2009 PONTIAC VIBE display

Playing a CD
The CD player can play the smaller
3 inch (8 cm) single CDs with an
adapter ring.
1. Insert a CD label side up
partway into the slot.
2. The CD player pulls the CD in
and begins playing.
3. The CD symbol and track
number displays.
4. The CD stays in the player if the
ignition or radio is turned off.
5. If the CD was the last source
selected, it resumes playing
when the radio is turned on.
Y(EJECT):Press and release to
eject a CD. Once ejected it can be
removed. If the CD is not removed
after several seconds the CD player
automatically pulls the disc back into
the player and starts playing.TUNE ADJ:Turn the TUNE ADJ
knob to select tracks on the CD.
ySEEK TRACKz:Pressyto
go to the start of the current
track, if more than ten seconds
have played. Press
zto go to the
next track. Holding or pressing
yorzmultiple times causes the
player to continue moving backward
or forward through the tracks on
the CD.
(FWD REV)(Fast Forward/
Fast Reverse):Press and hold
(
to advance playback quickly within a
track. Release to resume playing the
track. Press and hold
)to reverse
playback quickly within a track.
Release to resume playing the track.
BAND:Press to listen to the radio
when a CD is playing.CD/AUX (CD/Auxiliary):Press to
play a CD when listening to the radio.
Press the CD/AUX button again and
the system begins playing audio from
the connected portable audio player.
If a portable audio player is not
connected, “No Input Device Found”
displays.
See “Using the Auxiliary Input Jack”
later in this section.
INFO (Information):Press to
switch the display between the
track number, elapsed time of the
track, and the time. When the
ignition is off, press this button to
display the time.
EQ (Equalization):Press to select
an equalization setting while playing
a CD. See “EQ” listed previously for
more information. If an EQ setting is
selected for a CD, it is activated each
time a CD is played.
Infotainment 6-7
2009 - Pontiac Vibe Owner Manual

Care of CDs
The sound quality of the CD player
can be reduced because of:
The CD-R quality.
The method of recording
the CD-R.
The quality of the music that has
been recorded on the CD-R.
The way the CD-R has been
handled.
Store CD-R(s) in their original cases
or other protective cases and
away from dust and direct sunlight.
The CD player scans the bottom
surface of the disc. If the surface
of a CD is damaged, such as
cracked, broken, or scratched, the
CD may not play properly or at
all. Do not touch the bottom side of
a CD while handling it; this could
damage the surface. Pick up CDs
by grasping the outer edges or
the edge of the hole and the
outer edge.To clean a CD, use a soft lint free
cloth, or dampen a clean soft cloth
in a mild neutral detergent solution
mixed with water. Wipe the CD from
the center to the edge.
Care of The CD Player
Use a marking pen to identify CDs,
do not add labels.
Do not use CD lens cleaners; they
could damage the CD player.
Notice:If a label is added to a CD,
or more than one CD is inserted
into the slot at a time, or an
attempt is made to play scratched
or damaged CDs, the CD player
could be damaged. While using
the CD player, use only CDs in
good condition without any label,
load one CD at a time, and keep
the CD player and the loading slot
free of foreign materials, liquids,
and debris.
If an error displays, see “CD
Messages” later in this section.
Playing an MP3 CD-R Disc
Radios with the MP3 feature are
capable of playing an MP3 CD-R
disc. For more information on how to
play an MP3 CD-R disc, see Using
an MP3 later in this section.
CD Messages
If the CD ejects, it could be for
one of the following reasons:
The CD player is very hot.
When the temperature returns to
normal, the CD should play.
The road is very rough. When
the road becomes smoother,
the CD should play.
The CD is dirty, scratched, wet,
or upside down.
The air is very humid. If so, wait
about an hour and try again.
The format of the CD might not
be compatible. See Using an
MP3 later in this section.
6-8 Infotainment
2009 - Pontiac Vibe Owner Manual

A problem may have occurred
while burning the CD.
The label could be caught in the
CD player.
If any error occurs repeatedly or if
an error cannot be corrected,
contact your dealer/retailer. If the
radio displays an error message,
write it down and provide it to your
dealer/retailer when reporting
the problem.
Using the Auxiliary Input Jack
The radio has an auxiliary input
jack located on the lower right side
of the faceplate. This is not an
audio output; do not plug the
headphone set into the front
auxiliary input jack. An external
audio device such as an iPod,
laptop computer, MP3 player, CD
changer, etc. can be connected
to the auxiliary input jack for use
as another audio source.To use a portable audio player,
connect a 3.5 mm (1/8 inch) cable
to the radio’s front auxiliary input
jack. When a device is connected,
press the radio CD/AUX button
to begin playing audio from
the device over the vehicle
speakers.
PWR VOL (Power/Volume):Turn
to adjust the volume. Additional
volume adjustments may have to be
made from the portable device if
the volume is too quiet or not loud.
BAND:Press to listen to the
radio when a portable audio device
is playing.
CD/AUX (CD/Auxiliary):Press to
play a CD when a portable audio
device is playing. Press again
and the system begins playing
audio from the connected portable
audio player.
Using an MP3
MP3 CD-R Disc
MP3 Format
The MP3 player will only play
CD-R discs. It can read and play a
maximum of:
50 folders
11 folders in depth
50 playlists
10 sessions
255 les
All folders, playlists, sessions and
les over the maximum are ignored.
Record an MP3 disc:
Onto a CD-R disc.
Record playlists with an .m3u or
.wpl extension.
Do not mix standard audio and
MP3 les on the same disc.
Record the entire disc at once.
Finalize the disc when recording
an MP3 disc with multiple
sessions.
Infotainment 6-9
2009 - Pontiac Vibe Owner Manual

Root Directory
The root directory is treated as a
folder. All .mp3 les in the root
directory are accessed before
folders in the root directory.
Empty Directory or Folder
Empty folders and directories do
not display. The system ignores
empty directories and folders and
advances to the next directory
or folder that has .mp3 les in it.
No Folder
On a CD that contains only .mp3
les in the root directory the
next and previous folder functions
do not work.
On a CD that contains playlists
and .mp3 les the next and previous
folder functions search playlists
rst and then search .mp3 les in
the root folder.Order of Play
CDs that have playlists play the
tracks in the following order:
1. After the rst track in the rst
playlist ends, play continues
sequentially through all tracks
in each playlist
2. After the last track of the last
playlist ends, play restarts
from the rst track of the rst
playlist.
CDs that do not have playlists play
the tracks in the following order:
1. The rst le in the root directory
plays.
2. After all les from the root
directory have played, les in the
folders play.
3. After playing the last le from the
last folder, play restarts with the
rst le in the root directory.File System and Naming
The radio display shows, track
names that are shorter than
39 characters. Names that are
longer are shortened. The track
name appears as:
The song name that is in the
ID3 tag.
The le name without the le
extension if the song name is
not in the ID3 tag.
Preprogrammed Playlists
Playlists are accessed before les
or folders in the root directory.
Preprogrammed playlists created
by WinAmp™, MusicMatch™,
or Real Jukebox™ software can
be accessed and are treated
as special folders containing
compressed audio song les.
6-10 Infotainment
2009 - Pontiac Vibe Owner Manual

Music Navigator
The music navigator feature lets
MP3 CDs play in order by artist or
album.
The MP3 player scans the disc
to sort the les by artist and
album ID3 tag information.
It can take several minutes to
scan the disc depending
on the number of MP3 les
recorded to the CD-R.
The radio starts playing while
the disc is being scanned.
After the scan is nished,
the disc starts playing.
Playing an MP3
The MP3 player can play the
smaller 3 inch (8 cm) single CDs
with an adapter ring.
1. Insert a CD label side up
partway into the slot.
2. The CD player pulls the CD in
and begins playing.3. The CD stays in the player if the
ignition or radio is turned off.
4. If the CD was the last source
selected, it resumes playing
when the radio is turned on.
Y(EJECT):Press and release
to eject a CD. Once the disc is
ejected it can be removed.
If the CD is not removed after
several seconds the CD player
automatically pulls the disc back
into the player and starts playing.
ySEEK TRACKz:Press to go to
the start of the current track, if
more than ten seconds have played.
Press
zto go to the next track.
Holding or pressing
yorzmultiple
times will cause the player to
continue moving backward or
forward through the tracks on
the CD.
(FWD REV)(Fast Forward/
Fast Reverse):Press and hold
)
to advance playback quickly within
a track. Release
(to resume
playing the track. Press and hold
)
to reverse playback quickly within a
track. Release
(to resume
playing the track.
BAND:Press to listen to the radio
when a CD is playing.
INFO (Information):Press when
an MP3 CD is loaded, then press
the button below the Song, Artist,
Album, or Folder label to view
the information.
CD/AUX (CD/Auxiliary):Press to
play a CD when listening to the
radio.
Press the CD/AUX button again and
the system begins playing audio
from the connected portable audio
player. If a portable audio player
is not connected, “No Input Device
Found” displays.
Infotainment 6-11
2009 - Pontiac Vibe Owner Manual

Radio Reception
Frequency interference and static
can occur during normal radio
reception if items such as cell phone
chargers, vehicle convenience
accessories, and external electronic
devices are plugged into the
accessory power outlet. If there is
interference or static, unplug the item
from the accessory power outlet.
AM
The range for most AM stations is
greater than for FM, especially at
night. The longer range can cause
station frequencies to interfere
with each other. For better radio
reception, most AM radio stations
boost the power levels during the
day, and then reduce these levels
during the night. Static can also
occur when things like storms and
power lines interfere with radio
reception. When this happens, try
reducing the treble on the radio.
FM Stereo
FM stereo gives the best sound,
but FM signals only reach about
10 to 40 miles (16 to 65 km).
Tall buildings or hills can interfere
with FM signals, causing the
sound to fade in and out.
XM™ Satellite Radio Service
XM Satellite Radio Service gives
digital radio reception from
coast-to-coast in the 48 contiguous
United States, and in Canada. Just
as with FM, tall buildings or hills can
interfere with satellite radio signals,
causing the sound to fade in and out.
In addition, traveling or standing
under heavy foliage, bridges,
garages, or through tunnels could
cause loss of the XM signal for a
period of time. The radio may
display NO XM SIGNAL to indicate
interference.
Fixed Mast Antenna
The xed mast antenna can
withstand most car washes without
being damaged. If the mast should
ever become slightly bent, straighten
it out by hand. If the mast is badly
bent, replace it.
Check occasionally to make sure
the mast is still tightened to the
antenna base located on the roof
of the vehicle. If tightening is
required, tighten by hand.
XM™ Satellite Radio
Antenna System
The XM Satellite Radio antenna is
located on the roof of the vehicle.
Keep this antenna clear of snow and
ice build up for clear radio reception.
If the vehicle has a sunroof, the
performance of the XM system may
be affected if the sunroof is open.
Loading items onto the roof of
the vehicle can interfere with the
performance of the XM system.
Make sure the XM Satellite Radio
antenna is not obstructed.
6-14 Infotainment
2009 - Pontiac Vibe Owner Manual

LOCK/OFF:This is the only position
from which you can remove the key.
This locks the steering wheel,
ignition and automatic transmission.
Push in the ignition switch as you
turn the key toward you.
On vehicles with an automatic
transmission, the shift lever must be
in P (Park) to turn the ignition switch
to the LOCK/OFF position.
A warning tone will sound if the driver
door is opened with the key in the
ignition.
The ignition switch can bind in the
LOCK/OFF position with your wheels
turned off center. If this happens,
move the steering wheel from right
to left while turning the key to
ACC/ACCESSORY. If this doesn’t
work, then the vehicle needs service.{CAUTION
On manual transmission vehicles,
turning the key to LOCK/OFF and
removing it will lock the steering
column and result in a loss of
ability to steer the vehicle.
This could cause a collision.
If you need to turn the engine
off while the vehicle is moving,
turn the key only to ACC/
ACCESSORY. Do not push the
key in while the vehicle is moving.
ACC/ACCESSORY:This position
provides power to some of the
electrical accessories. It unlocks the
steering wheel and ignition. To move
the key from ACC/ACCESSORY to
LOCK/OFF, push in the key and then
turn it to LOCK/OFF.
A warning tone will sound when
the driver door is opened when the
ignition is still in ACC/ACCESSORY
or LOCK/OFF and the key is in the
ignition.ON/RUN:The ignition switch stays
in this position when the engine is
running. This position can be used to
operate the electrical accessories,
including the ventilation fan and
115 volt power outlet, as well as to
display some warning and indicator
lights. The transmission is also
unlocked in this position on
automatic transmission vehicles.
The battery could be drained
if you leave the key in the ACC/
ACCESSORY or ON/RUN position
with the engine off. You may not be
able to start the vehicle if the battery
is allowed to drain for an extended
period of time.
START:This position starts the
engine. When the engine starts,
release the key. The ignition switch
will return to ON/RUN for normal
driving.
Driving and Operating 8-3
2009 - Pontiac Vibe Owner Manual

Driver Shift Control (DSC)
DSC mode allows you to choose
the top gear limit of the vehicle’s
transmission and the vehicle’s speed
while driving down hill or towing a
trailer. To use this feature, do the
following:
1. Move the shift lever from
D (Drive) left to S (Shift Control).
While driving in this mode,
the transmission will remain
in the driver selected range.
When coming to a stop, the
vehicle will automatically shift
into 1 (First) gear.
2. Move the shift lever forward to
increase the gear range, or
rearward to decrease the gear
range available based upon your
current driving conditions and
needs.The number displayed in the
instrument cluster is the highest gear
that the transmission will be allowed
to operate in. However, your vehicle
can automatically shift to lower gears
as required by various driving
conditions. This means that all gears
below that number are available.
The display in the instrument
cluster will change from the currently
displayed message to 4 (Fourth)
when you enter S (Shift Control),
and change to indicate the requested
gear range when moving the shift
lever forward or rearward.
While using the DSC feature the
transmission will have rmer shifting
and sportier performance. You can
use this for sport driving or when
climbing hills to stay in gear longer
or to downshift for more power or
engine braking.The transmission will only allow
shifting into gears appropriate
for the vehicles speed and engine
revolutions per minute (RPM):
The transmission will not
automatically shift to the next
higher gear if the vehicle speed
or engine RPM is too high.
The transmission will not allow
shifting to the next lower gear if
the vehicle speed or engine RPM
is too high. An audible warning
will sound and the downshift will
not be allowed. The downshift
request will have to be made
again once the vehicle reaches
an acceptable speed.
Downshift
RequestedRequired
Vehicle Speed
4 (Fourth) to
3 (Third)Below 95 mph
(153 km/h)
3 (Third) to
2 (Second)Below 60 mph
(97 km/h)
2 (Second) to
1 (First)Below 30 mph
(48 km/h)
8-10 Driving and Operating
2009 - Pontiac Vibe Owner Manual
