2009 INFINITI QX56 display

AV
U1204 GPS COMMAV-45
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1204 GPS COMM
DescriptionINFOID:0000000004110653
Replace the AV control unit if this DTC is displayed. Refer to AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776802
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC CONSULT-III display Detection conditionAction to take
U1204 GPS COMM
[U1204] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV-168, "
Removal and Instal-
lation".
Revision: December 20092009 QX56

AV-46
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1205 GPS ROM
U1205 GPS ROM
DescriptionINFOID:0000000004110654
Replace the AV control unit if this DTC is displayed. Refer to
AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776804
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk dr
ive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC CONSULT-III display Detection conditionAction to take
U1205 GPS ROM
[U1205] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV- 1 6 8 , "
Removal and Instal-
lation".
Revision: December 20092009 QX56

AV
U1206 GPS RAMAV-47
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1206 GPS RAM
DescriptionINFOID:0000000004110655
Replace the AV control unit if this DTC is displayed. Refer to AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776806
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC CONSULT-III display Detection conditionAction to take
U1206 GPS RAM
[U1206] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV-168, "
Removal and Instal-
lation".
Revision: December 20092009 QX56

AV-48
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1207 GPS RTC
U1207 GPS RTC
DescriptionINFOID:0000000004110656
Replace the AV control unit if this DTC is displayed. Refer to
AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776808
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk dr
ive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC CONSULT-III display Detection conditionAction to take
U1207 GPS RTC
[U1207] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV- 1 6 8 , "
Removal and Instal-
lation".
Revision: December 20092009 QX56

AV
U1216 AV CONTROL UNITAV-49
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1216 AV CONTROL UNIT
DescriptionINFOID:0000000004110657
Replace the AV control unit if this DTC is displayed. Refer to AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776810
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of CONSULT-III DTC Detection Condition Action to take
U1216 CAN CONT
[U1216] Internal malfunction of AV co
ntrol unit (CAN controller) is
detected. Replace AV control unit.
Refer to AV- 1 6 8 , "
Remov-
al and Installation".
Revision: December 20092009 QX56

AV-50
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1217 AV CONTROL UNIT
U1217 AV CONTROL UNIT
DescriptionINFOID:0000000004110658
Replace the AV control unit if this DTC is displayed. Refer to
AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776812
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk dr
ive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC CONSULT-III display Detection conditionAction to take
U1217 BLUETOOTH CONN
[U1217] An internal malfunction is detected in AV control unit (Blue-
tooth module connection malfunction). Replace AV control unit. Refer
to
AV- 1 6 8 , "
Removal and Instal-
lation".
Revision: December 20092009 QX56

AV
U1218 AV CONTROL UNITAV-51
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1218 AV CONTROL UNIT
DescriptionINFOID:0000000003776813
Replace the AV control unit if this DTC is displayed. Refer to AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776814
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U1218 HDD-CONN
[U1218] Internal malfunction of AV
control unit (HDD connection
malfunction) is detected. Replace AV control unit. Refer to
AV-
168, "Removal and Installation".
Revision: December 20092009 QX56

AV-52
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1219 AV CONTROL UNIT
U1219 AV CONTROL UNIT
DescriptionINFOID:0000000004110626
Replace the AV control unit if this DTC is displayed. Refer to
AV-168, "Removal and Installation".
DTC LogicINFOID:0000000003776816
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk dr
ive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U1219 HDD-READ
[U1219] Internal ma
lfunction of AV control unit (HDD read malfunc-
tion) is detected. Replace AV control unit. Refer to
AV-
168, "Removal and Installation".
Revision: December 20092009 QX56
