37A-19
MECHANICAL COMPONENT CONTROLS
Brake servo: Removal - Refitting
RIGHT-HAND DRIVE
37A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
aRemove:
-the front right-hand wheel (see 35A, Wheels and
tyres, Wheel: Removal - Refitting, page 35A-1) ,
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the scoop under the scuttle panel grille (see Scoop
under the scuttle panel grille: Removal - Refit-
ting) (56A, Exterior equipment).aRemove:
-the fuel vapour recirculation solenoid valve pipes
(1) ,
-the fuel vapour recirculation solenoid valve con-
nector (2) ,
-the fuel vapour recirculation solenoid valve (3) ,
-the fuel vapour recirculation solenoid valve support
bolt (4) ,
-the fuel vapour recirculation solenoid valve support
(5) ,
-the brake master cylinder (see 37A, Mechanical
component controls, Master cylinder: Removal
- Refitting, page 37A-1) ,
-the brake servo non-return valve (see 37A, Me-
chanical component controls, Brake servo non-
return valve: Removal - Refitting, page 37A-11) .
aRemove the ignition coil (see Coils: Removal - Re-
fitting) (17A, Ignition). Special tooling required
Mot. 1672Low er engine support.
Equipment required
refrigerant charging station
Tightening torquesm
“brake - clutch pedal”
assembly nuts21 Nm
brake servo nuts21 Nm
123852
D4F or D7F
37A-23
MECHANICAL COMPONENT CONTROLS
Brake servo: Removal - Refitting
RIGHT-HAND DRIVE
37A
II - REFITTING OPERATION FOR PART
CONCERNED
aPosition the brake servo by moving the engine for-
ward as far as possible and tilting the pushrod up-
wards.
aRefit the brake servo from underneath the vehicle.
aRefit the brake servo.
aPosition the “brake - clutch pedal” assembly on the
bulkhead.
aTorque tighten the “brake - clutch pedal” assem-
bly nuts (21 Nm).
aRefit:
-the new dual safety connecting shaft between the
brake servo pushrod and the brake pedal from right
to left and from top to bottom,
-the brake servo nuts.
aTorque tighten the brake servo nuts (21 Nm).
III - FINAL OPERATION.
aRefit:
-the clutch master cylinder support,
-the clutch master cylinder support bolts,
-the clutch master cylinder rod on the clutch pedal.
aRefit the exhaust manifold (see Exhaust manifold:
Removal - Refitting) (12A, Fuel mixture).aRefit the catalytic converter (see Catalytic convert-
er: Removal - Refitting) (19B, Exhaust).
aRefit:
-the right-hand suspended engine mounting (see
Right-hand suspended engine mounting: Re-
moval - Refitting) (19D, Engine mounting),
-the rear suspended engine mounting (see Lower
engine tie-bar: Removal - Refitting) (19D, En-
gine mounting).
aRefit:
-the air filter box heat-resistant protector,
-the air filter box heat-resistant protector bolts,
-the air filter (see Air filter: Removal - Refitting)
(12A, Fuel mixture).
aRefit the "dehydrator reservoir - expansion valve"
connection (see Dehydrator reservoir - expansion
valve connecting pipe: Removal - Refitting) (62A,
Air conditioning).
aFill the refrigerant circuit using a refrigerant charg-
ing station (see Refrigerant circuit: Draining -
Filling) (62A, Air conditioning).
aRefit the ignition coil (see Coils: Removal - Refit-
ting) (17A, Ignition). D4F
K4M
JH3 or JR5
K4M
D4F, and 780
D4F
D7F
AIR CONDITIONING or CLIMATE CONTROL
D4F or D7F
