ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF090
PRESENT
OR
STOREDFRONT RIGHT-HAND WHEEL TARGET
NOTESPriorities when dealing with a number of faults:
Deal with fault DF026 Front right wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the target.
If the fault is still present, contact the Techline.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF090

38C-35
MR-413-X44-38C000$517_eng.mif
V1
38C
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
DF091
PRESENT
OR
STOREDFRONT LEFT-HAND WHEEL TARGET
NOTESPriorities when dealing with a number of faults:
Deal with fault DF006 Front left wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the target.
If the fault is still present, contact the Techline.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF091
MK70 ABS
Vdiag No: 04
MR-413-X44-38C000$517_eng.mif

38C-36
MR-413-X44-38C000$517_eng.mif
V1
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF092
PRESENT
OR
STOREDREAR RIGHT-HAND WHEEL TARGET
NOTESPriorities when dealing with a number of faults:
Deal with fault DF027 right rear wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the complete drum.
If the fault is still present, contact the Techline.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF092

38C-37
MR-413-X44-38C000$517_eng.mif
V1
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF093
PRESENT
OR
STOREDREAR LEFT-HAND WHEEL TARGET.
NOTESPriorities when dealing with a number of faults:
Deal with fault DF007 Rear left-hand wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the complete drum.
If the fault is still present, contact the Techline.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF093

38C-45
MR-413-X44-38C000$517_eng.mif
V1
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF229
PRESENT
OR
STOREDFRONT RIGHT-HAND WHEEL
1.DEF: Vehicle speed sensor signal consistent
NOTESPriorities when dealing with a number of faults:
Deal with fault DF026 Front right wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the target.
Check the connection and condition (possible damage to the wiring) of the connector of component 1094.
Check the connection and condition (possible damage to the wiring) of the connector of component 152.
If the connector is faulty (see Technical Note 6015A, Repairing electrical wiring, wiring: Precautions for
repair), repair the connector, otherwise replace the wiring.
Check for a voltage of approximately 12 V between the two connections of component 152 near
component 1094.
If a 12 V feed is not present, contact the Techline.
If all the checks are in order, swap the 2 front wheel speed sensors. Clear the computer fault memory.
Switch off the ignition. Switch the ignition back on and carry out a road test.
If a fault, which was initially registered as DF229 front right-hand wheel speed has become present DF230
front left-hand wheel speed, replace the wheel speed sensor (see MR411 Mechanical systems, 38C, Wheel
speed sensor: Removal - Refitting).
If the fault stays on the same side, the target is faulty, replace the active sensor bearing.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF229

38C-46
MR-413-X44-38C000$517_eng.mif
V1
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF230
PRESENT
OR
STOREDFRONT LEFT-HAND WHEEL SPEED
1.DEF: Vehicle speed sensor signal consistent
NOTESPriorities when dealing with a number of faults:
Deal with fault DF006 Front left wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the target.
Check the connection and condition (possible damage to the wiring) of the connector of component 1094.
Check the connection and condition (possible damage to the wiring) of the connector of component 153.
If the connector is faulty (see Technical Note 6015A, Repairing electrical wiring, wiring: Precautions for
repair), repair the connector, otherwise replace the wiring.
Check for a voltage of approximately 12 V between the two connections of the connector of component 153 near
component 1094.
If a 12 V feed is not present, contact the Techline.
If all the checks are in order, swap the 2 front wheel speed sensors. Clear the computer fault memory.
Switch off the ignition. Switch the ignition back on and carry out a road test.
If a fault, which was initially registered as DF230 front left-hand wheel speed has become present DF229 front
right-hand wheel speed, replace the wheel speed sensor (see MR411 Mechanical systems, 38C, Wheel
speed sensor: Removal - Refitting).
If the fault stays on the same side, the target is faulty, replace the active sensor bearing.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF230

38C-47
MR-413-X44-38C000$517_eng.mif
V1
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF231
PRESENT
OR
STOREDREAR RIGHT-HAND WHEEL
1.DEF: Vehicle speed sensor signal consistent
NOTESPriorities when dealing with a number of faults:
Deal with fault DF027 right rear wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the target.
Check the connection and condition (possible damage to the wiring) of the connector of component 1094.
Check the connection and condition (possible damage to the wiring) of the connector of component 150.
If the connector is faulty (see Technical Note 6015A, Repairing electrical wiring, wiring: Precautions for
repair), repair the connector, otherwise replace the wiring.
Check for a voltage of approximately 12 V between the two connections of component 150 near
component 1094.
If a 12 V feed is not present, contact the Techline.
If all the checks are in order, swap the 2 rear brake drums. Clear the computer fault memory.
Switch off the ignition. Switch the ignition back on and carry out a road test.
If the fault initially declared as DF231 "rear right-hand wheel speed" has become DF232 "rear left-hand wheel
speed" present, replace the complete drum (see MR411 Mechanical systems, 33A, Rear axle component).
If the fault remains on the same side, replace the speed sensor (see MR411 Mechanical systems, 38C Wheel
speed sensor, Removal - Refitting).
Important, do not forget to refit the drums to the correct wheels.
If the fault is still present, contact the Techline.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF231

38C-48
MR-413-X44-38C000$517_eng.mif
V1
ANTI-LOCK BRAKING SYSTEM
Fault finding - Interpretation of faults
MK70 ABS
Vdiag No: 04
38C
DF232
PRESENT
OR
STOREDREAR LEFT-HAND WHEEL
1.DEF: Vehicle speed sensor signal consistent
NOTESPriorities when dealing with a number of faults:
Deal with fault DF007 Rear left-hand wheel speed sensor circuit first if it is present.
Conditions for applying the fault finding procedure to stored faults:
The fault is declared present during a road test (in excess of 12 mph (20 km/h)
for 2 minutes).
Check the condition of the axle assemblies (impacts, damage, etc.) and the conformity and good condition of the
tyres.
Check that the braking system (condition of brake pads, sealing, sticking, bleed, bearing clearance, etc.) is in
good condition.
Visually inspect the condition of the target (for clogging, metallic contamination, bearing grease, etc.) and clean
using compressed air if necessary.
If there is a lot of grease on the target, contact the Techline.
Check that the wheel speed sensor mounting is in good condition.
Check the conformity of the target (condition, number of teeth = 48) using the special command SC001 Check
target teeth.
If there is non-conformity, replace the target.
Check the connection and condition (possible damage to the wiring) of the connector of component 1094.
Check the connection and condition (possible damage to the wiring) of the connector of component 151.
If the connector is faulty (see Technical Note 6015A, Repairing electrical wiring, wiring: Precautions for
repair), repair the connector, otherwise replace the wiring.
Check for a voltage of approximately 12 V between the two connections of the connector of component 151 near
component 1094.
If a 12 V feed is not present, contact the Techline.
If all the checks are in order, swap the 2 rear wheel brake drums. Clear the computer fault memory.
Switch off the ignition. Switch the ignition back on and carry out a road test.
If the fault initially declared as DF232 "rear left-hand wheel speed" has become present DF231 "rear right-
hand wheel speed", replace the complete drum. (see MR411 Mechanical systems, 33A Rear axle
components).
If the fault remains on the same side, replace the speed sensor (see MR411 Mechanical systems, 38C Wheel
speed sensor, Removal - Refitting).
Important, do not forget to refit the drums to the correct wheels.
If the fault is still present, contact the Techline.
AFTER REPAIRClear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
ABS_V04_DF232
