2009 Lexus IS250 heater

TABLE OF CONTENTSIndex
4
3-3. Using the interior lightsInterior lights list............................ 247
• Interior lights ............................... 249
• Personal lights ............................ 249
3-4. Using the storage features List of storage fe atures................ 251
• Glove box...................................... 251
• Console boxes ........................... 252
• Overhead console.................... 253
• Cup holders................................. 254
• Bottle holders/door pockets .......................................... 256
3-5. Other interior features Sun visors......................................... 257
Vanity mirror ................................. 258
Clock ................................................. 259
Satellite switch es ......................... 260
Ashtrays ........................................... 263
Cigarette lighter ........................... 264
Power outlet ................................... 265
Seat heaters .................................... 266
Seat heaters and ventilators ..................................... 269
Armrest ............................................ 272
Rear sunshade ............................... 273
Trunk storage extension............ 275
Coat hooks ..................................... 276
Floor mat.......................................... 277
Trunk features................................ 278
Garage door opener ................... 281
Compass.......................................... 287 4-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......................... 292
Cleaning and protecting the vehicle interior............................ 295
4-2. Maintenance Maintenance requir ements .... 298
General maintenance ............... 300
Emission inspection and maintenance (I/M)
programs ..................................... 303
4-3. Do-it-yourself maintenance Do-it-yourself service precautions ................................. 304
Hood.................................................. 307
Positioning a floor jack.............. 308
Engine compartment................... 310
Tires ................................................... 325
Tire inflation pressure................. 336
Wheels............................................. 340
Air conditioning filter.................. 342
Electronic key battery ................ 345
Checking and replacing fuses ................................................ 347
Headlight aim.................................. 361
Light bulbs ....................................... 363
4Maintenance and care

11
C
Automatic transmission
Manual transmission
Seat heater switches 
Seat heater/ventilator switches

P. 266
P. 269
Automatic transmission shift lever P. 131
Shift lock override button P. 415
Cigarette lighter
Ashtrays P. 264
P. 263
Manual transmission shift lever P. 137
Parking brake lever P. 140
Cigarette lighter
Ashtrays P. 264
P. 263
Seat heater switches 
Seat heater/ventilator switches

P. 266
P. 269
: If equipped

Interior features3
209
3-1. Using the airconditioning system
and defogger
Automatic air conditioning system............. 210
Rear window and outside rear view mirror
defoggers ............................... 218
3-2. Using the audio system Audio system type................... 219
Using the radio........................ 222
Using the CD player ............. 229
Playing back MP3 and WMA discs............................ 235
Optimal use of the audio system ...................................... 241
Using the AUX adapter ....... 244
Using the steering wheel audio switches ...................... 245
3-3. Using the interior lights Interior lights list ..................... 247
• Interior lights ........................ 249
• Personal lights ...................... 249 3-4. Using the storage
features
List of storage features.......... 251
• Glove box ................................ 251
• Console boxes ......................252
• Overhead console...............253
• Cup holders ...........................254
• Bottle holders/ door pockets ......................... 256
3-5. Other interior features Sun visors ................................. 257
Vanity mirror ........................... 258
Clock ......................................... 259
Satellite switches ................... 260
Ashtrays.................................... 263
Cigarette lighter .................... 264
Power outlet ............................ 265
Seat heaters ............................ 266
Seat heaters and ventilators ............................. 269
Armrest .................................... 272
Rear sunshade ........................ 273
Trunk storage extension ....... 275
Coat hooks ............................... 276
Floor mat ................................... 277
Trunk features ......................... 278
Garage door opener ............. 281
Compass .................................. 287

216
3-1. Using the air conditioning system and defogger
Rear outlets
Direct air flow to the left or right,
up or down
Turn the knob fully to the outside
of the vehicle to close the vent
■Using the automatic mode
Fan speed is adjusted automatically in accordance with the temperature setting and
ambient conditions. As a result, the following may occur.
●The system may switch automatically to recirculated mode when the coolest
temperature setting is selected in summer.
●Immediately after is pressed, the fan may stop for a while until warm or
cool air is ready to flow.
●Cool air may flow to the area around the upper body when the heater is on.
■Using the system in recirculated air mode
The windows will fog up more easily if the recirculated air mode is used for an
extended period.
■Window defogger feature
Recirculated air mode may automatically switch to
(outside air) mode in situ-
ations where the windows need to be defogged.
■When outside air temperature approaches 32F (0 C)
The air conditioning system may not operate even when is pressed.
■When the indicator light on flashes
Press and turn off the air conditioning system before turning it on once
more. There may be a problem in the air conditioning system if the indicator light
continues to flash. Turn the air conditioning system off and have it inspected by your
Lexus dealer.

266
3-5. Other interior features
Seat heaters
Vehicles with an automatic transmissionHeats the seats
The indicator light comes on.
The higher the number, the
warmer the seats become.
Driver’s
seatFront
passenger’s
seat

: If equipped

267
3-5. Other interior features
3
Interior features
■The seat heaters can be used when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■When not in use
Set the dial to “0”. The indicator light turns off.
Vehicles with a manual transmissionHeats the seats
The indicator light comes on.
The higher the number, the
warmer the seats become.Front
passenger’s
seat
Driver’s
seat

268
3-5. Other interior features
CAUTION
■Burns
●Use caution when seating the following persons in a seat with the seat heater on
to avoid the possibility of burns:
• Babies, small children, the elderly, the sick and the disabled
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or dr ugs that induce sleep (sleeping drugs,
cold remedies, etc.)
●Do not cover the seat with anything when using the seat heater.
Using the seat heater with a blanket or cushion increases the temperature of the
seat and may lead to overheating.
NOTICE
■To prevent seat heater damage
Do not put unevenly weighted objects on the seat and do not stick sharp objects
(needles, nails, etc.) into the seat.
■To prevent battery discharge
Turn the switches off when the engine is off.

269
3-5. Other interior features
3
Interior features
Seat heaters and ventilators
The seat heaters and ventilators heat the seats and maintain good airflow
by blowing air from the seats.
Vehicles with an automatic transmission
Heats the seats
The indicator light (amber)
comes on.
The higher the number, the
warmer the seats become.
Blows air from the seats
The indicator light (green)
comes on.
The higher the number, the
stronger the airflow becomes.
Front
passenger’s
seat
Driver’s
seat

: If equipped
