Audio system........................................................................................ 131
BluetoothŸ hands-free connection....................................................... 143
Rear Seat Entertainment - Dual Screen (RSE)–option ......................... 149
Trip computer........................................................................................ 152
Compass............................................................................................... 153
Stability system..................................................................................... 155
Active chassis system–Four C.............................................................. 157
Cruise control........................................................................................ 158
Collision warning with Auto-brake (option)........................................... 160
Adaptive Cruise Control–ACC (option)................................................. 166
Distance alert ....................................................................................... 173
Driver Alert System (option) ................................................................. 176
Park assist (option)................................................................................ 181
Blind Spot Information System (option)................................................184
Passenger compartment convenience................................................. 188

04 Comfort and driving pleasure
Menus and messages
04``121
Light settings
Lock settings
Reduced guard
1
Parking camera settings (accessory)
Steering force level (option)
Information
Climate settings
Automatic blower adjust
Recirculation timer
Auto. rear defroster
Reset climate settings
Main menu AMAudio settings
2
Sound stage
Equalizer, front
Equalizer, rear
Auto. volume control
Resets all audio settings.
Main menu FMFM settings
Radio text
Advanced radio settings
Audio settingsMain menu CDRandom
Off
Folder
Disc
Single disc
All discs
CD settings
Disc text (option)
Audio settingsMain menu AUXVolume, AUX input
Audio settings
Main instrument panel
G022908
Information display and menu controls
READ – access to the list of messages and
message confirmation.Thumbwheel – browse among menus and
options in the list of functions.RESET – reset the active function. Used in
certain cases to select/activate a function,
see the explanation under each respective
function.
The menus shown on the information displays
in the instrument panel are controlled with the
left lever. The menus shown depend on ignition
mode. Press READ to erase a message and
return to the menus.
1Certain models2The menu option for audio settings is available in all audio sources.

04 Comfort and driving pleasureClimate system
04124
IntroductionAir conditioningThe vehicle is equipped with Electronic Climate
Control (ECC). The climate control system
cools, heats or dehumidifies the air in the pas-
senger compartment.
NOTE
•
The air conditioning can be switched
off, but to ensure the best possible cli-
mate comfort in the passenger com-
partment and to prevent the windows
from misting, it should always be on.
•
In warm weather, a small amount of
water may accumulate under the car
when it has been parked. This water is
condensation from the A/C system and
is normal.
Sensor location•
The sunlight sensor is located on the top
side of the dashboard.
NOTE
The sunlight sensor monitors which side of
the car that is most exposed to sunlight.
This can mean that the temperature may
differ between the right and left-side air
vents, even if the temperatures set for both
sides of the passenger compartment are the
same.•
The temperature sensor for the passenger
compartment is located below the climate
control panel.
•
The outside temperature sensor is located
on the door mirror.
•
The humidity sensor (option) is located in
the interior rearview mirror.NOTE
Do not cover or block the sensors with
clothing or other objects.Side windows and moonroofTo ensure that the air conditioning works opti-
mally, the side windows, and the optional
moonroof should be closed.Fog on the inside of the windowsThe defroster function should be used to
remove fog or mist from the inside of the win-
dows. Keeping the windows clean with a com-mercially available window washing spray will
also help prevent fogging or misting.
Temporary shut-off of the air
conditioningThe air conditioning is momentarily disen-
gaged during full-throttle acceleration or when
driving uphill with a trailer. This may result in a
temporary increase in cabin temperature.Ice and snowAlways keep the air intake grille at the base of
the windshield free of snow.Climate system maintenanceSpecial tools and equipment are required to
maintain and carry out repairs on the climate
system. Work of this type should only be done
by a trained and qualified Volvo service tech-
nician.RefrigerantVolvo cares about the environment. The air
conditioning system in your car contains a
CFC-free refrigerant – R134a. This substance
will not deplete the ozone layer. The air condi-
tioning system contains 1.8 lbs (800 g) of
R134a. The systems uses PAG oil.Passenger compartment filterReplace the cabin air filter with a new one at
the recommended intervals. Please refer to

04 Comfort and driving pleasure
Climate system
04``125
your Warranty and Service Records Informa-
tion booklet, or consult a trained and qualified
Volvo service technician for these intervals.
The filter should be replaced more often when
driving under dirty and dusty conditions. The
filter cannot be cleaned and therefore should
always be replaced with a new one.
NOTE
There are different types of cabin air filters.
Ensure that the correct type is installed.Interior Air Quality System (IAQS)A multifilter helps reduce gases and particles
in the incoming air, thereby reducing the levels
of odors and contaminants entering the vehi-
cle. The air quality sensor detects increased
levels of contaminants in the outside air. When
the air quality sensor detects contaminated
outside air, the air intake closes and the air
inside the passenger compartment is recircu-
lated, i.e. no outside air enters the vehicle. The
filter also cleans recirculated passenger com-
partment air.
NOTE
Contact your Volvo retailer for IAQS air filter
replacement intervals.
Menu settingsThe default settings for three of the climate
system's functions can be changed in the
menu system, see page 120:•
Blower speed in automatic mode, see
page 127.
•
Recirculation timer for passenger com-
partment air, see page 127.
•
Automatic rear window defrosting, see
page 97.
The functions can also be returned to factory
settings in the menu system.
Air distribution
G017699
The incoming air is distributed from 20 different
vents in the passenger compartment.Air distribution is fully automatic in AUTO
mode.
If desired, air distribution can be controlled
manually, see page 130.
Air vents in the dashboard
G021367
OpenClosedHorizontal airflowVertical airflow
Direct the outer air vents toward the side win-
dows to defrost.

04 Comfort and driving pleasureClimate system
04126
Air vents in the door pillars
G021368
OpenClosedHorizontal airflowVertical airflow
Direct the outer air vents toward the side win-
dows to defrost.
Direct the vents into the passenger compart-
ment to maintain a comfortable climate in the
rear seat.
Electronic climate control, ECC
G018599
Ventilated front driver's seat (option)BlowerHeated front driver's seat (option)Air distributionVentilated front passenger's seat (option)AutoHeated front passenger's seat (option)Temperature control, passenger's sideA/C – On/OffHeated rear window and door mirrors, see
page 97.Defroster (maximum effect)
Recirculation/Air quality systemTemperature control, driver's side
Ventilated front seats (option)The ventilation system consists of fans in the
seats and backrests that draw air through the
seat upholstery. The cooling effect increases
as the air in the passenger compartment
becomes cooler.
The ventilation is controlled by the ECC sys-
tem, which takes into account the seat tem-
perature, sunlight in the passenger compart-
ment, and the ambient temperature.
The ventilation can be used at the same time
as seat heating.
The ventilation system can be activated when
the engine is running. There are three comfort
levels that produce different cooling and dehu-
midification effects:•
Level three: press the button once for
maximum output – three indicator lights
come on.
•
Level two: press the button twice for a
lower output – two indicator lights come
on.
