2009 MAZDA MODEL CX-9 display

Black plate (9,1)
Interior Equipment (View B)
Audio control switches ...................................................................................... page 6-58
SRS air bags ...................................................................................................... page 2-50
Cruise control switches ...................................................................................... page 5-19
Information display .......................................................................................... page 6-141
Climate control system ........................................................................................ page 6-2
Hazard warning flasher switch .......................................................................... page 5-70
Audio system ..................................................................................................... page 6-17
Glove box ........................................................................................................ page 6-148
Accessory socket ............................................................................................. page 6-151
AT shift lever ...................................................................................................... page 5-10
Seat warmer switches ........................................................................................ page 2-17
Rear window defroster switch ........................................................................... page 5-69
Hood release handle .......................................................................................... page 3-46
Coin box .......................................................................................................... page 6-148
Navigation system (if equipped) .......................................... Refer to the separate manual
Your Vehicle at a Glance
Interior Overview
1-3The equipment and installation position varies by vehicle CX-9_8Z66-EA-08F_Edition3 Page9
Tuesday, March 31 2009 1:50 PM
Form No.8Z66-EA-08F

Black plate (205,1)
qSpeedometer
The speedometer indicates the speed of
the vehicle.
qOdometer, Trip Meter and Trip
Meter Selector
The display mode can be changed
between trip meter A and trip meter B by
pressing the selector while one of them is
displayed. The selected mode will be
displayed.
Selector
Trip meter
Odometer
Trip meter B
Press the selector Press the selector Trip meter AOdometer
Odometer
Odometer
The odometer records the total distance
the vehicle has been driven.
Trip meter
The trip meter can record the total
distance of two trips. One is recorded in
trip meter A, and the other is recorded in
trip meter B.
For instance, trip meter A can record the
distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.
When trip meter A is selected, pressing
the selector again within one second will
change to trip meter B mode.
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
Driving Your Mazda
Instrument Cluster and Indicators
5-39
CX-9_8Z66-EA-08F_Edition3 Page205
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F

Black plate (207,1)
qFuel Gauge
The fuel gauge shows approximately how
much fuel is remaining in the tank when
the ignition switch is in the ON position.
We recommend keeping the tank over 1/4
full. When the low fuel warning light
illuminates or when the needle is near E,
refuel as soon as possible.
Low fuel
warning lightFull
Approx. 1/4 Full
NOTElAfter refueling, it may require some time for
the needle to stabilize. In addition, the
needle may deviate while driving on a slope
or curve since the fuel moves in the tank.
lThe direction of the arrow () shows next
to the low fuel warning light indicates that
the fuel-filler lid is on the left side of the
vehicle.
qDashboard Illumination
Rotate the knob to adjust the brightness of
the instrument cluster and other
illuminations in the dashboard.
NOTE
lThe brightness of dashboard illuminations
can be adjusted when the headlight switch
is in the
orposition.lWhen the dashboard illumination
brightness cannot be adjusted any more, a
beep sound will be heard.
l(Black-out meter)
The brightness of the instrument cluster
illumination can be adjusted when the
headlight switch is in any position.
Dim
Bright
Canceling the illumination dimmer
(Black-out meter and dashboard
illuminations)
When the headlight switch is in the
orposition, the illumination of the
instrument cluster and the information
display dims.
When driving on snowy or foggy roads,
or in other situations when the instrument
cluster or information display's visibility
is reduced due to glare from surrounding
brightness, cancel the illumination
dimmer and increase the illumination
intensity.
Driving Your Mazda
Instrument Cluster and Indicators
5-41
CX-9_8Z66-EA-08F_Edition3 Page207
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F

Black plate (208,1)
To cancel the illumination dimmer, press
the dashboard illumination knob.
NOTE
lThis symbol () indicates the knob to
adjust the brightness of the dashboard
illumination.
lIf the illumination dimmer is cancelled, the
instrument cluster and the information
display will not dim when the headlight
switch is turned to the
orposition
again.
5-42
Driving Your Mazda
Instrument Cluster and Indicators
CX-9_8Z66-EA-08F_Edition3 Page208
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F

Black plate (222,1)
qHeadlight High-Beam Indicator
Light
This light indicates one of two things:lThe high-beam headlights are on.lThe turn signal lever is in the flash-to-
pass position.
qShift Position Indicator Light
This indicates the selected shift position
when the ignition switch is in the ON
position.
Gear position indicator
Gear position indicator
When the shift lever is in the D or M
position, the numeral for the selected gear
displays.
qTCS/DSC Indicator Light
This indicator light stays on for a few
seconds when the ignition switch is turned
to the ON position. If the TCS or DSC/
RSC is operating, the indicator light
flashes.
If the light stays on, the TCS, DSC or the
brake assist system may have a
malfunction and they may not operate
correctly. Take your vehicle to an
Authorized Mazda Dealer.
5-56
Driving Your Mazda
Warning/Indicator Lights and Beep Sounds
CX-9_8Z66-EA-08F_Edition3 Page222
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F

Black plate (235,1)
Rear Window Defroster
The rear window defroster clears frost,
fog, and thin ice from the rear window.
The ignition switch must be in the ON
position.
Press the switch to turn on the rear
window defroster. The rear window
defroster operates for about 15 minutes
and turns off automatically.
The indicator light illuminates during
operation.
The defroster operation can be confirmed
by the indicator in the display.
To turn off the rear window defroster
before the 15 minutes has elapsed, press
the switch again.
Indicator light
CAUTION
Do not use sharp instruments or
window cleaners with abrasives to
clean the inside of the rear window
surface. They may damage the
defroster grid inside the window.NOTE
This defroster is not designed for melting snow.
If there is an accumulation of snow on the rear
window, remove it before using the defroster.
qMirror Defrosterí
To turn on the mirror defrosters, turn the
ignition switch to the ON position and
press the rear window defroster switch
(page 5-69).
Driving Your Mazda
Switches and Controls
5-69íSome models. CX-9_8Z66-EA-08F_Edition3 Page235
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F

Black plate (241,1)
6Interior Comfort
Use of various features for drive comfort, including air-conditioning and audio
system.
Climate Control System .......................... 6-2
Operating Tips .................................... 6-2
Vent Operation (Front) ........................ 6-4
Fully Automatic Type ......................... 6-6
Vent Operation (Rear) ....................... 6-12
Control Panel (Rear) ......................... 6-14
Audio System ......................................... 6-17
Antenna ............................................. 6-17
Operating Tips for Audio System ..... 6-17
Audio Set .......................................... 6-27
Audio Control Switch Operation (Steering
Wheel) ............................................... 6-58
AUX Mode (Auxiliary input) ........... 6-61
Safety Certification ........................... 6-63
Rear Entertainment System ................. 6-64
Rear Entertainment System
í............ 6-64
Part Names ........................................ 6-73
Before Operation ............................... 6-76
Sound Output .................................... 6-82
Rear Entertainment System
Functions ........................................... 6-86
DVD video, DVD audio, Video CD, Audio
CD and MP3/WMA CD Playback (Disc
Mode) ................................................ 6-87
Auxiliary Input (AUX mode) .......... 6-101
Language Code List ........................ 6-105
Country Code List ........................... 6-107
Error Message ................................. 6-111
Symptoms and Actions ................... 6-113Bluetooth Hands-Free ......................... 6-116
Bluetooth Hands-Free
í.................. 6-116
Basic Bluetooth Hands-Free
Operation ........................................ 6-120
Convenient Use of the Hands-Free
System ............................................. 6-124
Hands-Free Setting .......................... 6-130
When Bluetooth Hands-Free Cannot be
Used ................................................ 6-136
Safety Certification ......................... 6-137
Mazda Bluetooth Hands-Free Customer
Service ............................................ 6-137
Interior Equipment ............................. 6-138
Sunvisors ......................................... 6-138
Interior Lights ................................. 6-139
Information Display ........................ 6-141
Cup Holder ...................................... 6-146
Bottle Holder ................................... 6-147
Storage Compartments .................... 6-148
Accessory Sockets .......................... 6-151
Power Outlet
í................................ 6-152
6-1íSome models.
CX-9_8Z66-EA-08F_Edition3 Page241
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F

Black plate (246,1)
Fully Automatic Type
Climate control information is displayed on the information display.
Temperature setting display (driver)Ambient temperature /Temperature
setting display (front passenger)
Mode selector display
Airflow display A/C
DUALAU TO
Air intake display
Information display
Front passenger temperature control dial
Windshield defroster switchFan control dial Driver temperature control dial
Air intake selector OFF switch AUTO switch
Mode selector
switchA/C switch
DUAL switch
OUTSIDE (Ambient
temperature) switch
6-6
Interior Comfort
Climate Control System
CX-9_8Z66-EA-08F_Edition3 Page246
Tuesday, March 31 2009 1:52 PM
Form No.8Z66-EA-08F
