OVERVIEW
Indicator symbols
Instrument cluster
4
Tachometer
Service indicators and reminder
Speedometer
Vo l t m e t e r
Automatic Transmission indicator
Engine coolant temperature
Fuel gauge
Trip meter reset knob
Odometer and two trip meters
Battery warning1
Low engine oil pressure warning1
Brake system warning1
Malfunction/Check Engine indicator1
Engine oil replacement reminder1
Driver/Front passenger seat belt reminder1
(alarm will sound if speed is over 12 mph)
Open door warning1
1
For details, refer to “If a warning light turns on or a warning buzze\
r sounds” Section
5-2, 2009 Owner’s Manual.
2 For details, see “Rear differential lock system,” Section 2-4, 200\
9 Owner’s Manual.
Low fuel level warning1
M2.qxd 7/28/08 3:06 PM Page 4
OVERVIEW
Fuel tank door release and cap
6
Pull
Tu r nNOTE:Tighten
until one click is
heard. If the cap is
not tightened
enough, Check
Engine “ ”
indicator may
illuminate.
Keyless entry (if equipped)
Beep sound can be switched ON or OFF by customer. Refer to the Owner’s
Manual for more details.
NOTE:
After unlocking, if a door is
not opened within 60 seconds, all
doors will relock for safety.
Panic button
N
U
K
C
OL
K
C
OLC
I
N
A
P
Locking operationUnlocking operation
Push
Push and hold
Push ONCE: Driver door
TWICE: All doors
M2.qxd 7/28/08 3:06 PM Page 6
