02 Locks and alarm
Locks
02``61 Locking and unlocking the vehicle
From outside the vehicleThe remote key locks all of the doors and the
trunk.
The first press on the unlock button unlocks the
driver's door and a second press unlocks the
other doors and the trunk (see also page 52).
NOTE
The vehicle cannot be locked if a door is
open.From inside the vehicle
G019216
The lock buttons on the door panel can be used
to lock or unlock all doors and the trunk at the
same time.
Unlocking±
Press the unlock button.Locking±
Press the lock button after the front doors
have been closed.•
Each door can be locked individually with
the lock button on the respective doors.
The door must be closed first.
•
The door can be unlocked by pulling the
door handle once and opened by pulling
the handle again.
Automatic relockingIf the doors are unlocked, the locks will auto-
matically reengage (re-lock) and the alarm will
rearm after 2 minutes unless a door or the trunk
has been opened.Automatic lockingWhen the vehicle starts to move, the doors and
trunk can be locked automatically. This feature
can be turned on or off under Car settings
Lock settings
Doors automatic lock.
See page 120 for a description of the menu
system.
Glove compartment
G020548
The glove compartment can only be locked
and unlocked using the detachable key
blade in the remote key. See page 55 for
information on removing the key blade
from the remote key. Insert the key blade
in the glove compartment lock.Turn the key blade 90 degrees clockwise.Remove the key blade from the lock.

03 Your driving environmentInstruments and controls
0376
If the vehicle is driven at a speed
higher than approximately 5 mph
(7 km/h), the warning symbol comes on.
Trip odometers
G010608
Trip odometers and reset button
Odometer displayButton for toggling between T1 and T2,
and for resetting the odometer
The trip odometers are used to measure short
distances. A short press the button toggles
between the two trip odometers T1 and T2. A
long press (more than 2 seconds) resets an
active trip odometer to zero. The distance is
shown in the display.
Clock
G010609
Clock and setting control
DisplayControl for setting the clock
Turn the control clockwise/counterclockwise
to set the time. The set time is shown in the
information display.
The clock may be temporarily replaced by a
symbol in conjunction with a message, see
page 121.
Analogue clock (S80 Executive only)
G029076
Analogue clock
Button for setting the clock back.Burton for setting the clock ahead.
The analogue clock is located on the dash-
board, above the glove compartment.
Use either of the buttons to move the clock's
hands back or ahead. This can be done in two
ways:
To set the clock 1:
1. Hold down the button.
> The hand will move slowly for the first
5 minute time change and then move
faster.
2. Release the button when the time shown
on the clock is correct.

04 Comfort and driving pleasureAudio system
04134
Audio functions
G018382
Center console, controls for audio functions
Internal audio sources: AM, FM and CDExternal audio source. For connection, see
page 131Push button and knob controls for making
sound settingsNavigation buttonVolume and on/off
Audio volume and automatic volume
controlThe audio system compensates for disrupting
noises in the passenger compartment by
increasing the volume according to the speedof the vehicle. The level of sound compensa-
tion can be set at low, medium or high. Select
the level under Audio settings
Auto
volume control.
External audio source audio volumeExternal devices such as an MP3 player can be
connected to the AUX input, see page 131. The
volume of the external sound source AUX may
be different from the volume of the internal
sound sources such as the CD player or the
radio. If the external sound source's volume is
too high, the quality of the sound may be
impaired. To help prevent this, adjust the input
volume of the external audio source:
1. Set the audio system in AUX mode using
MODE and use (4) to navigate to
Volume,
AUX input
.
2.
Turn the control (3) or press
/
the nav-
igation button.
Sound settingsPress the control (3) repeatedly to toggles
among the sound settings. Adjustments are
made by turning the control (3).•
Bass
– Bass level.
•
Treble
– Treble level.
•
Fader
– Balance between the front and
rear speakers.
•
Balance
– Balance between the right and
left speakers.
•
Subwoofer
(option on certain markets
only) – Level for the bass speaker. The sub-
woofer can be switched off by turning con-
trol (3) counterclockwise to
MIN
.
•
Surround
(option) – Surround settings.
Under
Surround,
3 channel stereo or Dolby
Surround Pro logic II can be activated by
selecting
3-ch
or
Dpl2
respectively. This ena-
bles the following options:
•
Center level
1 – Level for the center
speaker.
•
Surround level
1 – Level for surround
sound.
EqualizerSound levels for different frequencies can be
adjusted separately using the equalizer
2.
1.
Go to
Audio settings
and select
Equalizer Front
or
Equalizer Rear
.
The sound level for the frequency is
adjusted with
/
on the navigation but-
ton. Press
/
to select another fre-
quency.
1Premium Sound2Certain audio systems

07 Index
07280
side marker lights...............................223
specifications...................................... 226
CCapacity weight....................................... 250
Cargo area
changing bulbs................................... 225
Catalytic converter................................... 200
CD player/changer........................... 135, 136
Cell phone, hands-free connection......... 142
Central locking system, introduction......... 50
Chains...................................................... 251
Check engine light..................................... 72
Child restraints
recalls and registration......................... 44
Child restraint systems.............................. 35
booster cushions.................................. 41
convertible seats.................................. 39
infant seats........................................... 37
ISOFIX/LATCH anchors........................ 42
top tether anchors................................ 43
Child safety.......................................... 33, 34
booster cushions.................................. 41
child restraint systems.......................... 35convertible seats.................................. 39
infant seats........................................... 37
Child safety locks...................................... 47
Climate system........................................ 128
air distribution............................. 125, 130
air vents.............................................. 126
Interior Air Quality System.................. 125
introduction......................................... 124
passenger compartment filter............ 125
refrigerant........................................... 124
Clock
analogue............................................... 76
Clock, setting............................................. 76
Cold weather driving................................ 196
Collision warning system......................... 159
Compass in rearview mirror..................... 152
Conserving electrical current................... 195
Convertible seats....................................... 39
Coolant............................................218, 276
Cooling system, general information....... 195
Courtesy lighting.................................. 91, 92
Crash mode............................................... 32
Cruise control..................................157, 158
adaptive......................165, 166, 167, 168Curb weight............................................. 250
Current, conserving................................. 195
DDefroster.................................................. 128
Detachable key blade................................ 55
Disconnecting the front passenger’s air-
bag....................................................... 23, 24
Dome lighting....................................... 91, 92
Door mirrors............................................... 98
Driver distraction warning............................ 9
Driving economically................................ 194
Driving in cold weather............................ 196
Driving through water..............................195EECC.......................................... 127, 128, 129
Economical driving..................................194
Electric parking brake.............................. 114
Electronic Climate Control.......126, 128, 129
air distribution table............................ 130

07 Index
07284
Recalls, child restraints.............................. 44
Refrigerant............................................... 276
Refrigerator (S80 Executive only)............ 190
Refueling..........................................198, 199
fuel filler cap....................................... 200
fuel filler door...................................... 200
fuel tank volume.................................276
Registering child restraints........................ 44
Remote control.......................................... 50
approach lighting.................................. 52
common functions................................ 52
immobilizer........................................... 50
key blade........................................ 50, 55
key memory.......................................... 50
locking the vehicle................................ 52
Personal Car Communicator..........52, 53
replacing the battery............................. 55
unlocking the vehicle............................ 52
Reporting safety defects............................ 15
Roadside Assistance............................... 278
Roof loads................................................ 204
SS80 Executive
analogue clock..................................... 76
front seat lumbar support..................... 85
front seat massage function................. 85
glasses................................................ 190
moving the front passenger's seat....... 86
refrigerator.......................................... 190
Safety, occupant........................................ 14
Safety defects, reporting........................... 15
Seat belts
Automatic locking retractor/Emergency
locking retractor.................................... 34
buckling................................................ 16
maintenance......................................... 16
pretensioners........................................ 16
reminder................................................ 16
reminder warning light.......................... 74
securing child restraint sys-
tems.......................................... 37, 39, 41
unbuckling............................................ 16
use during pregnancy........................... 17
using.....................................................16
Seats, front..........................................80, 85
Side door mirrors....................................... 98
Side impact airbags................................... 27Side marker lights, changing bulbs......... 223
Sirius satellite radio.................. 138, 140, 141
Snow chains............................................ 251
Snow tires................................................ 251
Sound settings, audio system................. 134
Spare tire................................................. 253
Speed-dependent steering...................... 156
Spin control............................................. 154
SRS............................................................ 18
Stability system........................................ 154
indicator light........................................ 73
Starting the engine................................... 105
with keyless drive...............................106
Starting the vehicle
after a crash (crash mode).................... 32
Start inhibitor (immobilizer)........................ 50
Steering wheel
adjusting............................................... 87
horn....................................................... 87
keypad.................................. 87, 120, 131
Stone chips, touching up......................... 267
Storage spaces........................................ 187
Studded tires........................................... 251
Sunroof (moonroof).......................... 100, 101
