Select the Settings menu.
In the Service submenu, select the Info menu item.
OR: If the Vehicle status main menu is active, use the arrow but-
tons to navigate to the service reminder display.
A minus sign in front of the number of miles (kilometers) or days
means that service is overdue.
Resetting the oil change service reminder
If the service was not performed by an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility, the oil change service
reminder can be reset as follows:

1. Switch off the ignition.
2. Press and hold the /./

▪ Speed warning --- mph
Audio ⇒ Booklet Radio or ⇒ Booklet Navigation system
Navigation ⇒ Booklet Navigation system
Phone ⇒ Booklet Mobile Phone Package
Assistants
▪ AFS
Vehicle status
Settings
▪ Language
▪ MFI data
– Travel time
– Curr. consum. (current fuel consumption)
– Av. consum. (average fuel consumption)
– Route
– Av. speed (average speed)
– Digit. speed (digital speed display)
– Oil temperature (3.6 liter engine only)
– Speed warn. (speed warning)
– Back
▪ Convenience
– ATA confirm
– Easy Open (on/off)
– Central locking
Auto lock
Auto unlock
Unlock doors
Back
– Window op. (window operation)
Off
All
Driver
Back
– Mirror down (on/off)

Display Function
Av. consumption
--.- l/100 km
(toggle) is displayed once the vehicle has been
driven about 330 feet (100 m). Until then, dash-
es appear instead of a number. The value dis-
played is updated every 5 seconds.
Range  -- mi Estimated distance in miles (km) that the vehicle
can go with the fuel left in the tank the way you
are currently driving. Takes account of the cur-
rent fuel consumption, among other things. Range  -- km
Route -- mi Distance driven in miles (km) per trip memories
1 and 2 (toggle).
Route -- km
Average speed
-- mph
Average speed on trips per trip memories 1 and
2 (toggle). Displayed once the vehicle has been
driven about 300 feet (100 m). Until then, dash-
es may appear instead of a number. The value
displayed is updated every 5 seconds.
Average speed
-- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
Oil temperature Current engine oil temperature (digital display;
3.6 liter engine only).
Speed warning
--- mph
When the set speed (from 20–155 mph or 30–
250 km/h) is exceeded, an acoustic warning
sounds and a visual message may also appear
in the instrument cluster display. Speed warning
--- km/h

Switching between the displays
Use the arrow up and down buttons (* and +) on the multi-
function steering wheel.

d For gasoline engines: Is unleaded fuel with the right octane rating
readily available?
d Are engine oil (⇒ Engine oil) and other operating fluids that meet
Volkswagen quality and performance requirements available where
you will be driving? For more information, please see
⇒ Booklet Warranty and Maintenance.
d Does the factory-installed navigation system work in the countries
where you will be driving, and is navigation data available?
d Are special or heavy-duty tires necessary for the kind of driving
expected?
NOTICE
Volkswagen is not responsible for mechanical damage that may
result from substandard fuel or service or the unavailability of
Genuine Volkswagen parts.
Driving through water on roads

Length 189 in – 193 in (4802 –
4902 mm)
Width 73 in (1855 mm)
Height (unloaded) 55.7 – 56.1 in (1417 –
1425 mm)
Wheelbase 106.6 in (2708 mm)
Minimum turning circle diameter
(wall to wall)2
37.4 ft (11.4 m)
Track2, front 61.1 – 61.3 in (1552 –
1556 mm)
Track2, rear 61.3 – 61.5 in (1557 –
1562 mm)
Ground clearance (unloaded) 4.9 in (124 mm)

NOTICE
Please be careful when parking your vehicle in areas with
parking barriers or curbs. These vary in height and could dam-
age your bumper and related parts if the front of your vehicle
hits a barrier or curb that is too high while you are getting into or
out of a parking spot.
Always be careful when you enter a driveway or drive up or
down steep ramps or over curbs or other obstacles. Parts of the
vehicle close to the ground may be damaged (such as bumper
covers, spoilers, and parts of the engine, suspension, and ex-
haust systems).

2 Slight differences to these figures are possible, depending on wheel and tire size fitted and the level selected.

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Whenever stalled or stopped for repair, move the vehicle a
safe distance off the road, stop the engine, turn on the emer-
gency flashers, and use other warning devices to warn ap-
proaching traffic.
Never park the vehicle in areas where the hot catalytic con-
verter and exhaust system can come into contact with dry
grass, brush, spilled fuel, oil, or other material that can catch
fire.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
High Intensity Discharge (HID) headlights provide bright, uniform
lighting to help you see and be seen. The light comes from an electric
arc between two electrodes in the gas-filled bulb. Over time, the elec-
trodes can wear down and the gap between them will get wider. The
HID lamp’s control unit then increases the voltage to keep the arc’s
brightness constant. However, the commonly called “Xenon” bulbs
will also ultimately burn out. Before they burn out, HID lamps can
flicker. A message will then appear in the MFI. This is your reminder
to see an authorized Volkswagen dealer or an authorized
Volkswagen Service facility to check the headlights.

Recommended cleaners
For the warmer months, Windscreen Clear SummerG 052 184 A1
or equivalent. Mixing ratio 1:100 (1 part concentrate to 100 parts wa-
ter) in the windshield washer reservoir.
All-season Windscreen ClearG 052 164 A2 or equivalent. Mixing
ratio in winter to 0 °F (-18 °C) about 1:2 (1 part concentrate to 2 parts
water), otherwise, mixing ratio 1:4 in the windshield washer reservoir.
Filling capacity
The windshield washer fluid reservoir holds about 3.1 qts. (3 liters); in
vehicles with a headlight cleaning system about 6.3 qts. (6 liters).
WARNING
Never mix antifreeze or similar additives into the windshield
washer reservoir. This could produce an oily film on the wind-
shield, which would considerably reduce visibility.
Use clear water with a cleaning solution recommended by
Volkswagen.
If necessary, blend with a suitable windshield washer fluid
antifreeze agent.
NOTICE
Never mix cleaning solutions recommended by Volkswagen
with other cleaning agents. If you do, this could cause sedi-
ments or other by-products that can clog the windshield washer
nozzles.
When refilling, do not confuse one type of operating liquid
with another! Otherwise serious malfunctions and engine dam-
age can occur!

The tires and wheels are essential parts of the vehicle's design. The
tires and wheels approved by Volkswagen are specially matched to
the characteristics of the vehicle for good road holding and safe han-
dling when in good condition and properly inflated.
Avoiding tire damage
If you must drive over a curb or other obstacle, drive very slowly
and as much as possible at a right angle to the curb with the tire tread
of both front wheels contacting the curb at the same time.
Regularly check tires for damage, such as punctures, cuts, tears
and blisters.
Remove embedded material in the tread profile that has not yet
penetrated the inside of the tire ⇒ Tire wear and damage.
Heed all warning messages from the Tire Pressure Monitoring Sys-
tem
Replace worn or damaged tires immediately ⇒  Tire wear and
damage.
Damage to tires and wheels is often not readily visible. If you notice
unusual vibration or the vehicle pulls to one side, this may indicate
that one of the tires is damaged. The tires must be checked immedi-
ately for hidden damage by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility. See also ⇒ Tire wear and
damage.
Never exceed the load and permissible maximum speed rating of
the tires ⇒ Tire labeling.
Always keep aggressive chemicals including grease, oil, gasoline
and brake fluid off the tires, including the spare wheel ⇒ .
Replace missing valve caps immediately.
Unidirectional tires
Unidirectional tires are designed to rotate only in one direction. Unidi-
rectional tires have arrows on the sidewalls that show the direction of
rotation ⇒ Tire labeling. Unidirectional tires must always be mounted
according to the specified direction of rotation in order to deliver their
best grip, braking performance, low road noise, and good wear as
well as good hydroplaning resistance.
If you have to mount a tire opposite to its proper direction of rotation,
you must drive more carefully, since the tire is no longer being used
as designed. This is particularly important on wet roads. You must
