Engine Compartment
The engine compartment of the Altima Hybrid houses an aluminum alloy 2.5 liter gasoline engine, the high
voltage harnesses, fuse/fusible link box, fuse block, inverter unit, transaxle and electric air conditioning
compressor.
Engine compartment components and locations
1. Fuse/Fusible link box
2.
Fuse block 3. Inverter unit
4. High voltage harness (orange) 5.
Transaxle 6. Electric air conditioning
compressor
7. Gasoline engine A.
HV electrical connector : Vehicle front
