2009 TOYOTA PRIUS change language

BASIC FUNCTIONS
20
When the “POWER” switch is in ACCES-
SORY or ON mode, the initial screen will
be displayed and the system will begin op-
erating.
CAUTION
When the vehicle is stopped with the
hybrid system operating, always ap-
ply the parking brake for safety.
After a few seconds, the “CAUTION”
screen will be displayed.
0U5701T
After about 5 seconds, the “CAUTION”
screen automatically switches to the map
screen. When the “MAP/VOICE” button
is also pushed, the map screen is dis-
played.
While the “ CAUTION” screen is displayed,
the “DEST” or “MENU” button cannot be
operated. And if the “Language” , “Cal-
endar” or “Maintenance” buttons on the
“Information” screen are touched, the
screen will change back to “CAUTION”
screen and then change to the map screen
in about 5 seconds later or if the “MAP/
VOICE” button is pushed.
Maintenance information
This system informs about when to replace
certain parts or components and shows
dealer information (if registered) on the
screen.
When the vehicle reaches a previously set
driving distance or date specified for a
scheduled maintenance check, the “Infor-
mation” screen will be displayed when the
navigation system is in operation.
To disable this screen, touch “Do Not
Display This Message Again.”. This
screen goes off if the screen is not op-
erated for several seconds.
To prevent this information screen from be-
ing displayed again, touch “Do Not
Display This Message Again.” .
To register “Maintenance information”, see
“Maintenance information” on page 112.
08/06/25 Prius_Navi_U
OM47615U
Initial screen

ADVANCED FUNCTIONS
84
INFORMATION
During route guidance, the voice
guidance continues even if the navi-
gation screen is changed to other
screens.
“Adaptive Volume Control”: By turning
“Adaptive V olume Control” on, the volume
is turned up automatically when the ve-
hicle speed exceeds 50 mph (80 km/h).
To turn the “Adaptive Volume Control”
system on, touch the button. The indicator
will be highlighted.
User selection
The system can memorize the following
settings for up to three users.
Map direction
Map scale
Map configuration
Guidance mode
Setup
Volume
Language
Route trace
Travel time/arrival time
Right screen of dual map
Road preference
Maintenance notification
08/06/25 Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
100
Setup
Setting the items shown on the “Setup”
screen can be done. (See page 81.)
1. Push the “MENU” button.
4U5555T
2. Touch “Setup”.
3. Touch the items to be set.
4. Touch “OK”.
The previous screen will be displayed.
INFORMATION
To reset all setup items, touch “De-
fault”.
Distance unit
Distance unit can be changed.
1. Push the “MENU” button.
2. Touch “Setup” on the “Menu”
screen.
3. Touch “km” or “miles” of “Dis-
tance” to choose the distance unit.
The selected button is highlighted.
4. Touch “OK”.
INFORMATION
This function is available only in En-
glish or Spanish. To s witch language,
see “Selecting a language” on page
129.
08/06/25 Prius_Navi_U
OM47615U

OTHER FUNCTIONS
129
Beep setting
You can set a beep sound off.
1. Push the “INFO” button.
5U5603T
2. Touch “Beep Off”.
“Beep Off” is highlighted.
To switch the beep sound on, touch “Beep
Off” again.
Selecting a language
The language of the touch −screen but-
tons, pop−up messages and the voice
guidance can be changed.
1. Push the “INFO” button.
5U5604T
2. Touch “Language”.
08/06/25 Prius_Navi_U
OM47615U

OTHER FUNCTIONS
130
5U5706T
3. Touch “English”, “Français” or “Es-
pañol” to select a language.
If a screen other than for the navigation
system is displayed, the current screen
would change to the “CAUTION” screen by
pushing the “MAP/VOICE” , “DEST” or
“MENU” button.
4. Touch “OK”.
The language is changed and the screen
returns to the map display.
08/06/25 Prius_Navi_U
OM47615U

INDEX
148
P
Phone #
button 36. . . . . . . . . . . . . . . . . . . . .
POI as a destination 74 . . . . . . . . . . . . . . . . .
POI Category button 36 . . . . . . . . . . . . . . . .
POI category change 103 . . . . . . . . . . . . . . .
POI information 28 . . . . . . . . . . . . . . . . . . . . .
POI Name button 36 . . . . . . . . . . . . . . . . . . .
POIs near the search point 49 . . . . . . . . . . .
POIs to be displayed 72 . . . . . . . . . . . . . . . .
Pop−up message 81, 107
. . . . . . . . . . . . . . .
Position/direction calibration 108
. . . . . . . . .
Preset memory point 12
. . . . . . . . . . . . . . . .
Previous button 36
. . . . . . . . . . . . . . . . . . . . .
Q
Quick access 12
. . . . . . . . . . . . . . . . . . . . . .
Quick access touch− screen buttons 36
. . . . . . . . . . . . .
R
Registering area to avoid 95
. . . . . . . . . . . . .
Registering home 10, 94
. . . . . . . . . . . . . . . .
Registering memory points 88
. . . . . . . . . . .
Registering preset memory point 12 . . . . . .
Reordering destinations 66
. . . . . . . . . . . . . .
Resume guidance 83
. . . . . . . . . . . . . . . . . . .
Resume Guidance button 80
. . . . . . . . . . . .
Route button 8
. . . . . . . . . . . . . . . . . . . . . . . .
Route guidance screen 60
. . . . . . . . . . . . . .
Route overview 74
. . . . . . . . . . . . . . . . . . . . .
Route preference 57, 71
. . . . . . . . . . . . . . . .
Route preview 75
. . . . . . . . . . . . . . . . . . . . . .
Route trace 76
. . . . . . . . . . . . . . . . . . . . . . . .
S
Scale indicator 8
. . . . . . . . . . . . . . . . . . . . . .
Screen adjustment 124
. . . . . . . . . . . . . . . . .
Screen configuration button 8
. . . . . . . . . . .
Screen layout function 103
. . . . . . . . . . . . . .
Screen off 124
. . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 26
. . . . . . . . . . . . . .
Screen setting 126
. . . . . . . . . . . . . . . . . . . . .
Search condition 68
. . . . . . . . . . . . . . . . . . . .
Search point from destinations 49 . . . . . . . .
Search point via the map screen 48 . . . . . .
Select User button 80
. . . . . . . . . . . . . . . . . .
Selecting a language 129
. . . . . . . . . . . . . . .
Selecting the search area 38
. . . . . . . . . . . .
Setting and deleting destination 66 . . . . . . .
Setting home as the destination 15 . . . . . . .
Setting route 68
. . . . . . . . . . . . . . . . . . . . . . . Setup
100
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup button 80
. . . . . . . . . . . . . . . . . . . . . . .
Setup screen 81
. . . . . . . . . . . . . . . . . . . . . . .
Single map 31
. . . . . . . . . . . . . . . . . . . . . . . .
Single map screen 30
. . . . . . . . . . . . . . . . . .
Sort 24
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound icons 90
. . . . . . . . . . . . . . . . . . . . . . .
Speech command system 121
. . . . . . . . . . .
Speech command
system indicator 8
. . . . . . . . . . . . . . . . . . .
Starting route from adjacent road 71 . . . . . .
Starting route guidance 55
. . . . . . . . . . . . . .
Street name 41
. . . . . . . . . . . . . . . . . . . . . . . .
Suspend guidance 82
. . . . . . . . . . . . . . . . . .
Suspend Guidance button 80
. . . . . . . . . . . .
Suspending and
resuming guidance 82
. . . . . . . . . . . . . . . .
Switch color 127
. . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 30
. . . . . . . . . . . . . . .
T
Talk switch 121
. . . . . . . . . . . . . . . . . . . . . . . .
Time zone 102
. . . . . . . . . . . . . . . . . . . . . . . .
Tire change calibration 109
. . . . . . . . . . . . . .
Tone 124
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Touch sc reen operation 21
. . . . . . . . . . . . . .
Traffic restrict. notification 81
. . . . . . . . . . . .
Turn list screen 30, 62
. . . . . . . . . . . . . . . . . .
Typical voice guidance prompts 63 . . . . . . .
U
Unit of measurement 101
. . . . . . . . . . . . . . .
User selection 84 . . . . . . . . . . . . . . . . . . . . . .
V
Voice guidance in all modes 81, 106
. . . . . .
Voice recognition guidance 81, 105
. . . . . . .
Volume 83 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Volume button 80. . . . . . . . . . . . . . . . . . . . . .
Z
Zoom in button 8
. . . . . . . . . . . . . . . . . . . . . .
Zoom out button 8
. . . . . . . . . . . . . . . . . . . . .
08/06/25 Prius_Navi_U
OM47615U
