Use a cloth1to protect the interior light hous-
ing.Use a clothAto protect the light housing.If you have a flat tire, see the “In case of
emergency” section of this manual.
TIRE PRESSURE
Tire Pressure Monitoring System
(TPMS)
This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS) . It
monitors tire pressure of all tires except
the spare. When the low tire pressure
warning light is lit, one or more of your
tires is significantly under-inflated.
The TPMS will activate only when the
vehicle is driven at speeds above 16 MPH
(25 km/h) . Also, this system may not de-
tect a sudden drop in tire pressure (for
example a flat tire while driving) .
For more details, refer to “Low tire pres-
sure warning light” in the “Instruments and
controls” section, “Tire Pressure Monitor-
ing System (TPMS)” in the “Starting and
driving” section, and “Flat tire” in the “In
case of emergency” section.
Interior light
WDI0206
Map light (if so equipped)
WDI0688
WHEELS AND TIRES
Maintenance and do-it-yourself8-31
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks
Replacing wheels and tires
When replacing a tire, use the same size, tread
design, speed rating and load carrying capacity
as originally equipped. Recommended types and
sizes are shown in “Wheels and tires” in the
“Technical and consumer information” section of
this manual.
WARNING
●The use of tires other than those recom-
mended or the mixed use of tires of
different brands, construction (bias,
bias-belted or radial) , or tread patterns
can adversely affect the ride, braking,
handling, VDC system, ground clear-
ance, body-to-tire clearance, tire chain
clearance, speedometer calibration,
headlight aim and bumper height.
Some of these effects may lead to acci-
dents and could result in serious per-
sonal injury.
●If your vehicle was originally equipped
with 4 tires that were the same size and
you are only replacing 2 of the 4 tires ,
install the new tires on the rear axle.
Placing new tires on the front axle may
cause loss of vehicle control in some
driving conditions and cause an acci-
dent and personal injury.●If the wheels are changed for any rea-
son, always replace with wheels which
have the same off-set dimension.
Wheels of a different off-set could
cause premature tire wear, degrade ve-
hicle handling characteristics, affect
the VDC system and/or interference
with the brake discs/drums. Such inter-
ference can lead to decreased braking
efficiency and/or early brake pad/shoe
wear. Refer to “Wheels and tires” in the
“Technical and consumer information”
section of this manual for wheel off-set
dimensions.
●When a spare tire is mounted or a wheel
is replaced, the TPMS will not function
and the low tire pressure warning light
will flash for approximately 1 minute.
The light will remain on after 1 minute.
Contact your NISSAN dealer as soon as
possible for tire replacement and/or
system resetting.
●Replacing tires with those not originally
specified by NISSAN could affect the
proper operation of the TPMS.●Do not install a damaged or deformed
wheel or tire even if it has been re-
paired. Such wheels or tires could have
structural damage and could fail with-
out warning.
●The use of retread tires is not
recommended.
●For additional information regarding
tires, refer to “Important Tire Safety In-
formation” (US) or “Tire Safety Informa-
tion” (Canada) in the Warranty Informa-
tion Booklet.
Wheel balance
Unbalanced wheels may affect vehicle handling
and tire life. Even with regular use, wheels can get
out of balance. Therefore, they should be bal-
anced as required.
Wheel balance service should be per-
formed with the wheels off the vehicle.
Spin balancing the wheels on the vehicle
could lead to mechanical damage.
●For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety Infor-
mation” (Canada) in the Warranty In-
formation Booklet.
8-40Maintenance and do-it-yourself
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks
Supplemental air bag warning labels.....1-55
Supplemental air bag warning light . . .1-55, 2-13
Supplemental front impact air bag system. . .1-47
Supplemental restraint system
Information and warning labels.......1-55
Precautions on supplemental restraint
system....................1-40
Supplemental restraint system
(Supplemental air bag system).........1-40
Supplemental side and curtain side-impact
air bag system..................1-52
Switch
Automatic power window switch.....2-33
Foglightswitch...............2-22
Hazard warning flasher switch.......2-22
Headlight and turn signal switch......2-20
Headlightcontrolswitch..........2-20
Ignition switch................5-7
Power door lock switch...........3-5
Rear window and outside mirror defroster
switch....................2-19
Turn signal switch..............2-22
Windshield wiper and washer switch . . .2-18
T
Tachometer....................2-4
Temperature gauge
Engine coolant temperature gauge.....2-6
Theft (NISSAN vehicle immobilizer system) ,
enginestart.............2-17,3-2,5-10
Three-way catalyst................5-2
Tilting steering wheel..............3-26
Tire
Flat tire....................6-2Spare tire................6-3,8-41
Tire and Loading Information label.....9-13
Tire chains..................8-38
Tireplacard.................9-13
Tire pressure................8-31
Tirerotation.................8-38
Types of tires................8-37
Uniform tire quality grading.........9-26
Wheels and tires..............8-31
Wheel/tire size................9-9
Tire pressure
Low tire pressure warning light......2-11
Tire Pressure Monitoring System (TPMS) . . .5-3
Top tether strap child restraint.........1-23
Towing
Flattowing..................9-25
Towtrucktowing..............6-11
Towing load/specification.........9-21
Trailer towing................9-18
Transmission
Continuously Variable Transmission (CVT)
fluid .....................8-13
Driving with Continuously Variable
Transmission (CVT).............5-12
Driving with manual transmission.....5-17
Selector lever lock release.........5-15
Travel (See registering your vehicle in another
country).....................9-11
Tripbutton ....................4-3
Trip odometer...................2-4
Triptime......................4-5
Trunk access through the rear seat....1-4,1-5
Trunk lid lock opener lever...........3-23
Trunklight....................2-39
Turn signal switch................2-22U
Uniform tire quality grading...........9-26
V
Vanity mirror...................3-26
Vehicle dimensions and weights........9-10
Vehicle identification..............9-11
Vehicle identification number (VIN)
(Chassis number)................9-11
Vehicle identification number (VIN) plate . . .9-11
Vehicle loading information...........9-14
Vehicle recovery.............6-12,6-13
Vehicle security system.............2-16
Vehicle security system
(NISSAN vehicle immobilizer system) ,
engine start.............2-17,3-2,5-10
Ventilators.....................4-7
W
Warning
Airbagwarninglight.........1-55,2-13
Anti-lock brake warning light........2-9
Battery charge warning light........2-10
Brake warning light..............2-9
Door open warning light..........2-10
Engine oil pressure warning light.....2-10
Hazard warning flasher switch.......2-22
Lowfuelwarninglight ...........2-10
Low tire pressure warning light......2-11
Low washer fluid warning light.......2-12
