2009 Mercury Mariner change time

Determine which maintenance schedule to follow
It’s important to follow the maintenance schedule that most closely mirrors your driving habits and the
conditions under which you drive. For this reason, the Scheduled Maintenance Guide is divided into two basic
maintenance schedules: the
Normal Schedule(further segmented intoTrucks, Fullsize Vans & SUVsandCars & CUVs) andSpecial Operating Conditions
Determining which maintenance schedule is right for you is easy. For the most part, do you drive your
Ford, Lincoln or Mercury vehicle under typical, everyday conditions? If so, follow theNormal Schedule Trucks,
Fullsize Vans & SUVs,orNormal Schedule Cars & CUVs.
Special Operating Conditions
However, if one or more of the Special Operating Conditions outlined below better describes how you
typically operate your vehicle, you will need to perform some maintenance services more often than the Normal
Schedule recommends.
•Towing a trailer or carrying heavy loads
•Extensive idling and/or driving at low-speeds for long distances
•Driving in dusty conditions
•Off-road operation
•Use of E85 fuel 50% of the time or greater (flex fuel vehicles only)
Important:For further details and information regarding these Special Operating Conditions see page 42.
Maximum Oil Change Interval
❑Normal Schedule: 7,500 miles or 6 months, whichever occurs first.❑Special Operating Conditions: 5,000 miles, 6 months, or 200 hours of engine operation, whichever occurs first
see appropriate schedule on page 42.
Motorcraft Premium Gold Engine Coolant
❑6 years or 105,000 miles - change Premium Gold coolant (whichever comes first)❑After initial change - change Premium Gold coolant every 3 years or 45,000 miles (see page 48)
GENERALMAINTENANCEINFORMATION
Scheduled Maintenance5
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
General Owner’s
Information

Exceptions
Some exceptions for specific vehicles and special applications are outlined below. In addition, you will find
further information under
Exceptionson page 47.
•Engine oil and Motorcraft Premium Gold Engine Coolant - time and mileage based
interval
If you’re unsure which maintenance schedule to follow, ask your Ford and Lincoln Mercury Dealership, or
visit the Maintenance area of www.genuineservice.com.
Oils, Fluids and Flushing
In many cases, fluid discoloration is a normal operating characteristic and, by itself, does not necessarily
indicate a concern or that the fluid needs to be changed. However, discolored fluids that also show signs of
overheating and/or foreign material contamination should be inspected immediately by a qualified
expert such as the factory-trained technicians at your Ford or Lincoln Mercury Dealership. Your vehicle’s oils
and fluids should be changed at the specified intervals or in conjunction with a repair. Flushing is a
viable way to change fluid for many vehicle sub-systems during scheduled maintenance. It is critical that
systems are flushed only with new fluid that is the same as that required to fill and operate the system, or
using a Ford-approved flushing chemical.
Chemicals and Additives
Non-Ford approved chemicals or additives are not required for factory recommended maintenance. In fact,
Ford Motor Company recommends against the use of such additive products unless specifically
recommended by Ford for a particular application.
Your vehicle is very sophisticated and built with multiple complex performance systems. Every manufacturer
develops these systems using different specifications and performance features. That’s why it’s
important to rely on your Ford or Lincoln Mercury dealership to properly diagnose and repair your vehicle.
When planning your maintenance services, consider your Ford or Lincoln Mercury dealership for all your
vehicle’s needs.
Get the most from your service and maintenance visits
There are a lot of reasons why visiting your Ford or Lincoln Mercury Dealership for all your service needs
is a great way to help keep your vehicle running great.
GENERALMAINTENANCEINFORMATION
6Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

Off-road operation
Every 5,000 miles or 6 monthsChange engine oil and replace oil filter
Rotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Every 30,000 milesChange automatic transmission/transaxle fluid (not
required on 6R60/6R75/TorqShift transmissions)
Replace wheel bearing grease and grease seals on
4x2 front wheel bearings (if non-sealed bearings)
Every 50,000 milesChange manual transmission fluid
Change rear axle lubricant (E–450 and F–450/550
only)
Every 60,000 milesChange transfer case fluid
As requiredReplace cabin air filter (if equipped)
Inspect and lubricate steering linkage ball joints and
U-joints (if equipped with zerk fittings)
Use of E85 50% of the time or greater (flex fuel vehicles only)
Every 5,000 milesRotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Every 3,000 milesFill fuel tank with a full tank of regular unleaded fuel
Every 5,000 miles or 6 monthsChange engine oil and replace oil filter
SPECIALOPERATINGCONDITIONS
Scheduled Maintenance45
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Special Operating
Conditions &
Exceptions

In addition, there are several exceptions to the Normal Schedule. They are listed below:
Normal Vehicle Axle Maintenance
❑Rear axles and power take off (PTO) units containing synthetic lubricant and light duty trucks equipped with
Ford-design axles are lubricated for life. These lubricants are not to be checked or changed unless a leak is suspected,
service is required or the axle assembly has been submerged in water. The axle and PTO lubricant should be
changed anytime the axle and PTO have been submerged in water. During extended trailer tow operation above 70°F
ambient and wide open throttle for extended periods above 45 mph, non-synthetic rear axle lubricants
should be replaced every 3,000 miles or 3 months, whichever occurs first. The 3,000 mile lube change interval
may be waived if the axle was filled with 75W140 synthetic gear lubricant meeting Ford specification
WSL-M2C192-A, part number F1TZ-19580-B or equivalent. Add friction modifier C8AZ-19B546-A (EST-M2C118-A)
or equivalent for complete refill of Traction-Lok rear axles (see
Owner’s Guidefor quantity). The axle
lubricant should be changed anytime an axle has been submerged in water.
Police/Taxi/Livery Vehicle Axle Maintenance
❑Replace rear axle lubricant every 100,000 miles. Rear axle lubricant change may be waived if the axle was
filled with 75W140 synthetic gear lubricant meeting Ford specification WSL-M2C192-A, part number FITZ-19580-B
or equivalent. Add four ounces of additive friction modifier C8AZ-19B546-A (EST-M2C118-A) or equivalent for
complete refill of Traction-Lok rear axles. The axle lubricant should be changed anytime the axle has been submerged
in water.
E–450 and F–450/550 Axle Maintenance
❑Replace rear axle lubricant every 100,000 miles under normal driving conditions on all E–450 and
F–450/550 applications. For E–450 and F–450/550 vehicles operated at or near maximum Gross Vehicle
Weights, the rear axle lubricant should be replaced every 50,000 miles. In addition, this 50,000 mile schedule
should be observed when the vehicles are operated under the Special Operating Conditions, where noted, on
page 42.
California Fuel Filter Replacement
❑If vehicle is registered in California, the California Air Resources Board has determined that the failure to
perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion
of the vehicle’s useful life. Ford Motor Company, however, urges you to have all recommended maintenance
services performed at the specified intervals and to record all vehicle service.
Class A Motorhome
❑Every two years - Change brake fluid❑Every 60,000 miles - Change automatic transmission fluid
EXCEPTIONS
Scheduled Maintenance47
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Special Operating
Conditions &
Exceptions
