2009 NISSAN VERSA HATCHBACK service indicator

CHECKING BULBS
With all doors closed, apply the parking brake
and place the ignition switch in the ON position
without starting the engine. The following lights
will come on:
or,,,,,
If equipped, the following lights come on briefly
and then go off:
or,(red) ,(blue) ,,
,,,,
If any light fails to come on, it may indicate
a burned-out bulb or an open circuit in the
electrical system. Have the system repaired
promptly.
WARNING LIGHTS
orAnti-lock Braking
System (ABS)
warning light (if so
equipped)
When the ignition switch is placed in the ON
position, the Anti-lock Braking System (ABS)warning light illuminates and then turns off. This
indicates the ABS is operational.
If the ABS warning light illuminates while the
engine is running, or while driving, it may indicate
the ABS is not functioning properly. Have the
system checked by a NISSAN dealer.
If an ABS malfunction occurs, the anti-lock func-
tion is turned off. The brake system then operates
normally, but without anti-lock assistance. See
Brake systemin theStarting and drivingsec-
tion.
orBrake warning light
This light functions for both the parking brake and
the foot brake systems.
Parking brake indicator
When the ignition switch is placed in the ON
position, the light comes on when the parking
brake is applied.
Low brake fluid warning light
When the ignition switch is placed in the ON
position, the light warns of a low brake fluid level.
If the light comes on while the engine is running
with the parking brake not applied, stop the ve-
hicle and perform the following:1. Check the brake fluid level. Add brake fluid
as necessary. See “Brake fluid” in the “Main-
tenance and do-it-yourself” section of this
manual.
2. If the brake fluid level is correct, have the
warning system checked by a NISSAN
dealer.
WARNING
●Your brake system may not be working
properly if the warning light is on. Driv-
ing could be dangerous. If you judge it
to be safe, drive carefully to the nearest
service station for repairs. Otherwise,
have your vehicle towed because driv-
ing it could be dangerous.
●Pressing the brake pedal with the en-
gine stopped and/or a low brake fluid
level may increase your stopping dis-
tance and braking will require greater
pedal effort as well as pedal travel.
●If the brake fluid level is below the
MINIMUM or MIN mark on the brake
fluid reservoir, do not drive until the
brake system has been checked at a
NISSAN dealer.
Instruments and controls2-7
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


●Title mode displays the song title, show
name, or temperature of the selected satel-
lite radio station.
SCRL (Scroll) button:
Press the SCRL button to scroll through
CD/MP3 text that is too long to be displayed on
the first line of the display.
FM/AM/SAT radio operation
FM/AM/SAT band select:
Pressing the RADIO button will change the band
as follows:
AM←→FM←→SAT (satellite, if so equipped)
When the RADIO button is pressed while the
ignition switch is in the ACC or ON position, the
radio will come on at the station last played.
No satellite radio reception is available when the
RADIO button is pressed to access satellite radio
stations unless optional satellite receiver and an-
tenna are installed and an XMsatellite radio
service subscription is active. Satellite radio can
only be installed in vehicles that were factory
pre-wired for satellite radio. Satellite radio is not
available in Alaska, Hawaii and Guam. If satellite
radio is not operational then the RADIO button is
used to toggle between AM and FM bands.If a compact disc is playing when the RADIO
button is pressed, the compact disc will auto-
matically be turned off and the last radio station
played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically change
from stereo to monaural reception.
TUNE/FF·REW/FOLDER
(Tuning):
To manually tune the radio, press the
TUNE/FF·REW/FOLDER button
or.
To move quickly through the channels, hold either
the
orbutton down for more than
1.5 seconds.
SEEK/TRACK/FILE
tuning:
Press the SEEK/TRACK/FILE button
orfor less than 1.5 seconds to tune from
high to low or low to high frequencies and stop at
the next broadcasting station.
To seek quickly through the channels, press and
hold the SEEK/TRACK/FILE button for more than1.5 seconds. When the button is released, the
radio will seek to the next broadcasting station.
SCAN tuning:
Press the SCAN button for more than 1.5 sec-
onds to stop at each broadcasting station for 5
seconds. Pressing the button again during this 5
second period will stop SCAN tuning and the
radio will remain tuned to that station. If the
SCAN button is not pressed within 5 seconds,
SCAN tuning moves to the next station.
PRESET A·B·C (Station memory opera-
tions):
18 stations can be set for the FM, AM and SAT
(satellite, if so equipped) radio to the A, B and C
preset button in any combination of FM, AM or
SAT stations.
1. Choose preset bank A, B or C using the
PRESET A·B·C select button.
2. Select the desired FM, AM or SAT station
band.
3. Tune to the desired station using manual,
SEEK or SCAN tuning. Press and hold any
of the desired station memory buttons (1 –
6) until a beep sound is heard.
4. The channel indicator will then come on and
the sound will resume. Programming is now
complete.
Heater, air conditioner, audio and phone systems4-23
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Wheel nut tightening torque:
83 ft-lb (113 N·m)
The wheel nuts must be kept tight-
ened to specifications at all times. It
is recommended that wheel nuts be
tightened to specification at each
tire rotation interval.
WARNING
●After rotating the tires, check and
adjust the tire pressure.
●Retighten the wheel nuts when
the vehicle has been driven for
600 miles (1,000 km) (also in
cases of a flat tire, etc.) .
●Do not include the spare tire in
the tire rotation.
●For additional information re-
garding tires, refer to “Important
Tire Safety Information” (US) or
“Tire Safety Information”
(Canada) in the Warranty Infor-
mation Booklet.
1. Wear indicator
2. Location mark
Tire wear and damage
WARNING
●Tires should be periodically in-
spected for wear, cracking, bulg-
ing or objects caught in the tread.
If excessive wear, cracks, bulging
or deep cuts are found, the tire(s)
should be replaced.●The original tires have built-in
tread wear indicators. When the
wear indicators are visible, the
tire(s) should be replaced.
●Tires degrade with age and use.
Have tires, including the spare,
over 6 years old checked by a
qualified technician because
some tire damage may not be ob-
vious. Replace the tires as neces-
sary to prevent tire failure and
possible personal injury.
●Improper service of the spare tire
may result in serious personal in-
jury. If it is necessary to repair the
spare tire, contact a NISSAN
dealer.
●For additional information re-
garding tires, refer to “Important
Tire Safety Information” (US) or
“Tire Safety Information”
(Canada) in the Warranty Infor-
mation Booklet.
WDI0259
8-42Maintenance and do-it-yourself
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


10 Index
A
Active Head Restraint..............1-6
Air bag (See supplemental restraint
system) .....................1-36
Air bag system
Front (See supplemental front impact air bag
system) ...................1-43
Side and curtain (See supplemental
side air bag and curtain side-impact
air bag system)...............1-47
Airbagwarninglabels.............1-50
Airbagwarninglight...........1-50,2-11
Air cleaner housing filter............8-20
Air conditioner
Air conditioner operation...........4-5
Air conditioner service............4-9
Air conditioner specification label.....9-12
Air conditioner system refrigerant and
oil recommendations.............9-7
Heater and air conditioner controls.....4-3
Servicing air conditioner...........4-9
Airflowcharts ..................4-6
Alarm system
(See vehicle security system).........2-14
Anchorpointlocations.............1-20
Antenna.....................4-28
Anti-lock brake warning light..........2-7
Anti-lock Braking System (ABS)........5-29
Armrests .....................1-5
Audible reminders................2-13Audio system..................4-10
Compact Disc (CD) changer.......4-24
Compact disc (CD) player.........4-18
FM-AM radio with compact disc (CD)
player ....................4-16
FM/AM/SAT radio with compact disc (CD)
changer...................4-21
Radio ....................4-10
Steering wheel audio control switch....4-27
Automatic
Automatic power window switch.....2-30
Automatic transmission fluid (ATF)....8-13
Driving with automatic transmission....5-14
Transmission selector lever lock
release................5-16,5-20
Automatic door locks...............3-6
B
Battery......................8-16
Chargewarninglight.............2-8
Before starting the engine...........5-12
Belt (See drive belt)..............8-18
Block heater
Engine....................5-32
Bluetoothhands-free phone system.....4-29
Booster seats..................1-31
Brake
Anti-lock Braking System (ABS)......5-29
Brake fluid..................8-15
Brake light (See stop light).........8-30Brake system................5-28
Brake warning light..............2-7
Brake wear indicators........2-13,8-22
Parking brake operation..........5-23
Self-adjusting brakes............8-22
Brakes......................8-22
Break-in schedule................5-25
Brightness control
Instrument panel..............2-21
Bulb check/instrument panel..........2-7
Bulb replacement................8-30
C
Capacities and recommended
fuel/lubricants...................9-2
CarphoneorCBradio.............4-28
Cargocover...................2-27
Cargo (See vehicle loading information) . . .9-13
CD care and cleaning.............4-26
CD changer (See audio system)........4-24
CD player (See audio system).........4-18
Child restraint with top tether strap......1-19
Child restraints..........1-10,1-15,1-17
Precautions on child
restraints............1-15,1-25,1-31
Top tether strap anchor point locations . .1-20
Child safety rear door lock............3-6
Chimes,audiblereminders...........2-13
Cleaning exterior and interior..........7-2
Clock...................4-17,4-21
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Lights
Maplights..................2-34
Lock
Child safety rear door lock..........3-6
Door locks..................3-4
Fuel-filler door lock opener lever......3-26
Power door locks...............3-5
Lowfuelwarninglight..............2-9
Low tire pressure warning light.........2-9
Low washer fluid warning light.........2-10
Luggage (See vehicle loading information) . .9-13
M
Maintenance
General maintenance............8-2
Insidethevehicle...............8-3
Maintenance precautions..........8-5
Outside the vehicle..............8-2
Seatbeltmaintenance...........1-15
Under the hood and vehicle.........8-4
Malfunctionindicatorlight...........2-12
Manual front seat adjustment..........1-2
Manual windows................2-31
Maplights....................2-34
Map pocket...................2-23
Meters and gauges................2-3
Instrument brightness control.......2-21
Mirror
Inside mirror.................3-29
Outside mirror control...........3-29
Outside mirrors...............3-29
Vanity mirror.................3-29
Moonroof ....................2-32N
NISSAN Intelligent Key™........3-10,3-13
NISSAN vehicle immobilizer
system................2-15,3-2,5-12
O
Octane rating (See fuel octane rating).....9-5
Odometer.....................2-4
Oil
Capacities and recommended
fuel/lubricants.................9-2
Changingengineoil ............8-10
Changing engine oil filter..........8-12
Checking engine oil level..........8-9
Engine oil...................8-9
Engine oil and oil filter recommendation . .9-6
Engine oil viscosity..............9-6
Outside mirror control.............3-29
Outside mirrors.................3-29
Overdrive switch................5-17
Overheat
Ifyourvehicleoverheats...........6-9
Owner’s manual order form..........9-21
Owner’s manual/service manual order
information....................9-21
P
Parking
Parking brake operation..........5-23
Parking/parking on hills...........5-27Phone, Bluetoothhands-free system....4-29
Power
Power door locks...............3-5
Power outlet.................2-23
Power rear windows............2-30
Power steering system...........5-28
Power windows...............2-29
Rear power windows
............2-30
Precautions
Maintenanceprecautions ..........8-5
Precautions on child
restraints............1-15,1-25,1-31
Precautions on seat belt usage.......1-7
Precautions on supplemental restraint
system....................1-36
Precautions when starting and driving . . .5-2
Push starting...................6-9
R
Radio
CarphoneorCBradio...........4-28
Compact Disc (CD) changer.......4-24
FM-AM radio with compact disc (CD)
player....................4-16
FM/AM/SAT radio with compact disc (CD)
changer...................4-21
Steeringwheelaudiocontrolswitch....4-27
Readiness for inspection maintenance (I/M)
test........................9-19
Rear power windows..............2-30
Rear seat.....................1-4
Rear window and outside mirror defroster
switch......................2-19
Rear window wiper and washer switches . . .2-18
10-4
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Recorders
Eventdata..................9-20
Refrigerant recommendation..........9-7
Registering your vehicle in another country . .9-10
Reporting safety defects (US only)......9-19
S
Safety
Child safety rear door lock..........3-6
Childseatbelts........1-15,1-25,1-31
Reporting safety defects (US only)....9-19
Seat adjustment
Front manual seat adjustment........1-2
Rear seat adjustment.............1-4
Seat belt
Child safety.................1-10
Infantsandsmallchildren .........1-10
InjuredPerson................1-11
Largerchildren ...............1-10
Precautions on seat belt usage.......1-7
Pregnant women..............1-11
Seat belt extenders.............1-14
Seatbeltmaintenance...........1-15
Seatbelts...................1-7
Shoulder belt height adjustment......1-14
Three-point type with retractor.......1-11
Seatbeltwarninglight.............2-11
Seats
Adjustment..................1-2
Frontseats..................1-2
Manual front seat adjustment........1-2
Rearseat...................1-4
Security indicator light.............2-13Security system (NISSAN vehicle immobilizer
system) , engine start........2-15,3-2,5-12
Self-adjusting brakes..............8-22
Service manual order form...........9-21
Servicing air conditioner.............4-9
Shiftlockrelease.............5-16,5-20
Shifting
Automatic transmission...........5-15
Continuously Variable Transmission
(CVT)....................5-18
Manual transmission............5-22
Shoulder belt height adjustment........1-14
Side air bag system (See supplemental side
air bag and curtain side-impact air
bag system)...................1-47
Spark plug replacement............8-19
Speedometer...................2-3
SRSwarninglabel...............1-50
Starting
Before starting the engine.........5-12
Jump starting.................6-7
Precautions when starting and driving . . .5-2
Push starting.................6-9
Starting the engine.............5-13
Steering
Power steering system...........5-28
Tilting steering wheel............3-28
Steering wheel audio control switch......4-27
Stoplight ....................8-30
Storage.....................2-23
Storage tray...................2-24
Sunglasses case................2-25
Sunglasses holder...............2-25
Sunroof (see Moonroof)............2-32
Supplemental air bag warning labels.....1-50
Supplemental air bag warning light . . .1-50, 2-11Supplemental front impact air bag system . .1-43
Supplemental restraint system
Information and warning labels.......1-50
Precautions on supplemental restraint
system....................1-36
Supplemental restraint system
(Supplemental air bag system).........1-36
Supplemental side and curtain side-impact
air bag system..................1-47
Switch
Automatic power window switch
.....2-30
Fog light switch...............2-21
Hazard warning flasher switch.......2-22
Headlightandturnsignalswitch......2-19
Headlight control switch..........2-19
Ignition switch................5-7
Overdrive switch..............5-17
Power door lock switch...........3-5
Rear window and outside mirror defroster
switch....................2-19
Rear window wiper and washer
switches...................2-18
Turnsignalswitch..............2-21
Windshield wiper and washer switch . . .2-17
T
Tachometer....................2-4
Theft (NISSAN vehicle immobilizer system) ,
engine start.............2-15,3-2,5-12
Three-way catalyst................5-2
Tilting steering wheel..............3-28
Tire
Flat tire....................6-2
Spare tire................6-3, 8-44
10-5
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie
