5. Remove the drain plugBwith a wrench by
turning it counterclockwise and completely
drain the oil.
If the oil filter is to be changed, remove and
replace it at this time. See “Changing engine
oil filter” later in this section.
WARNING
●Prolonged and repeated contact with
used engine oil may cause skin cancer.
●Try to avoid direct skin contact with
used oil. If skin contact is made, wash
thoroughly with soap or hand cleaner
as soon as possible.
●Keep used engine oil out of reach of
children.
CAUTION
●Be careful not to burn yourself. The en-
gine oil may be hot.
●Waste oil must be disposed of properly.
●Check your local regulations.
6. Clean and reinstall the drain plug and a new
washer. Securely tighten the drain plug with
a wrench. Do not use excessive force.
Drain plug tightening torque:
22 - 29 ft-lb (29 - 39 N·m )7. Refill engine with recommended oil through
the oil filler opening, then install the oil filler
cap securely.
See “Capacities and recommended
fuel/lubricants” in the “Technical and con-
sumer information” section of this manual for
drain and refill capacity.
The drain and refill capacity depends on the
oil temperature and drain time. Use these
specifications for reference only. Always use
the dipstick to determine when the proper
amount of oil is in the engine.
8. Start the engine. Check for leakage around
the drain plug and oil filter. Correct as re-
quired.
9. Turn the engine off and wait more than 10
minutes. Check the oil level with the dipstick.
Add engine oil if necessary.
MR18DE engine
AOil filler cap
BOil drain plug
COil filter
WDI0691
Maintenance and do-it-yourself8-11
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—tbrooks


9 Technical and consumer information
Capacities and recommended fuel/lubricants.........9-2
Fuel recommendation . . .........................9-4
Engine oil and oil filter recommendations..........9-6
Air conditioner system refrigerant and oil
recommendations..............................9-7
Specifications . . ...................................9-8
Engine........................................9-8
Wheels and tires...............................9-9
Dimensions and weights........................9-9
When traveling or registering your vehicle in
another country..................................9-10
Vehicle identification..............................9-10
Vehicle identification number (VIN) plate.........9-10
Vehicle identification number
(chassis number)..............................9-10
Engine serial number...........................9-11
F.M.V.S.S./C.M.V.S.S. certification label..........9-11
Emission control information label...............9-11Tire and loading information label................9-12
Air conditioner specification label................9-12
Installing front license plate........................9-12
Vehicle loading information........................9-13
Terms........................................9-13
Determining vehicle load capacity...............9-14
Loading tips..................................9-16
Measurement of weights.......................9-16
Towing a trailer...................................9-17
Flat towing....................................9-17
Uniform tire quality grading........................9-17
Emission control system warranty..................9-18
Reporting safety defects (US only).................9-19
Readiness for inspection/maintenance (I/M) test.....9-19
Event Data Recorders (EDR).......................9-20
Owner’s Manual/Service Manual order information . . . 9-21
In the event of a collision.......................9-21
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure
described in the “Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
US measure Imp measure Liter Recommended Fluids and Lubricants
Fuel 13-1/4 gal 11 gal 50.0 See “Fuel recommendation” in this section.
Engine oil (drain and refill) *5
With oil filter
changeHR16DE 3-1/2 qt 2-7/8 qt 3.3
HR16DE and MR18DE:
Engine oil with API Certification Mark *1
Viscosity SAE 5W-30*1 MR18DE 4-7/8 qt 4 qt 4.6
Without oil filter
changeHR16DE 3-1/4 qt 2-3/4 qt 3.1
MR18DE 4-1/2 qt 3-3/4 qt 4.3
Cooling system (with reservoir)
HR16DE 1-5/8 gal 1-3/8 gal 6.3
50% Genuine NISSAN Long Life Antifreeze/Coolant or equivalent *2
50% Demineralized or distilled water
MR18DE 1-3/4 gal 1-1/2 gal 6.8
Manual transmission gear oil— — 5-speed MT: Genuine NISSAN Manual Transmission Fluid (MTF) HQ
Multi 75W-85 or API GL-4, Viscosity SAE 75W-85
6-speed MT: Genuine NISSAN gear oil (XT4447M+) 75W80, Genu-
ine NISSAN gear oil (ETL8997B) 75Ww80, or equivalent *3
Automatic transmission fluid Refill to the proper level according to the in-
structions in the “Maintenance and do-it-
yourself” section.*7Genuine NISSAN Matic D ATF or equivalent (if available)
Continuously Varible Transmission (CVT) fluid Genuine NISSAN CVT fluid NS-2-V *4
Brake and clutch fluidGenuine NISSAN Brake Fluid or equivalent DOT 3
Multi-purpose grease — — NLGI No. 2 (Lithium soap base)
CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2Technical and consumer information
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Capacity (Approximate)
US measure Imp measure Liter Recommended Fluids and Lubricants
Air conditioning system refrigerant — — HFC-134a (R-134a) *5
Air conditioning system oil
M/T and A/T — — NISSAN A/C System Oil Type R or equivalent *5
CVT — — NISSAN A/C System Oil Type S or equivalent *5
Windshield washer fluid — — Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-
freeze or equivalent
*1: For further details, see “Engine oil and oil filter recommendations.”
*2: Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine cooling system caused by the use of non-genuine
engine coolant.Note that any repairs for incidents within the engine cooling system while using non-genuine engine coolant may not be covered by the warranty
even if such incidents occurred during the warranty period.
*3: If Genuine NISSAN gear oil is not available, API GL-4, Viscosity SAE 75W-80 may be used as a temporary replacement. However, use Genuine NISSAN gearoil as soon as it is
available.
*4:Use only Genuine NISSAN CVT Fluid NS-2-V.Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2-V will damage the CVT transmission, whichis
not covered by the NISSAN new vehicle limited warranty.
*5: For further details, see “Air conditioner system refrigerant and oil recommendations.”
*6: For further details, see “Engine oil” in the “Maintenance and do-it-yourself” section of this manual.
*7: See your NISSAN dealer or qualified workshop for service.
Technical and consumer information9-3
