2009 NISSAN VERSA HATCHBACK check engine

4. Close the lid securely as illustratedCD.
5. Operate the buttons to check the operation.
See a NISSAN dealer if you need assistance for
replacement.
FCC Notice:
Changes or modifications not expressly ap-
proved by the party responsible for compli-
ance could void the user’s authority to op-
erate the equipment.
This device complies with Part 15 of the
FCC Rules and RSS-210 of Industry
Canada.Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received, in-
cluding interference that may cause undes-
ired operation of the device.
HEADLIGHTS
Replacing the halogen headlight bulb
The headlight is a semi-sealed beam type which
uses a replaceable headlight (halogen) bulb.
They can be replaced from inside the engine
compartment without removing the headlight as-
sembly.
See a NISSAN dealer for replacing the head-
lights.
CAUTION
●Aiming is not necessary after replacing
the bulb. When aiming adjustment is
necessary, contact a NISSAN dealer.
●Do not leave the headlight assembly
open without a bulb installed for a long
period of time. Dust, moisture, smoke,
etc. entering the headlight body may
affect bulb performance. Remove the
bulb from the headlight assembly just
before a replacement bulb is installed.
●Only touch the base when handling the
bulb. Never touch the glass envelope.
Touching the glass could significantly
affect bulb life and/or headlight
performance.WDI0535
LIGHTS
Maintenance and do-it-yourself8-29
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


E–85 fuel
E-85 fuel is a mixture of approximately 85% fuel
ethanol and 15% unleaded gasoline. E-85 can
only be used in a Flexible Fuel Vehicle (FFV) . Do
not use E-85 in your vehicle. U.S. government
regulations require fuel ethanol dispensing
pumps to be identified by a small, square, orange
and black label with the common abbreviation or
the appropriate percentage for that region.
Aftermarket fuel additives
NISSAN does not recommend the use of any
aftermarket fuel additives (for example, fuel injec-
tor cleaner, octane booster, intake valve deposit
removers, etc.) which are sold commercially.
Many of these additives intended for gum, varnish
or deposit removal may contain active solvents or
similar ingredients that can be harmful to the fuel
system and engine.
Octane rating tips
Using unleaded gasoline with an octane
rating lower than recommended can cause
persistent, heavy “spark knock.” (“Spark
knock” is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If you
detect a persistent heavy spark knock even
when using gasoline of the stated octane
rating, or if you hear steady spark knock
while holding a steady speed on levelroads, have a NISSAN dealer correct the
condition. Failure to correct the condition
is misuse of the vehicle, for which NISSAN
is not responsible.
Incorrect ignition timing may result in spark
knock, after-run and/or overheating, which may
cause excessive fuel consumption or engine
damage. If any of the above symptoms are en-
countered, have your vehicle checked at a
NISSAN dealer.
However, now and then you may notice
light spark knock for a short time while
accelerating or driving up hills. This is not a
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.
CAUTION
●Your vehicle is not designed to run on
E-85 fuel. Using E-85 fuel in a vehicle
not specifically designed for E-85 fuel
can damage fuel system components
and is not covered by the NISSAN new
vehicle limited warranty.
●E-85 is a mixture of approximately 85%
fuel ethanol and 15% unleaded
gasoline.●U.S. government regulations require
ethanol dispensing pumps to be identi-
fied by a small, square, orange and
black label with the common abbrevia-
tion or the appropriate percentage for
that region.
Technical and consumer information9-5
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


If you believe that your vehicle has a de-
fect which could cause a crash or could
cause injury or death, you should immedi-
ately inform the National Highway Traffic
Safety Administration (NHTSA) in addi-
tion to notifying NISSAN.
If NHTSA receives similar complaints, it
may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot be-
come involved in individual problems be-
tween you, your dealer, or NISSAN.
To contact NHTSA, you may call the Ve-
hicle Safety Hotline toll-free at 1-888-
327-4236 (TTY: 1-800-424-9153); go
to http://www.safercar.gov; or write to:
Administrator, NHTSA, 400 Seventh
Street, SW., Washington, D.C. 20590.
You can also obtain other information
about motor vehicle safety from
http://www.safercar.gov.
You may notify NISSAN by contacting our
Consumer Affairs Department, toll-free, at
1-800-NISSAN-1.Due to legal requirements in some states and
Canadian Provinces, your vehicle may be re-
quired to be in what is called the “ready condi-
tion” for an Inspection/Maintenance (I/M) test of
the emission control system.
The vehicle is set to the “ready condition” when it
is driven through certain driving patterns. Usually,
the ready condition can be obtained by ordinary
usage of the vehicle.
If a powertrain system component is repaired or
the battery is disconnected, the vehicle may be
reset to a “not ready” condition. Before taking the
I/M test, check the vehicle’s
inspection/maintenance test readiness condi-
tion. Turn the ignition switch ON without starting
the engine. If the Malfunction Indicator Light
(MIL) comes on steady for 20 seconds and then
blinks for 10 seconds , the I/M test condition is
“not ready”. If the MIL does not blink after 20
seconds, the I/M test condition is “ready”. If the
MIL indicates the vehicle is in a “not ready” con-
dition, drive the vehicle through the following
pattern to set the vehicle to the ready condition. If
you cannot or do not want to perform the driving
pattern, a NISSAN dealer can conduct it for you.WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic con-
ditions and obey all traffic laws.
1. Start the engine, the low temperature indi-
cator light
illuminates in blue. Allow
the engine to idle until the low temperature
indicator light
goes out, indicating
normal operating temperature.
2. Accelerate the vehicle to 55 MPH (88
km/h) , then quickly release the accelerator
pedal completely and keep it released for at
least 10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 - 60 MPH (86 - 96 km/h) for at least 9
minutes.
4. Stop the vehicle.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 through 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 min-
utes.
REPORTING SAFETY DEFECTS (US
only)READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST
Technical and consumer information9-19
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


10 Index
A
Active Head Restraint..............1-6
Air bag (See supplemental restraint
system) .....................1-36
Air bag system
Front (See supplemental front impact air bag
system) ...................1-43
Side and curtain (See supplemental
side air bag and curtain side-impact
air bag system)...............1-47
Airbagwarninglabels.............1-50
Airbagwarninglight...........1-50,2-11
Air cleaner housing filter............8-20
Air conditioner
Air conditioner operation...........4-5
Air conditioner service............4-9
Air conditioner specification label.....9-12
Air conditioner system refrigerant and
oil recommendations.............9-7
Heater and air conditioner controls.....4-3
Servicing air conditioner...........4-9
Airflowcharts ..................4-6
Alarm system
(See vehicle security system).........2-14
Anchorpointlocations.............1-20
Antenna.....................4-28
Anti-lock brake warning light..........2-7
Anti-lock Braking System (ABS)........5-29
Armrests .....................1-5
Audible reminders................2-13Audio system..................4-10
Compact Disc (CD) changer.......4-24
Compact disc (CD) player.........4-18
FM-AM radio with compact disc (CD)
player ....................4-16
FM/AM/SAT radio with compact disc (CD)
changer...................4-21
Radio ....................4-10
Steering wheel audio control switch....4-27
Automatic
Automatic power window switch.....2-30
Automatic transmission fluid (ATF)....8-13
Driving with automatic transmission....5-14
Transmission selector lever lock
release................5-16,5-20
Automatic door locks...............3-6
B
Battery......................8-16
Chargewarninglight.............2-8
Before starting the engine...........5-12
Belt (See drive belt)..............8-18
Block heater
Engine....................5-32
Bluetoothhands-free phone system.....4-29
Booster seats..................1-31
Brake
Anti-lock Braking System (ABS)......5-29
Brake fluid..................8-15
Brake light (See stop light).........8-30Brake system................5-28
Brake warning light..............2-7
Brake wear indicators........2-13,8-22
Parking brake operation..........5-23
Self-adjusting brakes............8-22
Brakes......................8-22
Break-in schedule................5-25
Brightness control
Instrument panel..............2-21
Bulb check/instrument panel..........2-7
Bulb replacement................8-30
C
Capacities and recommended
fuel/lubricants...................9-2
CarphoneorCBradio.............4-28
Cargocover...................2-27
Cargo (See vehicle loading information) . . .9-13
CD care and cleaning.............4-26
CD changer (See audio system)........4-24
CD player (See audio system).........4-18
Child restraint with top tether strap......1-19
Child restraints..........1-10,1-15,1-17
Precautions on child
restraints............1-15,1-25,1-31
Top tether strap anchor point locations . .1-20
Child safety rear door lock............3-6
Chimes,audiblereminders...........2-13
Cleaning exterior and interior..........7-2
Clock...................4-17,4-21
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Clutch
Clutchfluid .................8-15
C.M.V.S.S. certification label..........9-11
Cold weather driving..............5-30
Compact disc (CD) player...........4-18
Console box...................2-27
Continuously Variable Transmission (CVT) . .5-17
Continuously Variable Transmission (CVT)
fluid .....................8-14
Driving with Continuously Variable
Transmission (CVT).............5-17
Controls
Audio controls (steering wheel)......4-27
Heater and air conditioner controls.....4-3
Coolant
Capacities and recommended
fuel/lubricants.................9-2
Changing engine coolant..........8-9
Checking engine coolant level........8-8
Corrosionprotection...............7-5
Cruise control..................5-24
Cupholders...................2-25
Curtain side-impact air bag system
(See supplemental side air bag and curtain
side-impact air bag system)..........1-47
D
Daytime running light system
(Canada only)..................2-20
Defroster switch
Rear window and outside mirror defroster
switch....................2-19
Dimensionsandweights.............9-9
Dimmer switch for instrument panel......2-21Door locks....................3-4
Door open warning light.............2-8
Drive belt....................8-18
Driving
Cold weather driving............5-30
Driving with automatic transmission....5-14
Driving with Continuously Variable
Transmission (CVT).............5-17
Driving with manual transmission.....5-21
Precautions when starting and driving . . .5-2
E
Economy-fuel .................5-26
Emission control information label.......9-11
Emission control system warranty.......9-18
Engine
Before starting the engine.........5-12
Blockheater.................5-32
Capacities and recommended
fuel/lubricants.................9-2
Changingenginecoolant ..........8-9
Changingengineoil ............8-10
Changing engine oil filter..........8-12
Checking engine coolant level........8-8
Checking engine oil level..........8-9
Engine compartment check locations....8-6
Engine cooling system............8-8
Engine oil...................8-9
Engine oil and oil filter recommendation . .9-6
Engine oil pressure warning light......2-8
Engine oil viscosity..............9-6
Engine serial number............9-11
Engine specifications.............9-8
Starting the engine.............5-13Eventdatarecorders..............9-20
Exhaust gas (Carbon monoxide)........5-2
Eyeglass case..................2-25
F
Flashers
(See hazard warning flasher switch)......2-22
Flat tire......................6-2
Floor mat positioning aid.............7-5
Fluid
Automatic transmission fluid (ATF)....8-13
Brake fluid..................8-15
Capacities and recommended
fuel/lubricants.................9-2
Clutch fluid.................8-15
Continuously Variable Transmission (CVT)
fluid.....................8-14
Engine coolant................8-8
Engine oil...................8-9
Window washer fluid............8-16
F.M.V.S.S. certification label..........9-11
Foglightswitch.................2-21
Front air bag system
(See supplemental restraint system).....1-43
Front seats....................1-2
Fuel
Capacities and recommended
fuel/lubricants.................9-2
Fuel economy................5-26
Fuelgauge..................2-5
Fuel octane rating..............9-5
Fuel recommendation............9-4
Fuel-filler door and cap...........3-26
Fuel-filler door lock opener lever......3-26
10-2
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Fuses ......................8-23
Fusible links...................8-24
G
Gascap.....................3-26
Gauge
Fuelgauge..................2-5
Odometer...................2-4
Speedometer.................2-3
Tachometer..................2-4
Trip odometer.................2-4
Generalmaintenance ..............8-2
Glovebox....................2-26
H
Hands-free phone system, Bluetooth....4-29
Hazard warning flasher switch.........2-22
Head restraints..................1-6
Active Head Restraint............1-6
Headlight and turn signal switch........2-19
Headlightcontrolswitch............2-19
Headlights....................8-29
Heater
Heater and air conditioner controls.....4-3
Heater operation...............4-4
Hood release..................3-22
Horn.......................2-22
I
Ignition switch..................5-7Immobilizer system.........2-15,3-2,5-12
Important vehicle information label.......9-11
In-cabin microfilter...............8-20
Increasing fuel economy............5-26
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders).....................2-6
Inside mirror...................3-29
Instrument brightness control.........2-21
Instrument panel..............0-7,2-2
Instrument panel dimmer switch........2-21
Intelligent Key system
Key operating range............3-11
Mechanical key................3-3
Remote keyless entry operation......3-16
Troubleshooting guide...........3-21
Warningsignals...............3-21
Interiorlight...................2-34
Interior trunk lid release.............3-26
ISOFIX child restraints.............1-17
J
Jump starting...................6-7
K
Keyfob battery replacement..........8-26
Keyless entry
With Intelligent Key system
(See Intelligent Key system)........3-16
Keys, Except Intelligent Key...........3-2
Keys, For Intelligent Key system.........3-3L
Labels
Air conditioner specification label.....9-12
C.M.V.S.S. certification label........9-11
Emission control information label.....9-11
Engine serial number............9-11
F.M.V.S.S. certification label........9-11
Tire and Loading Information label.....9-12
Vehicle identification number (VIN)
plate.....................9-10
Warning labels (for SRS)..........1-50
LATCH (Lower Anchors and Tethers
for CHildren) System..............1-17
License plate
Installing the license plate.........9-12
Light
Airbagwarninglight.........1-50,2-11
Brake light (See stop light).........8-30
Bulb check/instrument panel........2-7
Bulbreplacement..............8-30
Charge warning light.............2-8
Fog light switch...............2-21
Headlightandturnsignalswitch......2-19
Headlight control switch..........2-19
Headlights..................8-29
Interior light.................2-34
Lightbulbs..................8-29
Low tire pressure warning light.......2-9
Low washer fluid warning light.......2-10
Passenger air bag and status light.....1-44
Security indicator light...........2-13
Trunklight..................2-35
Warning/indicator lights and audible
reminders...................2-6
10-3
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Lights
Maplights..................2-34
Lock
Child safety rear door lock..........3-6
Door locks..................3-4
Fuel-filler door lock opener lever......3-26
Power door locks...............3-5
Lowfuelwarninglight..............2-9
Low tire pressure warning light.........2-9
Low washer fluid warning light.........2-10
Luggage (See vehicle loading information) . .9-13
M
Maintenance
General maintenance............8-2
Insidethevehicle...............8-3
Maintenance precautions..........8-5
Outside the vehicle..............8-2
Seatbeltmaintenance...........1-15
Under the hood and vehicle.........8-4
Malfunctionindicatorlight...........2-12
Manual front seat adjustment..........1-2
Manual windows................2-31
Maplights....................2-34
Map pocket...................2-23
Meters and gauges................2-3
Instrument brightness control.......2-21
Mirror
Inside mirror.................3-29
Outside mirror control...........3-29
Outside mirrors...............3-29
Vanity mirror.................3-29
Moonroof ....................2-32N
NISSAN Intelligent Key™........3-10,3-13
NISSAN vehicle immobilizer
system................2-15,3-2,5-12
O
Octane rating (See fuel octane rating).....9-5
Odometer.....................2-4
Oil
Capacities and recommended
fuel/lubricants.................9-2
Changingengineoil ............8-10
Changing engine oil filter..........8-12
Checking engine oil level..........8-9
Engine oil...................8-9
Engine oil and oil filter recommendation . .9-6
Engine oil viscosity..............9-6
Outside mirror control.............3-29
Outside mirrors.................3-29
Overdrive switch................5-17
Overheat
Ifyourvehicleoverheats...........6-9
Owner’s manual order form..........9-21
Owner’s manual/service manual order
information....................9-21
P
Parking
Parking brake operation..........5-23
Parking/parking on hills...........5-27Phone, Bluetoothhands-free system....4-29
Power
Power door locks...............3-5
Power outlet.................2-23
Power rear windows............2-30
Power steering system...........5-28
Power windows...............2-29
Rear power windows
............2-30
Precautions
Maintenanceprecautions ..........8-5
Precautions on child
restraints............1-15,1-25,1-31
Precautions on seat belt usage.......1-7
Precautions on supplemental restraint
system....................1-36
Precautions when starting and driving . . .5-2
Push starting...................6-9
R
Radio
CarphoneorCBradio...........4-28
Compact Disc (CD) changer.......4-24
FM-AM radio with compact disc (CD)
player....................4-16
FM/AM/SAT radio with compact disc (CD)
changer...................4-21
Steeringwheelaudiocontrolswitch....4-27
Readiness for inspection maintenance (I/M)
test........................9-19
Rear power windows..............2-30
Rear seat.....................1-4
Rear window and outside mirror defroster
switch......................2-19
Rear window wiper and washer switches . . .2-18
10-4
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie
