2009 VOLVO C30 check engine light

09 Maintenance and servicing
Maintaining your car
09
203
your vehicle diagnosed and, if necessary,
serviced by a qualified Volvo technician.
•
If you recently had service for a lit Check
Engine light, or if you had service that
required disconnecting the battery, a
period of driving is necessary to bring the
OBD II system to "ready" for inspection. A
half-hour trip of mixed stop-and-go/high-
way driving is typically needed to allow
OBD II to reach readiness. Your Volvo
retailer can provide you with more infor-
mation on planning a trip.
•
Maintain your vehicle in accordance with
your vehicle's maintenance schedule.

09 Maintenance and servicing
Battery
09``211 Battery maintenance
Driving habits and conditions, climate, the
number of starts, etc., all affect the service life
and function of the battery. In order for your
battery to perform satisfactorily, keep the fol-
lowing in mind:
Check the fluid level in each cell in the battery
every 24 months or every 15,000
1 miles
(24,000 km), whichever is sooner.
•
Use a screw driver to open the caps or
cover and a flashlight to inspect the level.
•
If necessary, add distilled water. The level
should never be above the indicator.
•
The fluid level should be checked if the
battery has been recharged.
•
After inspection, be sure the cap over each
battery cell or the cover is securely in
place.
•
Check that the battery cables are correctly
connected and properly tightened.
•
Never disconnect the battery when the
engine is running, or when the key is in the
ignition. This could damage the vehicle's
electrical system.
•
The battery should be disconnected from
the vehicle when a battery charger is used
directly on the battery.
WARNING
PROPOSITION 65 WARNING!
Battery posts, terminals, and related acces-
sories contain lead and lead compounds,
chemicals known to the state of California
to cause cancer and reproductive harm.
Wash hands after handling.Battery symbols:
Wear protection gogglesSee owner's manual for
detailsKeep away from children
CorrosiveNo smoking, no open flames,
no sparksExplosion
Battery replacementRemoving the battery1. Switch off the ignition and remove the key.
2. Wait at least 5 minutes after switching off
the ignition before disconnecting the bat-
tery so that all information in the vehicle's
electrical system can be stored in the con-
trol modules.
1More frequently in warm climates.

12 Index
12268
Electronic Climate Control (ECC) - option. 96
Emergency brake....................................... 75
Emergency locking retractor...................... 36
Emergency starting.................................. 155
Emergency towing................................... 153
Emission inspection readiness................ 202
Engine
specifications...................................... 260
starting................................................ 142
starting with keyless drive.................. 144
Engine compartment overview................ 205
Engine oil................................................. 206
changing............................................. 206
checking............................................. 206
specifications...................................... 259
volumes.............................................. 257
Equalizer, audio system........................... 233
Eyelets for anchoring loads..................... 113
FFederal Clean Air Act............................... 200
Flat tires
changing............................................. 181
repairing with tire sealing system....... 183
Fluids and oils.......................................... 257
FM1/FM2 menu....................................... 234
Fog lights
front...................................................... 63
rear........................................................ 64
Front airbags.............................................. 22
disconnecting passenger’s side airbag 26
Front fog lights........................................... 63
Front park assist...................................... 161
Front seats............................................... 102
accessing the rear seat...................... 102
manually operated.............................. 102
power.................................................. 103
Fuel filler door
unlocking.............................................. 64
Fuel gauge................................................. 53
Fuel requirements.................................... 138
Fuel tank volume...................................... 257
Fuses, replacing....................................... 221
GGasoline requirements............................. 138
Geartronic................................................ 147
Generator................................................. 262
Glossary of tire terminology..................... 174
Glove compartment................................. 108
locking................................................ 127
Gross vehicle weight (GVW)............175, 255HHand brake (parking brake)....................... 75
Hands-free connection (cell phone) (Cell
phone, hands-free connection)................ 244
Hazard warning flashers............................ 74
Headlights.................................................. 63
changing bulbs................................... 213
high and low beams............................. 65
high beam flash.................................... 65
Headlight washers..................................... 71
High beam flash......................................... 65
High beams................................................ 65
Home safe lighting............................... 65, 83

12 Index
12
269
Hood, opening......................................... 204IIgnition switch.......................................... 141
Immobilizer.............................................. 142
Immobilizer (start inhibitor)...................... 118
Indicator and warning symbols............ 53, 55
Inflatable Curtain........................................ 30
Inflation pressure..................................... 168
Inflation pressure, checking..................... 169
Inflation pressure table
Canadian models................................ 171
US models.......................................... 170
Information display..............................53, 60
messages in.......................................... 60
Information symbol.................................... 55
Inspection, preparing for......................... 202
Inspection readiness................................ 202
Instrument overview.................................. 50
Instrument panel.................................. 50, 53
Instrument panel lighting........................... 64
Interior lighting......................................... 106iPOD connector (audio system)...............231
ISOFIX/LATCH anchors............................. 44
JJacket hanger.......................................... 108
Jump starting........................................... 155KKey blade.........................................120, 124
Keyless drive
location of antennas (pacemaker warn-
ing)...................................................... 125
locking and unlocking the vehicle...... 123
power seat memory............................ 124
starting the engine.............................. 144
Keylock.................................................... 142
Kickdown.................................................147
LLabel information..................................... 252
LATCH (ISOFIX) anchors........................... 44
Liftgate wiper........................................... 210
Liftgate wiper/washer................................ 72
Lighting panel............................................ 63
Load anchoring eyelets........................... 113
Loading the vehicle
roof loads............................................ 156
Locking
from the inside.................................... 127
glove compartment............................. 127
Locking the vehicle.................................. 123
Long distance trips.................................. 136
Lug nuts (wheel nuts)............................... 179MMaintenance............................................ 200
performed by the owner.....................202
Manual climate control.............................. 93
Manual transmission................................ 145
Mirrors.................................................. 77, 78
