2009 VOLVO V50 clock setting

02 Instruments and controlsPersonal settings
0282
Control panelAD
BC
E
G026307
DisplayMenu buttonExit buttonEnter buttonMenu navigation controlsPersonal settings can be made for some of the
car's functions, such as the central locking
system, climate control, and the audio system.
Please refer to page 241 for more information
on the audio functions that can be adjusted.
The settings are presented in the display (A).
To access the menu and adjust settings1.
PressMENU (B).
2.
Scroll to
Car Settings
using the menu nav-
igation control (E).
3.
PressENTER (D).
4. Select an alternative using the menu navi-
gation control (E).
5. Confirm your selection by pressing
ENTER.
To exit the menuPressEXIT (C).Available settingsClock adjustTo set the time:
1. Use the number keys or the up/down arrow
keys on the navigation control (E) to
change the hour or minute.2. Select hour(s) or minute(s) to be changed
with the left/right arrow keys.
3.
PressENTER to start the clock.
NOTE
If you are currently using the 12-hour time
setting, use the up/down arrow keys to
selectAM/PM after the minute-setting has
been adjusted.Lock confirmation lightWhen the car is locked/unlocked with the
remote control, the direction indicators can be
selected to flash to confirm the action. The
alternatives On/Off are available for both lock-
ing and unlocking.AutolockWhen the car starts to move, the doors and
tailgate can be locked automatically. The alter-
natives On/Off are available.
NOTE
Pulling the handle twice on a door unlocks
and opens that door.UnlockThere are two alternatives for unlocking:

03 ClimateElectronic Climate Control (ECC) – option
0396
G019518
Auto – On/OffBlower speedRecirculationDefrosterAirflow controlsA/C – ON/OFFHeated driver's seatHeated front passenger's seatRear window and door mirror defrostersTemperature selector
ECC functions1. Auto – On/Off
TheAUTO function automat-
ically regulates climate con-
trol to maintain the desired
temperature. The automatic
function controls heating, air
conditioning, blower speed,
recirculation, and air distribu-
tion.
If you select one or more manual functions, the
remaining functions continue to be controlled
automatically. All manual settings are switched
off when AUTO is switched on.
AUTO
CLIMATE
is shown in the display.
2. Blower speed
The blower speed can be
increased or decreased by
turning the knob. The blower
speed is regulated automati-
cally if AUTO is selected. The
previously set blower speed is
disconnected.
NOTE
If the knob is turned counterclockwise and
the blower indication in the display goes
out, the blower and the air conditioning are
switched off. The display shows the blower
symbol and
OFF
.

05 Locks and alarm
Locking and unlocking
05``127 Locking/unlocking the vehicle from the
inside
G007451
The switches near the door opening handles on
the driver's and front passenger's doors can be
used to lock or unlock all doors and the tail-
gate, open the side windows
1, and to set the
alarm.
•
Unlocking: Press the upper section of the
switch. A long press (for several seconds)
also opens all the side windows.
•
Locking: Press the lower section of the
lock button.
NOTE
•
The ignition key must be in position I or
higher (see page 143) before all side
windows can be opened using the
switches in the front doors.
•
The doors cannot be opened by pulling
up the lock buttons.
•
Each door can also be locked manually
using the lock button on that particular
door. This applies only if the car has not
been locked from the outside.
•
The doors can also be unlocked (and
the door opened) by pulling the handle
in the door twice.
Locking the glove compartment
G020034
The glove compartment can only be locked
and unlocked using the detachable key blade
on the remote control, see page 120 for infor-
mation on removing the key blade from the
remote control.
Insert the key blade in the glove compart-
ment lock.Turn the key blade 90 degrees clockwise.
The key slot will be in the horizontal posi-
tion.Remove the key blade from the lock.
1This function must be set to On in the Personal settings menu (see page 83)

10 AudioAudio functions
10242
Tracks can be selected in two ways:•
Turn the Tuning knob (no. 4 in the illustra-
tion on page 244) clockwise or counter-
clockwise
•
Use the right or left arrow keys on the nav-
igation control (no. 5 in the illustration on
page 244) to select the desired track. The
arrow keys on the steering wheel keypad
can also be used in the same way.NOTE
The system supports playback of files in the
most common versions of formats such as
mp3, wma, and wav. However, there may be
versions of these formats that the system
does not support.USB flash driveTo simplify the use of a USB flash drive, it is
advisable to only store music files on the drive.
It will take considerably longer for the system
to index the files on the drive if it contains any-
thing other than compatible music files.MP3 playerMany mp3 players have a file indexing system
that is not supported by the vehicle's audio
system. In order to use an mp3 player, the sys-
tem must be set to USB Removable device/
Mass Storage Device.
iPodAn iPod receives current and its battery is
charged through the connecting cord. How-
ever, if the iPod's battery is completely
drained, it should be recharged before the iPod
is connected to the audio system.
NOTE
When an iPOD is used as a sound source,
the vehicle's audio system has a menu
structure similar to the one in the iPOD. See
the iPOD's manual for detailed information.For further information, refer to the accessory
manual USB/iPod Music Interface.Sound settingsOptimal sound reproductionThe audio system is calibrated for optimal
sound reproduction through the use of digital
signal processing. This calibration takes into
account the speakers, amplifier, cabin acous-
tics, the seating position of the listener, etc., for
each combination of vehicle and audio system.
There is also dynamic calibration that takes
into account the setting of the volume control,
radio reception, and the vehicle's speed. The
sound settings described in this manual, such
as
BASS
,TREBLE
, and
EQUALIZER
are onlyintended to enable the user to adapt sound
reproduction to his/her personal preferences.
1.
PressSOUND (5). Press this button
repeatedly until you come to the setting
that you wish to change.
2.
Turn the TUNING dial (4) to make the
desired setting.
The following settings can be made:
BASS
–set the bass level
TREBLE
–set the treble level
BALANCE
–set the left/right sound balance
FADER
–set the front/rear sound balance
SUBWOOFER
(accessory)–set the level for
the subwoofer (bass speaker)
CENTER
–make settings for the center speaker
SURROUND
–make settings for surround
sound
Subwoofer (accessory)To switch the subwoofer on or off:
1.
PressMENU followed by ENTER.
2.
Select
AUDIO SETTINGS
and press
ENTER.
3.
Select
SUBWOOFER
and press ENTER.

12 Index
12
277
fluid.....................................................219
general information............................. 153
Bulbs
headlights........................................... 223
list of................................................... 272
Bulbs, replacing....................................... 223
CCapacities, fluids..................................... 267
Capacity weight............................... 183, 265
Cargo area
steel grid............................................. 113
Cargo area cover..................................... 113
Cargo area net................................. 114, 115
Catalytic converter, three-way................. 274
CD changer.............................................. 249
CD player................................................. 249
Cell phone, hands-free connection......... 254
Central locking system - remote control. 118
Chains...................................................... 186
Changing a wheel.................................... 190
Child restraints
recalls and registration......................... 45Child restraint systems.............................. 36
booster cushions.................................. 41
convertible seats.................................. 39
infant seats........................................... 37
ISOFIX/LATCH anchors........................ 42
top tether anchors................................ 44
Child safety................................................ 34
booster cushions.................................. 41
child restraint systems.......................... 36
convertible seats.................................. 39
infant seats........................................... 37
Child safety locks....................................129
Climate system
air distribution....................................... 99
air vents................................................ 92
Electronic Climate Control.................... 96
manual climate control......................... 93
passenger compartment filter.............. 90
refrigerant.....................................90, 267
Climate system, general information......... 90
Clock
setting...................................................82
Coat hanger............................................. 108
Cold weather precautions........................ 137
Compact disc care..................................251
Compass in rearview mirror....................... 77Conserving electrical current................... 138
Convertible seats....................................... 39
Coolant.................................................... 267
changing............................................. 218
checking level of................................. 218
Courtesy lighting...................................... 105
Crash mode............................................... 33
Cruise control............................................ 68
Cup holders.....................................107, 109
Curb weight.....................................183, 265
DDetachable key blade.............................. 120
Detachable trailer hitch............................ 162
Dimensions.............................................. 264
Disabling the passenger's side front air-
bag............................................................. 26
Disconnecting the front passenger’s air-
bag............................................................. 26
Display....................................................... 58
Dolby Pro Logic II (DPL II)........................ 243
Door mirrors............................................... 78
