(2) Strap indicating the location of the storage compartment handle
(3) MDI (MEDIA-IN) jack in the pull-down storage compartment
Opening and closing the glove compartment
If necessary, unlock the glove compartment with the emergency key
⇒  Vehicle key set. It is locked when the key slot is vertical.
To open, pull the handle ⇒ fig. 124.
To close, push the lid up.
Opening and closing the storage compartment for the Owner's
Manual or MDI (MEDIA-IN) jack
Depending on equipment, the storage compartment at the top of the
glove compartment is designed to hold either the Owner's Manual or
the MDI (MEDIA-IN) jack.
The Owner's Manual compartment or MDI (MEDIA-IN) jack is located
in a storage compartment at the top, which can be pulled down to
open ⇒ fig. 125 (3).
The strap (2) indicates the handle for opening the storage compart-
ment.
If the vehicle is not equipped with the MDI (MEDIA-IN) jack, always
keep the Owner's Manual in this storage compartment. To stow the
Owner's Manual, place it in the slot with the binding facing the inside
of the glove compartment door.
Holders
Depending on the model, there may be holders for a pen and a note-
pad in the glove compartment.
Cooling the glove compartment
There is an air vent (1) in the back of the glove compartment. Cool air
can be directed into the glove compartment if the air conditioner is on.
Open or close the air vent by turning it.

When adding engine coolant, use a mixture of distilled water and at
least 40% coolant additive G 13 or G 12 plus-plus (TL-VW 774 G) for
optimum corrosion protection ⇒ .
Do not mix G 13 with G 12 plus or G 11. Mixing these coolant addi-
tives together significantly reduces corrosion protection ⇒  and can
lead to engine damage that is not covered by any Volkswagen Lim-
ited Warranty.
WARNING
Too little antifreeze protection in the engine cooling system can
cause engine failure and severe injuries.
Always make sure there is enough of the correct coolant ad-
ditive to provide proper antifreeze protection at the coldest
temperatures that can be expected where the vehicle will be
used.
At extremely cold temperatures, the coolant could freeze,
causing the vehicle to break down. The heater would also not
work, and vehicle occupants could be without protection at
subfreezing temperatures.
NOTICE
Never mix original Volkswagen engine coolant additives with
other additives not approved by Volkswagen. Mixing
Volkswagen coolant additives with coolant additives made by
other manufacturers can seriously damage the engine and the
engine cooling system.
If the fluid in the engine coolant reservoir is any color but pink,
then G 13 was mixed with a different engine coolant. If this is the
case, the engine coolant must be replaced immediately. Other-
wise serious malfunctions or engine damage can occur!
Engine coolant and engine coolant additives can pollute the envi-
ronment. Collect leaking operating fluids and dispose of them proper-
ly in accordance with applicable environmental laws and regulations.

failure. If you have added non-distilled water, take the vehicle
immediately to an authorized Volkswagen dealer or an author-
ized Volkswagen Service Facility to have the coolant system
drained, flushed, and refilled completely with the proper coolant.
Refill engine coolant only up to the top edge of the marked fill
range ⇒ fig. 168. Excess engine coolant may be forced out of the
engine cooling system when it gets hot and cause damage.
In the case of significant engine coolant loss, refill engine
coolant only when the engine is completely cooled down. Signif-
icant engine coolant loss is a sign of leaks in the cooling sys-
tem. Have the engine cooling system checked immediately by an
authorized Volkswagen dealer or an authorized Volkswagen Ser-
vice Facility. Otherwise the engine may be damaged!
When changing or topping off operating fluids, make sure that
you pour the fluids into the correct reservoirs. Serious malfunc-
tions and engine damage can result if you pour operating fluids
into the wrong reservoir.

Cleaning upholstery on non-heated seats, manual seats, or seats
without airbag components
Before using any cleaning agent, familiarize yourself with instruc-
tions and warnings on the packaging.
Vacuum upholstery, fabric trim, Alcantara® upholstery, and carpet-
ing regularly with a suitable brush attachment.
Do not use power washers, steam cleaners, or cooling spray.
A soft sponge or a commercially available lint-free microfiber cloth
may be used for general cleaning ⇒ .
Clean Alcantara® surfaces with a damp cotton or wool cloth or a
commercially available lint-free microfiber cloth ⇒ .
Upholstery and fabric trim with light generalized soiling can be
cleaned with a commercially available dry-foam cleaner.
If the upholstery and fabric trim pieces are heavily soiled, see your
authorized Volkswagen dealer or authorized Volkswagen Service
Facility before you begin cleaning to learn about suitable cleaning
options. If necessary, have the cleaning done by a professional.
Treating stains
When treating stains, it may be necessary to clean the entire surface
and not just the stain itself. This is especially true if the entire surface
has become dirty from normal use. Otherwise, the area that is treated
may become lighter than the untreated area. If you have questions or
concerns, consult a professional cleaner.

Type of stain Recommended cleaning for fabric and uphol-
stery
Water-based
stains, such as
coffee or fruit
juice.
– Moisten a sponge with water and rub the stain
gently with a circular motion.
– Wipe dry with an absorbent cloth.
Persistent stains,
such as choco-
late or make-up.
– Use only Volkswagen-approved cleaning prod-
ucts.
– If necessary, have the fabric or upholstery pro-
fessionally cleaned.

Type of stain Recommended cleaning for fabric and uphol-
stery
Grease-based
stains, such as
oil, lipstick, etc.
– Use only Volkswagen-approved cleaning prod-
ucts.
– If necessary, have the fabric or upholstery pro-
fessionally cleaned.

WARNING
If there is a malfunction in the airbag system, the airbag may
not deploy correctly or at all, or it may deploy unexpectedly.
This could cause fatal injuries.
Have the airbag system inspected immediately by your au-
thorized Volkswagen dealer or authorized Volkswagen Service
Facility.
NOTICE
If the upholstery on power seats, heated seats, or seats with air-
bag components is wet, electrical components and the vehicle
electrical system could be damaged.
If the seating surface becomes soaked, have it dried and the
system components checked immediately by an authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
Do not use steam cleaners because the steam could cause the
dirt to penetrate deeper into the fabric and make it impossible to
remove.
Power washers and cooling sprays can damage the uphol-
stery.
NOTICE
Clean only the carpet and floor mats with brushes. Other tex-
tile surfaces can be damaged by brushes.
If detergent pastes or mild detergent solutions are applied with
a damp cloth or sponge, the surfactants in the detergent may
cause visible lines to form at the edges of the area where the

WARNING
Improper use of operating fluids and equipment can cause ac-
cidents, serious personal injuries, burns and/or poisoning.
Always store vehicle care products in a safe place in original
containers that are securely closed.
To reduce the risk of poisoning, never use empty food or
beverage containers that might mislead someone into drinking
from them.
Always keep vehicle care products out of the reach of chil-
dren.
Always read and heed all the instructions and all WARNINGS
on the package before using vehicle care products.
When using products that give off harmful fumes, always
work outdoors or in a well ventilated area.
Never use fuel, turpentine, engine oil, nail polish remover or
other volatile fluids for vehicle care. They are poisonous and
highly flammable. They could cause fires and explosions!
NOTICE
Only refill with suitable operating fluids. When changing or
topping off fluids, make sure that you pour the fluids into the
correct reservoirs. Adding incorrect fluids will cause serious
malfunctions and engine damage! Under no circumstances
should you mix up operating fluids. Otherwise serious malfunc-
tions and engine damage can occur!
Accessories and other things installed in front of the cooling
air intakes impair the efficiency of the engine coolant. The en-
gine can overheat under high outside temperatures or under
high engine loads!
Leaking operating fluids can pollute the environment. Collect
leaking operating fluids in suitable containers and dispose of them
properly in accordance with applicable environmental laws and regu-
lations.
