558 6-1. Specifications
Oil viscosity
●The 5W portion of the oil viscosity rating indicates the characteristic
of the oil which allows cold startabi lity. Oils with a lower value before
the W allow for easier starting of the engine in cold weather.
● The 30 in 5W-30 indicates the oil visc osity when the oil is at its oper-
ating temperature. An oil with a hi gher viscosity may be better suited
if the vehicle is operated at high speeds, or under extreme load con-
ditions.
Cooling system
*: With towing package
Capacity
(Reference)
2.7 L 4-cylin-
der (1AR-FE)
engine Without rear air conditioning system
7.3 qt. (6.9 L, 6.1 Imp. qt.)
8.0 qt. (7.6 L, 6.7 Imp. qt.)*
With rear air conditioning system
9.6 qt. (9.1 L, 8.0 Imp. qt.)
10.4 qt. (9.8 L, 8.6 Imp. qt.)*
3.5 L V6
(2GR-FE)
engine Without rear air conditioning system
9.3 qt. (8.8 L, 7.7 Imp. qt.)
10.0 qt. (9.5 L, 8.4 Imp. qt.)*
With rear air conditioning system
11.6 qt. (11.0 L, 9.7 Imp. qt.)
12.4 qt. (11.7 L, 10.3 Imp. qt.)*
Coolant type Use either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite, and
non-borate coolant with long-life hybrid
organic acid technology
Do not use plain water alone.

576 6-1. Specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

596 Alphabetical index
Electric power steering ........... 218
Electronic keyIf your electronic key battery is discharged .......................... 539
Emergency flashers
Switch.................................... 498
Emergency, in case of If the back door opener is
inoperative ............................74
If the electronic key does not operate properly.................. 539
If the engine will not start ...... 535
If the shift lever cannot be shifted from P...................... 537
If the vehicle has a discharged battery ................................. 541
If the warning buzzer
sounds... ............................ 510
If the warning light turns on ........................................ 510
If the warning message is displayed............................. 521
If you have a flat tire ............. 522
If you lose your keys/
wireless remote control
transmitter ........................... 538
If you think something is wrong .................................. 506
If your vehicle becomes
stuck ................................... 548
If your vehicle needs to be towed .................................. 499
If your vehicle overheats ....... 545 Engine
Compartment ........................ 437
Engine switch ................ 173, 177
Hood ..................................... 432
How to start the
engine ......................... 173, 177
Identification number............. 553
If the engine will not start ...... 535
Ignition switch ............... 173, 177
Overheating .......................... 545
Engine compartment cover .... 439
Engine coolant
Capacity ................................ 558
Checking ............................... 445
Preparing and checking before winter .................................. 238
Engine coolan t temperature
gauge ...................................... 188
Engine immobilizer system .... 115
Engine oil Capacity ................................ 556
Checking ............................... 440
Preparing and checking before winter .................................. 238
Engine oil maintenance data ......................................... 443
Enhanced vehicle stability control .................................... 218
Enhanced VSC ......................... 218
EPS............................................ 218
Event data recorder ................. 508E
